TF-6225

Motion Control

Mainboard Instruction

Laser Motion Control

RV 1.0

2018.05

www.sztrocen.com

Table of Contents

Need help?

Do you have a question about the TF-6225 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trocen TF-6225

Page 2 Trocen is not liable for any loss or liability arising directly, indirectly, specifically, incidental or consequential due to the use of this manual or this product.
Page 3 TF-6225 Motion Control User Manual Contact Us Shenzhen Trocen Automation Tech. Co. Ltd. 409-411, 4F, Bldg B, Huameiju Business Center, Xinhu Rd., Bao’an District, Shenzhen, Guangdong Province, China Phone: +86 13502563268 (Coco) Tech Support: +86 136 9228 6280 (Tiger. Chan) Email: coco@sztrocen.com...
Page 4 TF-6225 Motion Control User Manual Version Ver. No. Revision Date V1.0 2018/05/17 WWW.SZTROCEN.COM...
Page 5 Address: 409-411, 4F, Bldg B, Huameiju Business Center, Xinhu Rd., Bao’an District, Shenzhen, Guangdong Province, China Code: 518100 User Manual The users will understand the basic composition, installation and use of TF-6225 by reading this instruction. For Who This manual is applicable to engineers who have a certain understanding of laser mechanical automation and electrical circuits.
Page 6: Table Of Contents
TF-6225 Motion Control User Manual Content 1. Overview ........................6 1.1 Terms and Explanation ..................6 1.2 Introduction ..................... 6 2. LaserCAD Installation ....................7 3. Hardware Installation ....................7 3.1 Hardware Part ....................7 3.1.1 Wire ...................... 7 3.1.2 Mainboard .................... 9 3.1.2.1 Appearance ................
Page 7: Overview
Includes: panel, motherboard, wire and so on. 1.2 Introduction TF-6225 motion controller is a motion control system developed by Shenzhen Trocen Automation Tech co., LTD for 5 years. This system is used by LaserCAD software and wiring board motion controller, which greatly improves the production efficiency and reduces the production cost.
Page 8: Lasercad Installation
You can go through 《LaserCAD User Manual》 for more details about installation and how-to-use LaserCAD. 3. Hardware Installation Users will get further to know hardware parts of TF-6225 and how they are connected. At the same time, you can also learn something about common related peripheral component and electrical connection.
Page 9 TF-6225 Motion Control User Manual CN1&CN2 as one set to connect wiring CN Cable board and panel. 8PIN Patch cord with USB and network port. 15cm Connect amplifier. Copper Cable Amplifier Cable Connect amplifier and main board. WWW.SZTROCEN.COM...
Page 10: Mainboard
TF-6225 Motion Control User Manual 3.1.2 Mainboard 3.1.2.1 Appearance Figure3-1 Mainboard Appearance WWW.SZTROCEN.COM...
Page 11: Size Of Mainboard
TF-6225 Motion Control User Manual 3.1.2.2 Size of Mainboard Figure3-2 Size of Main board 3.1.3 Wiring Board The panel and other parts of machine are connected by wiring board. The components as below: ⚫Connect motor driver ⚫Detection of motion axis limit signal ⚫Input signal detection...
Page 12: Wiring Board Appearance
TF-6225 Motion Control User Manual 3.1.3.1 Wiring Board Appearance Figure3-3 Wiring Board Appearance WWW.SZTROCEN.COM...
Page 13: Main Board Interface
TF-6225 Motion Control User Manual 3.1.3.2 Main Board Interface Figure3-4 Main Board Interface WWW.SZTROCEN.COM...
Page 14: Electric Connect
TF-6225 Motion Control User Manual 3.2 Electric Connect 3.2.1 Integral Wiring Diagram Figure3-5 Integral Wiring Diagram 3.2.2 Unit Port and Wiring Diagram on Wiring Board 3.2.2.1 Power Supply Port on Wiring Board The power supply for wiring board and panel. Please pay more attention to polarity when you are connecting them.
Page 15: Connection Port Of Main And Wiring Board
TF-6225 Motion Control User Manual 3.2.2.2 Connection Port of Main and Wiring Board Connect mainboard and wiring board with CN cables. Table3-3 Connection Instruction Name Explanation Connect CN1 to mainboard Connect CN2 to mainboard 3.2.2.3 Signal Input Port on Wiring Board There are two ports for signal input.
Page 16: Signal Output Port On Wiring Board
TF-6225 Motion Control User Manual Wiring diagram for signal input: Figure3-6 Wiring Diagram for Signal Input 3.2.2.4 Signal Output Port on Wiring Board There are two output ports for power supply outside and signal control. Table3-5 Signal Output Port Instruction...
Page 17: Laser Power Supply Port On Wiring Board
TF-6225 Motion Control User Manual Working，output is high logic level; Free，output is low logic level. OUT5 Output signal (reserved). OUT6 Output signal (reserved). Power ground (OUT). OUT7 Stuffing signal. OUT8 Feeding signal. OUT9 Output signal (reserved). OUT10 Output signal (reserved).
Page 18: Motor Drive Control Port On Wiring Board
TF-6225 Motion Control User Manual Table3-6 Laser Controller Output Instruction Name Instruction Power ground (OUT). Laser switch signal, 24V high level light TTL+(24V) output. Laser Laser switch signal, 24V low level light TTL-(24V) output. PWM(24V) Laser power, 24V power signal.
Page 19: Input Port Of Limit Signal On Wiring Board
TF-6225 Motion Control User Manual DC5V Power (OUT) Y1/Y2 Pulse signal Direction signal DC5V Power (OUT) Pulse signal (Lifting shaft) Direction signal DC5V Power (OUT) Pulse signal Direction signal Figure3-8 Diagram of Interface and Driver Connection Y1 and Y2 are Y axis and they have the same signal. Y1 and Y2 can be used to connect to the machine with two Y-axis drivers.
Page 20 TF-6225 Motion Control User Manual to a minimum at the coordinate (zero position) limit sensor signal input signal. The lower limit of the Y-axis, the axis movement ELY- to a minimum at the coordinate (zero position) limit sensor signal input signal The upper limit of X-axis.
Page 21: Fqa
TF-6225 Motion Control User Manual Figure3-9 Wiring Diagram 4. FQA WWW.SZTROCEN.COM...
