Summary of Contents for Flo Ultra
- Page 1 FLO Ultra™ Lifting Jig Installation and Operation Guide ...
-
Page 2: Table Of Contents
3.2. Forklift Operations 3.3. Unloading the Crate from the Truck 4. Lifting 4.1. Center of Gravity 4.2. Forklift Lifting 4.2.1. Installing the Lifting Jig on the FLO Ultra 4.2.2. Lifting the FLO Ultra with a Forklift 5. Copyright and Liability... -
Page 3: Important Safety Instructions
3. FLO cannot be held responsible for any damage that may occur resulting from custom installations not described in this document. 4. If for any reason it is not possible to install the FLO Ultra lifting jig according to the procedures provided in this guide, the installer should contact the FLO team. -
Page 4: Introduction
2. Introduction 2.1. About the Lifting Guide The FLO Ultra™ Lifting Guide is a concise guide to lifting the FLO Ultra extracted from the FLO Ultra™ Installation Guide . This guide covers all of the information necessary for installing the lifting jig and safely lifting the FLO Ultra charging station. -
Page 5: Unloading The Crate From The Truck
Dimensions: 132 x 48 x 90 inches (335 x 122 x 229 cm) Lifting modes: The FLO Ultra must be picked up by the forklift from one of the two long sides. NOTE: Forklift extensions are required to handle the crate from the long side. -
Page 7: Lifting
4. Lifting FLO offers an optional lifting jig for forklift to assist with the handling. 4.1. Center of Gravity The images below show the FLO Ultra's center of gravity. -
Page 8: Forklift Lifting
"Unloading the Crate from the Truck" on page 5 for more information. NOTE: The lifting jig (ASME0586) is optional and sold separately from the FLO Ultra charging station. Please refer to the FLO Ultra Ordering Guide available at flo.com. Follow the instructions below to correctly lift a FLO Ultra with a forklift: ... - Page 9 1. Place the forklift lifting jig horizontal bars on top of the FLO Ultra, aligning the extrusions at the bottom with the indentations on top of the FLO Ultra. 2. Place the angle lift lifting jigs on top of the forklift lifting bars in a perpendicular arrangement, aligning the screw holes of the angle lifting jigs and the lifting bars.
- Page 10 3. Place the washer on top of the angle lift lifting jig screw hole and screw in the head screw. On the bottom of the angle lift lifting jig, add an oversized washer and a bolt to the head screw to secure the parts together. The torque must be 70 N m (51.6 lb-pi).
-
Page 11: Lifting The Flo Ultra With A Forklift
3. Confirm the lifting capacity of the forklift to make sure it can safely lift the weight of the FLO Ultra. Only use a forklift that can safely lift the FLO Ultra. The lifting capicity of the forklift must be over 700 kg (1 540 lbs) to lift the charging station and the lifting jig. - Page 12 6. Ensure the good positioning of the forks between the forklift lifting jig and the FLO Ultra (identified by each of the arrows of B). Do a visual check to ensure the right positioning of the forks and that the path of the forklift is clear.
-
Page 13: Copyright And Liability
CA_EN Document ID: PRFM0166 FLO CA: © 2024 Services FLO Inc., All rights reserved. FLO, the FLO logo, LEAD THE WAY, and TRACEZ LA VOIE are trademarks of Services FLO Inc. ADDÉNERGIE is a trademark of AddÉnergie Technologies Inc. used under license by Services FLO Inc. - Page 14 Eastern office: 2800, Louis-Lumière Street, office 100, Québec (QC) G1P 0A4 CANADA Regional office – Western Canada: #501 – 4190 Lougheed Highway Burnaby (British Columbia), Canada, V5C 6A8 United-States Office: 1270 Pacific Dr, Auburn Hills, MI, United States – 48326...
