- Page 1 MANUAL Quench USA Inc. 630 Allendale Road, Ste 200 King of Prussia, PA 19406 (855) 558-9796 www.Quenchwater.com...
- Page 2 XL1 MANUAL Congratulations on your choice of the PWT XL1 Water Dispenser. The XL1 model dispenses hot, cold, and ambient water. The PWT XL1 Water Dispenser provides exceptional quality and great tasting water with every use. INTRODUCTION Carefully read and follow all instructions to ensure proper and efficient operation of your PWT XL1 Water Dispenser.
-
Page 3: Table Of Contents
Resetting Hot Tank Overload Thermostat ......30 MAINTENANCE Preventative Maintenance ............ 31 System Inspection ..............32 Warranty Procedure .............. 32 TROUBLESHOOTING Advanced Settings ..............33 Troubleshooting Guide ............35 XL1 Manual Page 3 - Revision: 01-20-2025... -
Page 4: Safety Alert Symbols
WARNING! TIP HAZARD. Dispenser could tip or fall causing serious injury if installed with a base. Always install unit on a firm, flat, and level surface and secure unit to cabinet, wall, or XL1 Manual Page 4 - Revision: 01-20-2025... - Page 5 DO NOT PLACE HEAVY ITEM OR WATER CONTAINER ON TOP OF UNIT. Water may leak into the electrical system causing a fire hazard. Heavy items may fall off causing injury. Contact PWT for assistance or help finding an Authorized Service Representative. XL1 Manual Page 5 - Revision: 01-20-2025...
-
Page 6: Features And Benefits
Large Dispense Area 14.7-inch dispense height with recessed faucet to protect from cross-contamination. Leak Prevention XL1 Water Dispensers are supplied with a leak stop device to cut off the water supply in the case of a water leak or overfill. Touch-Capacitive Dispensing A Touch Capacitive Screen is used to activate select and dispensing functions as well as operate the technician menus. - Page 7 XL1 Water Dispensers have been tested and certified to rigorous NSF and UL Standards. We believe that performance testing and certifications validate PWT as a world-leader in Water Dispensers. PWT XL1 Component Certifications Include: UL399 – Certified Drinking Water Cooler Intertek Labs (ETL) Certified the XL1 Water Dispenser to ANSI/UL 399 Standard for Drinking Water Coolers.
-
Page 8: Model Designations, Consumables, & General Specs
MODEL - BRAND NAME DESCRIPTION PART NUMBER XL1 – Hot, Cold, Ambient WSXL1FR00E(XXXXXX) CONSUMABLES FILTER REPLACEMENT FREQUENCY PART NUMBER SEDIMENT FILTER 24 MONTHS (20,000 gal) H17-SD3 PRE-CARBON FILTER 24 MONTHS (20,000 gal) H17-ECS3 RO MEMBRANE (x2) 36 MONTHS XL12-WRO1280 POST-CARBON FILTER... - Page 9 ITEM 480mm W x 518mm D x 1740mm H Width/Depth/Height 18.9”W x 20.4”D x 68.5”H Weight (dry) 155lbs (70.3 kg) 68.5” 20.4” 18.9” XL1 Manual Page 9 - Revision: 01-20-2025...
-
Page 10: Receiving Your Equipment
(877) 386-0823 to report the damage. Photograph all damages to be submitted with the claim. THIS MUST BE DONE WITHIN FIVE BUSINESS DAYS OF DELIVERY. If not reported within 3 business days, PWT and/or carrier will not be responsible for replacement or repair. XL1 Manual Page 10 - Revision: 01-20-2025... -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS The below pictures show the front user interface (UI) and ADA control panel for the XL1 Water Dispenser. To Select Temperature: On the main screen, touch one of the three temperature selections to designate the temperature of water dispensed. -
Page 12: Warranty
PWT MANUFACTURED WATER DISPENSER LIMITED WARRANTY The PWT XL1 is covered by the PWT Warranty for a period of 1 year from the date of purchase against manufacturer defects given the filtration is changed with branded filters on the recommended schedule. -
Page 13: Service Requirements
4. Clean and sanitize external surfaces of the XL1 Water Dispenser. Use soap and water or chemicals that are compatible with ABS plastic and will not damage or degrade the product surfaces. -
Page 14: Parts List
XL1 PARTS LIST Note: Only stocked parts are listed. Description Part # Drip Tray Assy (Grill + Tray) AB156A01 Lower Front Panel Assy AB155A01 Description Part # ASSY Upper Front Panel Assy AB154A01 Description Part # LCD Touch PCB EB164A01... - Page 15 3-Way Dispense SV EC033A01 Hot Tank TB023A01 Top Lid PA034A01 Caster IJ003A01 Rear Panel IB210A01 Cold Water Pump EE023A01 XL1 Booster Pump EE012A01 Side Panel - Right IB205A01 Not Shown TDS Sensor EJ033A01 XL1 Manual Page 15 - Revision: 01-20-2025...
-
Page 16: Flow Diagram
XL1 WATER FLOW DIAGRAM XL1 Manual Page 16 - Revision: 01-20-2025... -
Page 17: Construction
XL1 CONSTRUCTION SMPS RASPBERRY PI PCB LCD TOUCH PCB MAIN PCB AMBIENT TANK DISPENSE S/V BANK HOT TANK DISPENSE LED PCB UV LIGHT CAP OVERLOAD THERMOSTAT COLD TANK TOUCH PCB ANCILLARY POWER OUTLET INLET S/V SEDIMENT + CARBON FILTRATION COLD DRAIN PORT... -
Page 18: Pre-Installation Procedures
Only qualified personnel who have read and understand this entire manual should attempt to install, or service this XL1 Water Dispenser, failure to do so could result in death or serious injury. DO NOT plug into an electrical supply until specifically instructed. -
Page 19: Notes On Installation
*If either are blocked, the water will not flow smoothly to and from the unit, and may cause performance degradation. 8. Do not place any heating system near the rear of the unit. 9. The power supply, source water, and drain must be directly connected to the unit. XL1 Manual Page 19 - Revision: 01-20-2025... -
Page 20: Unpacking The Unit
SECOND person help, by keeping a foot on the front of the pad and assist while another person rolls the unit off the pad from the back. The pad can try to follow the unit otherwise. XL1 Manual Page 20 - Revision: 01-20-2025... -
Page 21: Filter Flushing Procedure
XL1 FILTER FLUSHING PROCEDURE It is important to flush all filters inside the XL1 unit prior to installation. This will flush any carbon fines and preservative from the filters and extend the life of the filters as well reduce the potential of blockages and improve the quality of the water. - Page 22 Mineral+ filter. Turn the water OFF and return the last Mineral+ filter to its original head and restore the original plumbing of the out port of the left-most filter head. To Drain XL1 Manual Page 22 - Revision: 01-20-2025...
- Page 23 9. Allow the unit to fill. Turn the Supply Valve ON, and allow the system to begin processing tap water through the RO system and fill the tanks. This can take up to an hour (depending on supply flow). XL1 Manual Page 23 - Revision: 01-20-2025...
-
Page 24: Sanitizing
XL1 SANITIZING PROCEDURE Before the final steps of installation, it is recommended to SANITIZE the water path of the unit upon installation, and regularly through its service life. The steps below outline how to sanitize a unit that has previously been installed and connected to water and power. - Page 25 Remove the section of tubing used for draining. The unit will not begin cooling and heating until after commissioning and it has completely filled. The unit is now ready for final installation steps. XL1 Manual Page 25 - Revision: 01-20-2025...
-
Page 26: Installation
XL1 INSTALLATION It is very important to follow all instructions listed. Failure to do so may cause the system to not operate properly and may impact the long-term reliability of the system. Always check local plumbing codes before tapping into water supply line and drain line. Tap into the water source with an approved connector. - Page 27 Note: The XL1 WILL NOT chill or heat water until the water in the ambient tank has reached the float valve, meaning all tanks have filled to capacity. This can take up to 1 hour depending on supply flow and pressure.
-
Page 28: Commissioning
1. Input the branding code. Once the unit is powered on and the front screen comes online, the unit will give a prompt for a branding code. The branding code for the PWT XL1 is as follows: PWT123. Input this 6-digit code into the prompt, then hit “Confirm”. A welcome message will appear, press “Continue”, and then the main UI screen will come up and the... -
Page 29: Final Inspection
Leaving water in the hot tank will allow you to turn the hot tank on immediately after installation of the system but if left overnight may result in a taste complaint. NEVER lay the system on its side. XL1 Manual Page 29 - Revision: 01-20-2025... -
Page 30: Resetting Hot Tank Overload Thermostat
Continue with resetting the thermostat, then connect the unit to power again. Water will begin heating, and hot water should be available within 5-10 minutes. OVERLOAD RESET XL1 Manual Page 30 - Revision: 01-20-2025... -
Page 31: Preventative Maintenance
4. Check solenoids for proper function. Dripping solenoids should be replaced immediately. Every 5 years, in addition to the above, perform the following: Replace all internal fittings and tubing. Replace solenoids. XL1 Manual Page 31 - Revision: 01-20-2025... -
Page 32: System Inspection
Temperature Check (Cold water should be below 50˚F, Hot water should be above 160˚F) TDS Check Site Cleanup WARRANTY PROCEDURE Procedure for XL1 warranty evaluation: Contact PWT technical support and provide the following information: Serial number Failure Full details around failure... -
Page 33: Advanced Settings
XL1 ADVANCED SETTINGS The XL1 unit has an Admin Menu that can be accessed with a 6-digit numeric code. Many detailed options and settings can be controlled from the Admin Menu. Below is an outline of how to access the menu, and what all of the settings and options control. - Page 34 Factory Reset Button Shows Filter Type and which Shows Filter max life in gallons and filters have been installed. months, and remaining Filter life %. Filter Alerts can be toggled for individual filters. XL1 Manual Page 34 - Revision: 01-20-2025...
-
Page 35: Troubleshooting Index
Ensure the power cable is properly plugged into the wall power Power Cord Disconnected outlet. Tripped GFCI Reset GFCI outlet. Screen Connection Error Check the connection of the main ribbon cable to the UI screen. XL1 Manual Page 35 - Revision: 01-20-2025... - Page 36 “stick” open and become very hot to the touch. Replace in either case. 5. Cold Water not cold Possible Reason Solution If compressor will not engage, or is too hot to touch, contact Compressor Issue Technical Support. XL1 Manual Page 36 - Revision: 01-20-2025...
