Alamo Industrial Built Sharper TRAXX RF TR477936 Operator's Manual

Snow blade
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SNOW BLADE
Published 05/19
This Operator's Manual is an
integral part of the safe operation of
this
maintained with the unit at all times.
READ,
FOLLOW the Safety and Operation
Instructions
manual and the TRAXX RF manual
before operating the equipment.
C01-Cover_TRAXX
ALAMO INDUSTRIAL
1502 E. Walnut
Seguin, Texas 78155
830-372-3551
Email: parts@alamo-industrial.com
OPERATOR'S MANUAL
machine
and
UNDERSTAND,
contained
®
©2019 Alamo Group Inc.
Important
and
must
be
Instructions are found
in the Mower Safety
and
Video that can be
instantly accessed on
in
this
the
internet
www.algqr.com/ave
Part No. TR477936
Operating
Safety
at:
$0.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Built Sharper TRAXX RF TR477936 and is the answer not in the manual?

Questions and answers

Related Manuals for Alamo Industrial Built Sharper TRAXX RF TR477936

Summary of Contents for Alamo Industrial Built Sharper TRAXX RF TR477936

  • Page 1 FOLLOW the Safety and Operation instantly accessed on Instructions contained this internet manual and the TRAXX RF manual www.algqr.com/ave before operating the equipment. C01-Cover_TRAXX ® ALAMO INDUSTRIAL 1502 E. Walnut Seguin, Texas 78155 830-372-3551 Email: parts@alamo-industrial.com ©2019 Alamo Group Inc. $0.00...

  • Page 3: Osha Training Requirements

    Your Authorized Alamo Industrial Dealer may have shown this video and presented you a DVD Video when you purchased your mower. If you or any mower operator have not seen this video, Watch the Video, Read this Operator’s Manual, and Complete the Video Guidebook before operating your new mower.
  • Page 4 Alamo Industrial Division is willing to provide one (1) AEM Mower Safety Practices Video Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video DVD Format – AEM/FEMA Mower Operator Safety Video Mower Operator’s Manual AEM Mower Operator’s Safety Manual...
  • Page 5 Contact your Dealer to explain any instructions that you do not fully understand. The care you give your Alamo Industrial machine will greatly determine your satisfaction with its performance and its service life. Carefully read and follow the instructions in this manual to provide you with a thorough understanding of your new implement and its intended use and service requirements.

  • Page 6: Pre-Delivery Service

    DEALER to CUSTOMER Pre-Delivery/ Operation Instructions Dealer should inform the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable. Dealer should inform Purchaser to review the contents of the Operator’s Manual including safety equipment, safe operation and maintenance, to review the Safety Signs on the TRAXX RF Unit and of Purchaser’s responsibility to train his/her operators of safe operation procedures.

  • Page 7: Table Of Contents

    Table of Contents SAFETY SECTION ......................1-1 GENERAL SAFETY INSTRUCTIONS AND PRACTICES ................. 1-2 OPERATOR SAFETY ............................1-3 CRUSHING HAZARDS ............................1-4 CONNECTING OR DISCONNECTING IMPLEMENT SAFETY ................ 1-5 SLIDING HAZARD ............................. 1-6 THROWN OBJECTS HAZARDS ........................1-7 THROWN OBJECTS HAZARD (CONTINUED) ....................1-8 RUN OVER HAZARDS ............................

  • Page 9: Safety Section

    SAFETY SECTION Safety Section 1-1 © 2019 Alamo Group Inc.

  • Page 10: General Safety Instructions And Practices

    SAFETY GENERAL SAFETY INSTRUCTIONS AND PRACTICES A careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions.

  • Page 11: Operator Safety

    SAFETY OPERATOR SAFETY TO AVOID SERIOUS INJURY OR DEATH DO THE FOLLOWING: • READ, UNDERSTAND and FOLLOW Operator's Manual instructions, Warnings and Safety Messages. • WEAR SAFETY GLASSES, safety shoes, hard hat, hearing protection and gloves when operating or repairing equipment •...

  • Page 12: Crushing Hazards

    SAFETY CRUSHING HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM FALLING OFF TRACTOR, EQUIPMENT RUN OVER, ROLLOVER AND CRUSHING BY FALLING WING OR IMPLEMENT: WHEN RAISING OR LOWERING MOWER: • Raise or lower when no one is within 20 feet of mower. •...

  • Page 13: Connecting Or Disconnecting Implement Safety

    SAFETY CONNECTING OR DISCONNECTING IMPLEMENT SAFETY TO AVOID SERIOUS INJURY OR DEATH FROM BEING CRUSHED BY TRACTOR OR IMPLEMENT: WHEN BACKING tractor to implement hitch: • DO NOT ALLOW BYSTANDERS between tractor and implement. BEFORE connecting and disconnecting implement hitch: •...

  • Page 14: Sliding Hazard

    SAFETY SLIDING HAZARD TO AVOID SERIOUS INJURY OR DEATH FROM SLIDING OR EQUIPMENT ROLLOVER: Never attempt to operate the TRAXX RF with metal cleats or spiked track on concrete hillsides or hard hillside surfaces. Operation of the spiked or cleated track on concrete or hard surface hillsides could result in sudden and violent loss of traction and control of the machine and may result in serious injury or death.

  • Page 15: Thrown Objects Hazards

    SAFETY THROWN OBJECTS HAZARDS MOWERS CAN THROW OBJECTS 300 FEET OR MORE UNDER ADVERSE CONDITIONS. TO AVOID SERIOUS INJURY OR DEATH TO OPERATOR OR BYSTANDERS FROM THROWN OBJECTS: • KEEP bystanders 300 feet away STOP MOWING IF PASSERSBY ARE WITHIN 300 FEET UNLESS: •...

  • Page 16: Thrown Objects Hazard (Continued)

    SAFETY THROWN OBJECTS HAZARD (CONTINUED) MOWER OPERATION: • DO NOT exceed mower's rated Cutting Capacity or cut non-vegetative material. • ADJUST mower sections or wing close and parallel to ground without exposing blades • ADJUST cutting HEIGHT to AVOID BLADE CONTACT with solid objects like wire, rocks, posts, curbs, guard rails and fixed obstructions.

  • Page 17: Run Over Hazards

    SAFETY RUN OVER HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM FALLING OFF TRACTOR OR EQUIPMENT RUN OVER: • Never allow riders on unit. • Never ride on unit. • Never stand in front of the mower, stay 300 feet away from the front of the mower while mowing. •...

  • Page 18: Mower Blade Contact Hazards

    SAFETY MOWER BLADE CONTACT HAZARDS KEEP AWAY FROM ROTATING BLADES TO AVOID SERIOUS INJURY OR DEATH FROM BLADE CONTACT: • STAY AWAY and KEEP HANDS, FEET and BODY AWAY from rotating blades, drivelines and parts until all moving elements have stopped. •...

  • Page 19: High Pressure Oil Leak Hazard

    SAFETY HIGH PRESSURE OIL LEAK HAZARD TO AVOID SERIOUS INJURY OR DEATH FROM HIGH PRESSURE HYDRAULIC OIL LEAKS PENERATING SKIN: • DO NOT OPERATE equipment with oil or fuel leaks. • KEEP all hydraulic hoses, lines and connections in GOOD CONDITION and TIGHT before applying system pressure.

  • Page 20: Electrical & Fire Hazards

    SAFETY ELECTRICAL & FIRE HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM ELECTRICAL CONTACT WHEN WORKING AROUND ELECTRICAL POWER LINES, GAS LINES AND UTILITY LINES: • INSPECT mowing area for overhead or underground electrical power lines, obstructions, gas lines, cables and Utility, Municipal, or other type structure. •...

  • Page 21: Hazards With Maintenance Of Implement

    SAFETY HAZARDS WITH MAINTENANCE OF IMPLEMENT AVOID SERIOUS INJURY OR DEATH FROM COMPONENT FAILURE BY KEEPING IMPLEMENT IN GOOD OPERATING CONDITION PERFORMING PROPER SERVICE, REPAIRS MAINTENANCE. BEFORE PERFORMING SERVICE, REPAIRS AND MAINTENANCE ON THE IMPLEMENT: • STOP ENGINE, engage parking brake, lower implement, allow all moving parts to stop and remove key. •...

  • Page 22: Operator Safety Instructions And Practices

    SAFETY OPERATOR SAFETY INSTRUCTIONS AND PRACTICES Make sure that no bystander, animal or obstruction such as a vehicle, building or street sign are within the width of the Snow Plow. The design of the Snow Plow may impair the operator vision when operating. Use extreme caution to ensure that the Snow Plow is not driven into the path of pedestrian or vehicle traffic.
  • Page 23 SAFETY Never attempt to repair, lubricate, adjust, clean, remove obstructions or perform any other type of service to any component while the Snow Plow is in motion or while the engine is running. Completely shut down the engine and wait for all motion to come to a complete stop before servicing the Snow Plow.

  • Page 24: Transporting Safety Instructions And Practices

    SAFETY TRANSPORTING SAFETY INSTRUCTIONS AND PRACTICES Transport the Truck, Power Unit, and Snow Plow only at safe speeds. Serious accidents and injuries can result from driving this equipment at unsafe speeds. Become familiar with the driving characteristics of the equipment and how it handles before operating or transporting on streets and highways.

  • Page 25: Parts Information

    SAFETY PARTS INFORMATION PARTS INFORMATION Alamo Industrial mowers use balanced and matched system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Alamo Industrial specifications. Non-genuine "will fit" parts do not consistently meet these specifications.

  • Page 26: Decal Location

    NOTE: Alamo Industrial supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Alamo Industrial cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).

  • Page 27: Decal Description

    SAFETY Decal Description Traxx Snow Blade 05/19 Safety Section 1-19 © 2019 Alamo Group Inc.
  • Page 28 SAFETY Traxx Snow Blade 05/19 Safety Section 1-20 © 2019 Alamo Group Inc.
  • Page 29 SAFETY Traxx Snow Blade 05/19 Safety Section 1-21 © 2019 Alamo Group Inc.

  • Page 30: Federal Laws And Regulations

    SAFETY FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such.
  • Page 31 SAFETY Traxx Snow Blade 05/19 Safety Section 1-23 © 2019 Alamo Group Inc.
  • Page 32 SAFETY Traxx Snow Blade 05/19 Safety Section 1-24 © 2019 Alamo Group Inc.

  • Page 33: Introduction Section

    INTRODUCTION SECTION Introduction Section 2-1 © 2019 Alamo Group Inc.
  • Page 34 The Snow Blade must not be used by minors, untrained and unqualified personnel. This equipment must be only installed on the Traxx radio controlled machine sold by Alamo Industrial. For the purpose of this Alamo Industrial equipment, the following definitions apply.

  • Page 35: Description Of The Snow Blade

    INTRODUCTION DESCRIPTION OF THE SNOW BLADE 1. Frame 2. Snow Scraping Ring 3. Rubber Covering 4. Head Lift Spring 5. Jack Pipe for Tilt 6. Control Valve 7. Jack Tilt 8. Catch Plate 9. Rotating Wheel 10. Spring Tension Screw Traxx Snow Blade 05/19 Introduction Section 2-3 ©...

  • Page 36: Before Operating This Machine

    NOTE: Warranties are honored only if completed “Owner Registration and Warranty” forms are received by Alamo Industrial within thirty days of delivery of the implement. 3. Record the Snow Blade Model and Serial Numbers on the Warranty page at the front of the Operator’s Manual.

  • Page 37: Operation Section

    OPERATION SECTION Operation Section 4-1 © 2019 Alamo Group Inc.

  • Page 38: Operation

    OPERATION ALAMO INDUSTRIAL TRAXX SNOW BLADE OPERATION INSTRUCTIONS ALAMO INDUSTRIAL TRAXX Snow Blades are manufactured with quality material by skilled workers. These snow blades are designed for removing accumulations of snow from driveways, barnyards, roadways, and parking lots. It is the operator’s responsibility to be knowledgeable of all potential operating hazards and to take every reasonable precaution to ensure oneself, others, animals, and property are not injured or damaged by the Snow Blade, or TRAXX RF.

  • Page 39: Standard Equipment & Specifications

    OPERATION 1. STANDARD EQUIPMENT & SPECIFICATIONS SPECIFICATIONS Weight 271 lbs. (123kg) 2. CONNECTING THE SNOW BLADE TO THE TRAXX RF Use extreme caution when connecting the snow blade to the TRAXX RF. The snow blade should be securely resting at ground level. Keep hands and feet out from under the snow blade and clear of pinch points between the TRAXX RF and snow blade.
  • Page 40 OPERATION 2.1 Connecting the Snow Blade to the TRAXX RF 1. Align the TRAXX RF until the TRAXX mounting plate (a) is centered and parallel to the turbine plate (b). 2. Lower the TRAXX plate, move forward slowly until the two blades are in contact with one another and lift the TRAXX plate until the turbine plate is completely hooked.

  • Page 41: Wheel Adjustment

    OPERATION NOTE: To tilt the blade to the left or to the right, use the switch (f) of the remote control. Before connecting the snow blade pipes, carefully clean all quick disconnect. The introduction of foreign bodies in the circuit can cause pump breakage. 3.

  • Page 43: Maintenance Section

    MAINTENANCE SECTION Maintenance Section 5-1 © 2019 Alamo Group Inc.

  • Page 44: Maintenance

    MAINTENANCE All maintenance, cleaning and repairing operations must be carried out when the engine is turned off and the security key is removed. Before performing any cleaning or maintenance operations, wait for the machine and equipment to cool down. Before any working day, check the machine is in good condition, the wear and tear of the machine and its hydraulic hoses, that there is no oil spill and that all safety decals are perfectly intact and readable.

  • Page 45: Replacement Of Hydraulic Hoses

    MAINTENANCE 3.REPLACEMENT OF HYDRAULIC HOSES Check the wear and tear of the hydraulic hoses or if there are oil spills. The hydraulic hoses (a) must be replaced periodically (every 2000 hours or on a yearly basis) or when there are leaks) 4.GREASING POINTS GREASING POINTS 1.
  • Page 46 Traxx Snow Blade 05/19 Part No. TR477936...
