- Page 1 Homepin Taiwan Company Limited SERVICE MANUAL Blues Brothers Pinball MADE IN TAIWAN Licenced to Homepin Taiwan Co Ltd by Blues Brothers Approved Ventures LLC TAIWAN CO. LTD.
- Page 2 Homepin Taiwan Company Limited Blues Brothers Pinball (BBros) Contents of this Service Manual PAGE SUBJECT Introduction & Warranty Coin Door Board and Coin Mech connection information Switch Matrix 6 & 7 Solenoid Allocation 8 to 11 Switched Lamps Allocation Reflective Opto Positions...
- Page 3 Company Limited. INTRODUCTION Thank you for purchasing a Blues Brothers Pinball machine. We are certain you will have many enjoyable hours playing this unique machine. The software provided by us is a proven version that will allow the operation and use of all features in this machine.
- Page 4 Homepin Taiwan Company Limited Blues Brothers Pinball Door Board & Coin Acceptor Connections MECHANICAL COIN MICRO SWITCH CONNECTOR (IF USED) COIN ENTRANCE LAMP CONNECTION POWER SUPPLY CONNECTION FOR CONNECTION ELECTRONIC FROM POWER COIN MECH SELECT VOLTAGE SUPPLY PCB - P7...
- Page 5 Homepin Taiwan Company Limited Blues Brothers Pinball Switch Matrix IDC P1 26P IDC CONNECTS MPU J4 PIN 4 SW RETURN 0 ALL SWITCH BOARDS TO J8 OF MPU KICK HOLE L SPINNER START R-DT-LEFT (O) L-DT-LEFT (E)
- Page 6 Blues Brothers Pinball (BBros) SOLENOID ALLOCATION DRIVER DRIVER TEST SOLENOID OR MECHANISM WIRE COLOUR BOARD TRANS- MODE TK=THICK TN=THIN CONNECTOR ISTOR 50VDC SUPPLY YELLOW (TK) SOL# TOP GATE “OPEN” PURPLE (TN) SOL# TOP GATE “CLOSE” PURPLE/WHT (TN) SOL# LIFT GATE...
- Page 7 *J7 is not connected in Blues Brothers Pinball 50VDC SUPPLY P2 Q17 *NOT USED* P3 Q18 *NOT USED* P4 N/C P5 Q19 DRIVE TO TOPPER VIA IDC J3 P6 Q16B LEFT LANE SAVE GATE “CLOSE” NOT CONNECTED...
- Page 8 Homepin Taiwan Company Limited WWW.HOMEPIN.CO M sales@homepin.com SWITCHED LAMPS – BLUES BROTHERS SWITCHED LAMPS LAMP NUMBER DRIVE SCR # NOTES ‘SHOOT AGAIN’ ‘SAVE’ - NOTE: 2 & 3 ON SAME PCB LEFT SIDE OUTLANES ‘BONUS’ ‘BONUS’ – NOTE: 4 & 5 ON SAME PCB RIGHT SIDE OUTLANES ‘EXTRA BALL’...
- Page 9 SWITCHED LAMPS (cont) LAMP NUMBER DRIVE SCR # NOTES ‘BUILD BONUS’ (CAPTIVE BALL) LEFT ARROW “E” 2ND ARROW “L” 3RD ARROW “W” ‘BONUS WHEN LIT’ 5TH ARROW “O” 6TH ARROW “O” 7TH ARROW “D” BOTTOM LETTER “E” 2RD BOTTOM LETTER “K” 3RD BOTTOM LETTER “A”...
- Page 10 GAME START BUTTON BALL LAUNCH BUTTON...
- Page 12 NOTE: “A” is a standard micro switch on the kick out hole mech...
-
Page 13: Re-Installation Procedure
Homepin Taiwan Company Limited Blues Brothers Pinball Assembly of the two gate mechanisms Both gate mechanisms are very similar the main differences being: (1) The mounted angle of the solenoid on the bracket. (2) The shape of the pull wire. - Page 14 Homepin Taiwan Company Limited Flipper control operation Blues Brothers Pinball (BBros) The flippers in BBros are electronically controlled by a flipper board mounted near each flipper assembly, H-0048. They are muted during game over and at certain other times during game play. The mute signal, ground and the 12 &...
- Page 15 Homepin Taiwan Company Limited...
- Page 16 Taiwan Company Limited BBros 22 June 2022...
-
Page 17: Fuse Allocation
Homepin Taiwan Company Limited Blues Brothers Pinball Power Supply Regulator & Fuse Allocation P1 - FROM MAINS TRANSFORMER SECONDARIES FUSE ALLOCATION F1 - 8AT - TX 70VAC F2 - 8AT - TX 70VAC F3 - 8AT - 70VDC - COIL POWER... - Page 18 Homepin Taiwan Company Limited Blues Brothers Pinball Front Cabinet Wiring Harness Tilt Bob Assembly Launch Ball Lamp PCB J4A Green/White Pin1 Orange Unreg 12V Q43 - Green Q47 - Purple DOOR Yellow AUDIO PCB J4 Volume UP Vol UP Yellow...
