ODB DCL750TM Owner's Manual

Leaf and debris collector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DCL750TM
Leaf and Debris Collector
Owner's Manual
Safety Manual
Pre-Operating Manual
Operating Manual
Maintenance Manual
Service Manual
Parts Catalog
2024 Edition
ODB Company
5118 Glen Alden Drive
Richmond, VA 23231
800-446-9823
www.leafcollector.com
DCL750TM
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCL750TM and is the answer not in the manual?

Questions and answers

Summary of Contents for ODB DCL750TM

  • Page 1 DCL750TM Leaf and Debris Collector Owner's Manual Safety Manual Pre-Operating Manual Operating Manual Maintenance Manual Service Manual Parts Catalog 2024 Edition ODB Company 5118 Glen Alden Drive Richmond, VA 23231 800-446-9823 www.leafcollector.com DCL750TM...
  • Page 2 READING AND UNDERSTANDING THIS MANUAL IF YOU HAVE ANY QUESTIONS CONCERNING THE INSTALLATION OR OPERATION OF THIS UNIT, PLEASE CALL ODB FOR ASSISTANCE BEFORE ATTEMPTING TO REPAIR OR OPERATE THE UNIT. IMPROPER USE OF ANY MACHINE CAN RESULT IN SERIOUS INJURY!

  • Page 3: Safety Precautions

    Read and understand this entire manual before operating, maintain- ing or repairing the leaf vacuum. If the decal above is missing or damaged call ODB immediately and we will send you a replacement free of charge. Never operate a unit with damaged or missing safety decals.
  • Page 4 Introduction...

  • Page 5: Table Of Contents

    Table of Contents Section A: Safety Precautions A.1 Definitions and Symbols ......................4 A.2 Basic Safety Procedures ......................7 A.3 Daily Checklist ..........................8 A.4 Personal Protective Equipment ....................9 Section B: Get to Know Your Equipment B.1 Equipment Specifications—Trailer Mounted Leaf Collector ............10 B.2 Equipment Specifications—Chassis-Mounted or Roll-Off Leaf Collector ........
  • Page 6 Table of Contents Continued Section E: Parts/Drawings E.8 Hose Group ..........................42 E.9 Rear Door Group ........................43 E.10 Box Group ..........................44 Section F: Appendix F.1 Limited Warranty ........................45 F.2 Delivery Checklist ........................48 F.3 Machine Data Page ........................49...

  • Page 7: Section A: Safety Precautions

    Do Not Over-Lubricate Do Not Ride ... (Wide Version) 200179 Danger - Do Not Ride, ... 200188 Do Not Go Under Raised Body Call ODB Big Sticker Call ODB wide sticker Caution - Proper Wheel Nut 200177 Warning - Flammable Tightness ...

  • Page 8: Definitions And Symbols

    Section A: Safety Precautions A.2 Definitions and Symbols These symbols are placed in select locations on the unit itself to signify a possible hazard. Please pay close attention to these warnings as they can prevent an accident. DANGER: Placing a limb or other body part in this area while in operation will result in death or serious injury.
  • Page 9 Section A: Safety Precautions WARNING: To prevent any potential injury, this machine MUST not be operated without the intake hose attached. WARNING: All power must be shut off and the fan must be stopped before unplugging the boot or elbow. WARNING: Do not engage the clutch with the engine RPM over 1,500.
  • Page 10 Section A: Safety Precautions WARNING: Clean the exhaust or hopper seal area before lowering the hopper in order to ensure safety as well as improve the longevity of your equipment. CAUTION: Follow all these instructions in order to safely operate your equipment as well as improve its longevity. DANGER: Do NOT sit, stand or ride on the unit, as this could potentially cause serious personal injury or death.

  • Page 11: Basic Safety Procedures

    Section A: Safety Precautions A.3 Basic Safety Procedures · Read and understand this manual and safety procedures before operating the Leaf Collector. · Study the operating section of this manual and become familiar with all controls and their functions. · Always use proper safety precautions. Observe all safety decals. ·...

  • Page 12: Daily Checklist

    Section A: Safety Precautions A.3 Daily Checklist Please follow the following steps prior to use in order to extend the life of your leaf collector: □ Fill the fuel tank with appropriate fuel □ Check engine oil level and top off as required □...

  • Page 13: Personal Protective Equipment

    Section A: Safety Precautions A.4 Personal Protective Equipment Always be sure to use proper personal protective equipment when operating machine. These items include but are not limited to: · Safety Glasses · Gloves · Proper footwear · Safety vest · Hearing protection...

  • Page 14: Section B: Get To Know Your Equipment

    Section B: Get to Know Your Equipment B.1 Equipment Specifications—Trailer Mounted Leaf Collector General: This specification describes a self-contained engine-driven vacuum leaf collecting machine. The leaf collector is trailer mounted, designed for one-person operation, and capable of picking up and completely mulching leaves from curb sides, median strips, ditches, open spillways, and other areas, then depositing the mulch in an integral 17, 20, 25 or 30 cubic yard all-steel hopper.
  • Page 15 Section B: Get to Know Your Equipment pounds thrust. The clutch handle is extended to provide easy access by the operator, allowing engagement and disengagement of the fan while the engine is running. SUCTION FAN OPTIONS – 25 INCH OR 30 INCH 25 INCH SUCTION FAN: The fan is 25"...

  • Page 16: Suction Hose

    Section B: Get to Know Your Equipment 30 INCH FAN HOUSING: The fan housing is 37" high, 39" long, and 10-1/2" wide, made of 1/4" steel plate. For added resistance to abrasive debris, the housing includes a two-piece replaceable liner made of 1/4" thick steel.
  • Page 17 Section B: Get to Know Your Equipment welded to the cross channels in such a way as to maintain a 5" overall height. The hopper and frame assembly form a unitized structure. The hopper dimensions are 101" wide, 99" long, and 80" high, creating a capacity of 17 cubic yards.

  • Page 18: Rear Doors

    Section B: Get to Know Your Equipment steel sections reinforced with 1-1/2" expanded metal. The replaceable aluminum mesh screen is bolted to the screen frames. The hopper assembly is attached to the main frame by a 3/8" thick steel plate hinge assembly which is formed, bushed, and welded to the rear of the hopper frame.
  • Page 19 Section B: Get to Know Your Equipment TRAILER FRAME: 25 Cubic Yards The leaf collector overall size is 101" wide, 314" long and 118" high. The main frame is 34" wide and 272" long, made of 6"x 2" x 5/16" wall rectangular tubing and 6" @ 10.5 pounds per foot steel channel.
  • Page 20 Section B: Get to Know Your Equipment the fan hub with four 3/8”-16 by 1” socket head cap screws and split ‘lock’ washers. The housing has a double lip seal. The fluid coupler has a sealed pilot bearing and heavy duty roller bearings. The fluid coupler provides smooth engagement as the engine RPM is increased from idle and disengages when the engine RPM is returned to idle.

  • Page 21: Fan Housing

    Section B: Get to Know Your Equipment SUCTION FAN - 25 And 30 Cubic Yard Units The fan is 30" diameter, 8-1/4" wide at the tip and has six radial blades. The fan backing plate is 1/4" thick steel and the blades are 3/8" thick AR400 abrasion resisting alloy steel with 1/8" formed reinforcing welded to the back faces.
  • Page 22 Section B: Get to Know Your Equipment per foot to combine flexibility with heavy duty performance. HOPPER AND HOPPER FRAME: 17 Cubic Yards- 20 Cubic Yards The hopper frame is 100-3/4" wide, 99" long and made of 5" @ 9 pounds per foot channel supporting the full length and width of the hopper.
  • Page 23 Section B: Get to Know Your Equipment This hopper capacity is achieved without an excessive front hopper extension. The hopper is made from 12 gauge sheet steel all welded construction with five supporting ribs of 3" structural channel encircling the hopper for strength. The inside of the hopper is smooth for ease of dumping a fully packed load.

  • Page 24: Trailer And Towing Hardware

    Section B: Get to Know Your Equipment The Quick Disconnect device includes a flange on the end of the suction hose, a split ring attached to the blower housing, and an over-center clamp for locking the split ring over the hose flange. A safety cover is also provided, for use when the suction hose is removed.

  • Page 25: Section C: Maintaining Your Equipment

    Section C: Maintaining Your Equipment C.1 P.T.O. Maintenance · Release and shaft bearings should be lubricated with a short fiber bearing grease. · Release bearings require lubrication every ten hours of operation. · Shaft bearings require lubrication every fifty hours of operation. ·...

  • Page 26: Screen Panels Cleaning And Removal

    Section C: Maintaining Your Equipment C.3 Screen Panels Cleaning and Removal · Normal, day-to-day cleaning of the screens can be accomplished without removing the panels from the hopper. · Simply spray off the screens with a water hose or low pressure sprayer. ·...

  • Page 27: Optional Equipment Maintenance

    Section C: Maintaining Your Equipment C.5 Optional Equipment Maintenance · For all information regarding the installation, operation and maintenance of the optional fluid coupling system, please refer to section E.2 in this manual. · For all information regarding the operation and maintenance of the Kohler KDI 2504 TCR Final Tier 4 Diesel- 74HP engine, please refer to the enclosed manufacturer’s maintenance manual.

  • Page 28: Section D: Proper Use And Operation Procedures

    Section D: Proper Use and Operation Procedures D.1 Instrument Panel Operation · The instrument panel is located on the front side of the Leaf Collector. · The panel includes an off/start/on switch [1], a throttle control [2], and the LED display module [3]. ·...

  • Page 29: Hopper Unloading Instructions

    Section D: Proper Use and Operation Procedures materials will shorten the life of the leaf collector parts. · If boom operation is too fast for smooth operation, individual functions can be adjusted by the needle valves or by decreasing the flow with flow control valve mounted on the exhaust chute, depending on your individual machine’s setup.

  • Page 30: Starting The Engine And Equipment

    Section D: Proper Use and Operation Procedures 12. Turn the engine off. Caution: The fan will continue to rotate after the engine has been shut down. Wait 5 minutes after turning engine off before performing any work. Touching the fan while it is still rotating may cause serious injury or death to the operator.

  • Page 31: Section E: Parts/Drawings

    Section E: Parts/Drawings 280010310 1990XZ 837XZ 1988XZ 808XZ SCL800017JD 1196XZ 1989XZ 8002300 Valve Handle 800-446-9823 SCL800TM...

  • Page 32: Hydraulic Components

    Section E: Parts/Drawings Hydraulic Components Item Number Part Number Description Quantity 837XZ DCL HYD HOIST DOWN 25CYD STR 808XZ DCL HYD HOSE RETURN 1988XZ DCL750,HYD,HOIST,HOSE 1989XZ DCL750,HYD,SUCTION,HOSE 1990XZ DCL750,HYD,RETURN,HOSE 1991XZ DCL750,HYD,BOOM,HOSE HYF1000 FITTING,BOTTOM PORT ON EATON HYF1023 FITTING,PUMP TO TANK FILTER H HYF1026 FITTING,FILTER HEAD TO PUMP H HYF1085...
  • Page 33 Section E: Parts/Drawings Item Number Part Number Description Quantity 8002300 HAND VALVE HYF1006 FITTING,HAND VALVE TO HYD PUMP 156XZ BUCHER AL001 M8 HANDLE 5501011A HAND VALVE COVER SCL65TM 5501011C HAND VALVE COVER RUBBER GASKET...
  • Page 34 Section E: Parts/Drawings Item Number Part Number Description Quantity 1685XZ ASM,HYD,TANK,BUYERS SMR15SF10 1685XZ002 BUYERS HFA91025 1685XZ003 BUYERS FILLER BREATHER...
  • Page 35 Section E: Parts/Drawings Item Number Part Number Description Quantity BHCB BATTERY BOX HOLD DOWN STD2200 BATTERY GROUP 34 LCT6015B BATTERY CABLE GROUND LCT60084B BATTERY CABLE BATTERY TO START LCT60024SS BATTERY CABLEGROUND 60084R BATTERY CABLE 84" RED 4 GAUGE. Not Shown 711XZ LIMIT SWITCH &...
  • Page 36 Section E: Parts/Drawings Item Number Part Number Description Quantity 1672XZ 25YD CHASSIS STANDARD TM 2803XZ JACK PLATE NOZZLE ATTACHMENT SCL800624 PARKING JACK 2000092 CLEVIS HOOK 1/2 INCH SCL800 S SCL800623B PINTLE EYE ONLY 800 1642XZ PARKING JACK HANDLE 5502011 HAND VALVE BRACKET BOLT ON SCL 758XZ BODY PROP SAFETY HANDLE 757XZ...
  • Page 37 Section E: Parts/Drawings Item Number Part Number Description Quantity HAP103 HANGER KIT 12K AXLE HAP2033 HANGER KIT B 12K AXLES 2091259 10K AXLE, HD SPRNGS SCL822620DWR DUAL WHEEL & TIRE ASSEMBLY...
  • Page 38 Section E: Parts/Drawings Item Number Part Number Description Quantity 8003501B FUEL TANK, 40 GAL EPA CERTIFIED GAS 1672XZ033 FUEL TANK BOTTOM...
  • Page 39 Section E: Parts/Drawings Item Number Part Number Description Quantity 1688XZ ASM,BOX EXH DUCT LFB-00000108 GASKET (1/2"), EXH CHUTE 1687XZ ASM,BLOWER,DUCT LCT616801 BEARING BOOM SUPPORT LFB-A0000003 FAN HOUSING, 25”, NO LINERS 1876XZ ASM,25” CCW IMPELLER STAR LCT650601 Q3 2 1/4 BUSHING LCT600615 SHAFT END PROTECTORS BELT DRIVE 1689XZ...
  • Page 40 Section E: Parts/Drawings Item Number Part Number Description Quantity LCT616606A BOOM ARM FRONT LOCKING SCL816606A BOOM SWIVEL MAST SCL MPCS15012 CYL HOSE BOOM M3219PC PUMP COVER M3219RUB PUMP COVER RUBBER MPM3219S BOOM PUMP LCT616615D PUSH BUTTON STATION HOLD DOWN U CLAMP STD2320D PUSH BUTTON BOX COVER ONLY STD2321C...
  • Page 41 Section E: Parts/Drawings Section E: Parts/Drawings E.7b Hydraulic Boom Pump ITEM # PART NUMBER DESCRIPTION MPM3219S COMPLETE PUMP ASSEMBLY (ALL ABOVE) MP-08004 ELECTRIC MOTOR, 12V MP-17744 SOLENOID SWITCH, HEAVY DUTY MP-19283D COIL, CARTRIDGE ASSEMBLY MP-07193D CARTRIDGE MP-10861D COIL, 2 WAY- 2 POSITION MP-06232 PLASTIC RESERVOIR, 3.5”...
  • Page 42 Section E: Parts/Drawings Item Number Part Number Description Quantity LCT616601 INTAKE NOZZLE 16INCH LCT616616 HOSE BAND LCSDH16120UC CLEAR URETHANE HOSE LCT616603U HOSE SUPPORT BAND ‘U’ 1/4 PROOF CHAIN 11 LINK 20010 QUICK LINK 5/16 INCH PVCG46 GRIP FOR LCT616.601...
  • Page 43 Section E: Parts/Drawings Item Number Part Number Description Quantity 1690XZ FAB,BOX,SINGLE DOOR 75023 BRACKET PLATE SCL DOOR HARDWARE 75022 ROD BRACKET SCL DOOR HARDWARE 750214A 800 DOOR ROD LH 19696X SCL DOOR HDW HANDLE 196939 SCL DOOR HDW BUSHING 19697X SCL DOOR HDW SEAL PIN 19694X SCL DOOR HDW SEAL PLATE...
  • Page 44 Section E: Parts/Drawings Item Number Part Number Description Quantity 1674XZ 25YD DCL750 BOX STANDARD SCL805810 BOX SCREEN SCL800 1678XZ FAB,BOX,REAR BOX HINGE 1679XZ FAB,BOX,REAR HINGE PIN 75021 KEEPER SCL DOOR HARDWARE ELC-00000123 BASIC ICC,THREE RED LED,LIGHT BAR STD2201 MARKER LIGHT L.E.D. RED 3/4” W LFM-A0000077 SINGLE LED STROBE LIGHT 1674XZ021...

  • Page 45: Section F: Appendix

    Section F: Appendix ARM / TruckCorp LLC Limited Warranty A. GENERAL PROVISIONS The warranties described below are provided by ARM, a TruckCorp LLC Company ("ARM"), to the original purchaser of new equipment purchased directly from ARM or an authorized reseller of new ARM products.
  • Page 46 Section F: Appendix exposure to extreme temperatures, hoist failure because of being in the raised position for extended periods of time, and other situations outside of ARM’s control. (6) Normal maintenance, including parts and service. (7) Damage to any part of a plow unit, hitch, plowing vehicle or loss of use incurred by the striking of movable or immovable objects while using the equipment, plowing, or removing snow.
  • Page 47 Section F: Appendix warranty on any other item unless it delivers to the purchaser a separate written certificate specifically warranting the item. G. JURISDICTION AND VENUE The limited warranties provided hereunder shall be construed and enforced under Ohio law. Any legal action regarding a dispute under this warranty or an action to enforce the terms hereof shall be brought in the State Court located in Stark County, Ohio or in the Federal District Court for the Northern District of Ohio.

  • Page 48: Delivery Checklist

    Section F: Appendix Delivery Checklist To validate your warranty, please review the delivery checklist and sign off on each item: Task Inspection Initial & Date Review Owner’s Manual Review Pintle Hitch Installation Verify Proper installed Height for level towing Review 7-way trailer plug Attach to tow vehicle and verify operation Engine operation Ensure function and placement: Air filter...
  • Page 49 Section F: Appendix Machine Data Page Equipment Serial Number Size Model Number...
