AURATON Carina
User manual ver. 20200908
The document presents collected information on safety, assembly and use of AURATON Carina.
Weekly, multifunctional timer switch
AURATON Carina is a weekly, multifunctional timer switch designed for controlling a pump in domestic
hot water (DHW) circulation system. Auraton Carina may be also used to activate any device with a
voltage of 230 V AC and maximum current of 16 A.
8 programs for switching ON/OFF devices in one day and max. 56 repeatable programs for
switching ON/OFF devices in one week with the set time accuracy of 1 second.
Easy programming with buttons identified by corresponding symbols displayed on LCD screen
Function of random switching ON/OFF.
Function of manual switching ON/OFF.
Red LED indicator for the output status. The LED is activated when output signal is ON (active).
Green LED indicator for indicating correct power supply of the timer switch (230 V AC).
The function of maintaining the state of the display and saved programs after power supply
failure or when the time switch is unplugged from the outlet (approx. one week).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Carina and is the answer not in the manual?

Questions and answers

Summary of Contents for AURATON Carina

  • Page 1 AURATON Carina is a weekly, multifunctional timer switch designed for controlling a pump in domestic hot water (DHW) circulation system. Auraton Carina may be also used to activate any device with a voltage of 230 V AC and maximum current of 16 A.
  • Page 2 Display 12 h clock mode Weekdays: MO – Monday, TU – Tuesday, WE – Wednesday, TH – Thursday FR – Friday, SA – Saturday, SU – Sunday Clock Random mode Daylight Saving Time Output status OFF Automatic mode Output status ON Program number: ON –...

  • Page 3: Setting The Clock

    Setting the clock In order to set the clock: Press and hold CLOCK button. Then use the following buttons: WEEK – to set a weekday, HOUR – to set the hour, MIN – to set minutes, SEC – to set seconds. Default setting of the clock operation is to display time in 24-hour mode.
  • Page 4 Multi-function display Button for setting minutes Button for setting seconds Reset of the device Manual mode button Activation indicator (red) Control socket for actuating device (socket of E or F type) Power indicator (green)
  • Page 5 Button for setting programs Button for setting time Button for setting day of the week Button for setting hours Programming The time switch may be programmed with maximum 8 programs. Each setting is made individually. To enter the programming mode, proceed as follows: Press PROG button.

  • Page 6: Automatic Operation Mode

    the time of program switching off is to be set. Use buttons: WEEK (weekend), HOUR (hours), MIN (minutes), SEC (seconds) to set the time. When switching off time is set, press PROG, button, to continue programming of the next program. For the next program repeat the procedure described in paragraphs 2-4 above. In order to exit the programming mode, press CLOCK button or wait 10 seconds.

  • Page 7: Manual Operation Mode

    “ON” time. Random operation mode If this function is enabled, Auraton Carina will randomly turn on and off the controlled device, e.g. bedside lamp, to simulate presence of person(s) in the house.

  • Page 8: Daylight Saving Time

    Daylight Saving Time In order to activate DST function, which eliminates the need to adjust the clock, press simultaneously HOUR and MIN buttons. The display will show DST icon and the clock will automatically add one hour to the displayed time. In order to switch off DST function, again press simultaneously HOUR and MIN buttons.

  • Page 9: Disposal Of The Device

    The user shall return it to a collection point for electrical and electronic waste. Contact and address of the manufacturer: LARS, ul. Świerkowa 14 64-320 Niepruszewo www.auraton.pl Download User manual Declaration of conformity...
