- Page 1 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Assembly instruction “System” System 1 + Element 8 Art.-No. 4591-30 + Art.-No. 4591-30-8 (Version: Steel posts) Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 1 von 24...
-
Page 2: Table Of Contents
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Contents Assembly instruction “System” System 1 + Element 8 Art.-No. 4591-30 + Art.-No. 4591-30-8 (Version: Steel posts)............. 1 Introduction Assembling........................ 3 Datasheet System1 + Element; Art. 4591-30 + Art. 4591-30-8............. 4 Delivery contents (parts list with part numbers)................ -
Page 3: Introduction Assembling
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 1 Introduction Assembling General information This equipment should be installed, inspected, maintained and operated in accordance with EN1176-7 guidelines. Before installation work commences, please check that you have all of the equipment and fixation components in the parts list provided (see Tables 3-1 and 3-2). -
Page 4: Datasheet System1 + Element; Art. 4591-30 + Art. 4591-30-8
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Datasheet System1 + Element; Art. 4591-30 + Art. 4591-30-8 Space requirement including safety area: 7.30 m x 7.30 m Height of fall: 1.50 m The images (individual drawings) are not to scale!! -
Page 5: Delivery Contents (Parts List With Part Numbers)
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 3 Delivery contents (parts list with part numbers) In words Table 3-1: Delivery contents, in words Pos. Quantity Element / Size O.K. Missing Description Steel posts Ø 102 mm, length 3.00 m... -
Page 6: Table 3-2: Delivery Contents, In Symbols
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 In symbols Table 3-2: Delivery contents, in symbols Pos. Quantity Symbol Pre-assambled at Pos. 6 Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 6 von 24... - Page 7 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Art.-Nr. 4591-30-8 Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 7 von 24...
-
Page 8: Erection Instructions
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Erection instructions Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 8 von 24... - Page 9 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 9 von 24...
- Page 10 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 10 von 24...
- Page 11 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 11 von 24...
- Page 12 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Setting time for concrete at least 7-8 days Concrete C25/30 (for foundation) Fall protection Foundation radius at least 10 cm Drainage layer 10 cm Unit spacing (centre-centre) posts Clearance post dimensions Upper play level P.1 - 5...
-
Page 13: Post Installation Checks
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Post installation checks If the equipment has not been installed safely, you must ensure that the public is prevented from using it. Marking filler depth • Labelling the posts to show the depth of material provided as fall protection (i.e. -
Page 14: B Maintenance Instruction "System" System 1 + Element
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Maintenance instruction “System” System 1 + Element 8 Art.-No. 4591-30 + Art.-No. 4591-30-8 (Version: Steel posts) Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 14 von 24... -
Page 15: Introduction Maintenance
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Introduction Maintenance General informations This equipment should be installed, inspected, maintained and operated in accordance with EN 1176-7 guidelines. Please note: Providing any necessary repairs are carried out, a piece of play equipment that is inspected regularly cannot become so damaged that it is dangerous. -
Page 16: General Maintenance Information
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 General maintenance information Maintenance intervals Maintenance intervals are based on average use. Please note that more frequent inspections and/or maintenance are required if the play equipment is subject to intensive use. - Page 17 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 6.10 Faults Faults must be repaired as soon as they are detected. If serious defects that compromise safety cannot be repaired straight away, the public must be prevented from using the equipment with immediate effect.
-
Page 18: Regular Maintenance
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Regular maintenance Image Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 18 von 24... - Page 19 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Regular maintenance (Text) m = monthly j = 1/4 quarterly j = 1/2 half-yearly ¼ j ½ j Check ground in fall and protection area for hard objects and loose foundations.
-
Page 20: Maintenance Timetable
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Maintenance timetable Special advices 8.1.1 Maintenance interval We strongly advise you to carry out inspections and maintenance work within the specified periods as use of the equipment, the weather and malicious vandalism cause wear and tear that compromises the safety and function of the equipment. -
Page 21: Monthly Maintenance
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Monthly maintenance • Check the spaces between the equipment and the ground (clearance and height of fall). • Check the ground surface in the area with fall protection for hard objects and loose foundations. -
Page 22: Annual Maintenance
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 • Annual Maintenance • 12 Annual maintenance • Ascertaining that the equipment, foundations and surfaces are safe for operation. • In particular, the equipment should be checked for decay and corrosion. It may be necessary to dig out or excavate certain components in order to do so. - Page 23 KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 Kübler Sport · Karl-Ferdinand-Braun-Straße 3 · D-71522 Backnang · www.kuebler-sport.de Seite 23 von 24...
-
Page 24: Maintenance Printout
KÜBLER SPORT GMBH | SERVICE ASSEMBLY AND OPERATiON iNSTRUCTiON | S4040 14 Hand over document After the installation of the equipment pass the installation and maintenance documents to the operator. The operator has to receive the hand over documents. The complete filled and signed hand over document should be sent to the supplier.
