- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 106381(B1&B2) Dining Table REVISION 0: 07/02/2015 PAGE 1 OF 4 REVISION 1: 12/15/2020 COASTERFURNITURE.COM...
- Page 2 106381(B1&B2) ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1.
- Page 3 106381(B1&B2) ITEM: STEP 1 Unscrew short bolt to detach plywood from table leg. Unscrew short bolt to detach plywood from table leg. (Please keep the short bolt to be use in STEP 3) (Please keep the short bolt to be use in STEP 3) STEP 2 COASTERFURNITURE.COM PAGE 3 OF 4...
- Page 4 106381(B1&B2) ITEM: STEP 3 STEP 4 COMPLETE COASTERFURNITURE.COM PAGE 4 OF 4...
- Page 5 106381(B1&B2) ITEM: 70.50" 35.50" 30.00" 28.50" 15.25" 22.25" 44.25" 31.50" 49.25" Note: Dimension tolerance ±5% COASTERFURNITURE.COM...
