- Page 1 EN User Manual | Hob ZGO62414BA zanussi.com\register...
-
Page 2: Table Of Contents
Welcome to Zanussi! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................11 5. -
Page 3: General Safety
• Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. • If the appliance has a child safety device, it should be activated. - Page 4 • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. • If the glass ceramic surface / glass surface is cracked, switch off the appliance and unplug it from the mains. In case the appliance is connected to the mains directly using junction box, remove the fuse to disconnect the appliance from power supply.
-
Page 5: Safety Instructions
2. SAFETY INSTRUCTIONS • Before carrying out any operation make This appliance is suitable for the following sure that the appliance is disconnected markets: EG from the power supply. • Make sure that the parameters on the 2.1 Installation rating plate are compatible with the electrical ratings of the mains power supply. -
Page 6: Gas Connection
2.3 Gas connection • Make sure that the ventilation openings are not blocked. • Do not let the appliance stay unattended CAUTION! during operation. When using a gas cylinder, always keep • Set the cooking zone to “off” after each it on a flat horizontal surface (with the use. -
Page 7: Installation
have to move them on the cooking • Clean the appliance regularly to prevent surface. the deterioration of the surface material. • To prevent spills, use only stable • Switch off the appliance and let it cool cookware with the correct shape and down before cleaning. -
Page 8: Injectors Replacement
• the material is not hardened, but shows its correct elasticity; Choose fixed connections or use a flexible • the fastening clamps are not rusted; pipe in stainless steel in compliance with the • expired term is not due. regulation in force. If you use flexible metallic If one or more defects are visible, do not pipes, be careful they do not come in touch repair the pipe, but replace it. -
Page 9: Connection Cable
• from natural gas G20 20 mbar to liquid approximately 2 cm longer than the brown (or gas, fully tighten the bypass screw in. black) phase wire. • from liquid gas to natural gas G20 20 3.7 Assembly mbar, undo the bypass screw approximately 1/4 of a turn. - Page 10 3.8 Possibilities for insertion The panel installed below the hob must be easy to remove and let an easy access in case a technical assistance intervention is necessary. Kitchen unit with door min 6 mm min 30 mm A. Supplied seal B.
-
Page 11: Product Description
4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Auxiliary burner Control knobs 4.2 Control knob Symbol Description no gas supply / off position ignition position / maximum gas supply minimum gas supply Rapid burner Semi-rapid burner 5. DAILY USE 5.2 Ignition of the burner WARNING! Refer to Safety chapters. -
Page 12: Hints And Tips
If after some tries the burner does not The spark generator can start light, check if the crown and its cap are in automatically when you switch on the correct positions. mains, after installation or a power cut. It is normal. WARNING! Do not keep the control knob pushed for more than 15 seconds. -
Page 13: Care And Cleaning
7. CARE AND CLEANING WARNING! 7.3 Removing and assembling pan supports Refer to Safety chapters. After cleaning of the hob, make sure that pan 7.1 General information supports are in a correct position. In order to place a pan support properly. •... -
Page 14: Troubleshooting
8. TROUBLESHOOTING WARNING! Refer to Safety chapters. 8.1 What to do if... Problem Possible cause Remedy There is no spark when you try to The hob is not connected to an elec‐ Check if the hob is correctly connec‐ activate the spark generator. trical supply or it is connected incor‐... -
Page 15: Labels Supplied With The Accessories Bag
8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send this C. -
Page 16: Environmental Concerns
9.3 Other technical data Gas original: G20 (2H) 20 mbar 7,7 kW TOTAL POWER: Gas replacement: G30 (3+) 28-30 mbar 545 g/h G31 (3+) 37 mbar 536 g/h Electric supply: 220-240 V ~ 50-60 Hz Appliance category: II2H3+ Gas connection: R 1/2"... - Page 20 867345783-D-052024...
