- Page 1 Laveo DF1045 Portable Toilet User’s Manual Patented CAGE CODE: 6NNM4 Waterless Toilets, Inc. 14 Indian Neck Avenue Branford, CT 06405 (203) 248-4440 sales@dry-flush.com www.dryflush.com Please visit the “Owner Tips & Tricks” section on our website for helpful YouTube videos and more! Rev 8/22/23...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Precautions… ..................2 Setup… .................... 3 Getting your Laveo ready for use… ..........7 Electrical Connections… ..............8 Installing the Refill… ..............10 Removing the Waste and Empty Cartridge… ....... 11 How to Use your Laveo… ............12 Trouble Shooting Guide…... -
Page 3: Precautions
NEVER use the Laveo for any use other than that for which it was designed. • Use the Quick Floor Mount Kit by Dry Flush if you are going to install your Laveo in a moving craft or vehicle. •... -
Page 4: Setup
SETUP Before you begin using your new Laveo, let’s take a moment to review some of the parts that make it work. You can come back to these pictures during set-up, or in the unlikely chance that you will have to call for technical support. Pictured here are the various parts found on the front side of the Laveo. - Page 5 DO NOT remove the panel unless instructed to do so by a Dry Flush Customer Support. On the outside of the panel is where you can find the Product Label. This label also has the serial number of your Laveo printed...
- Page 6 Refill Cartridge and the lip of the Toilet Base. Should this gasket become damaged it should be replaced. Contact Dry Flush if you need to replace your Foam Gasket. The Octagon Container supplies rigid support to the liner and bagging material while waste is being stored within the Laveo.
- Page 7 To the right is the view of the inside of the Laveo. This view shows the floor panel located below the Octagon Container. The Square Key is connected to the shaft of the gear box (not shown), and is the part responsible for turning the Octagon Container during the flush cycle.
-
Page 8: Getting Your Laveo Ready For Use
Getting your Laveo ready for use Your Laveo Portable Toilet comes fully equipped and almost completely ready to use out of the box, but due to shipping regulations and the shipping environment, we ask that you please perform the following: 1. -
Page 9: Electrical Connections
ELECTRICAL CONNECTIONS The picture to the right shows a close-up of the Battery Compartment. We have already discussed the parts that make up this section on Page 4, but now we will discuss how to use these components. The Power Inlet is where the Laveo receives power from the Battery, or from our optional AC Power Adapter. - Page 10 Replacement fuses can be purchased at most big box stores, Dry Flush, or auto parts shops. It’s generally best to bring the old fuse with you to ensure you buy the correct replacement. WARNING: Never replace any fuse with a fuse that is rated higher than the fuse you are replacing.
-
Page 11: Installing The Refill
INSTALLING THE REFILL 1. Raise the toilet seat and lift off the white trim top piece. 2. Remove the Octagon Container from the Laveo. Place the black disposal liner into the Octagon Container, and roll the top down around the rim as you would a trash can liner. -
Page 12: Removing The Waste And Empty Cartridge
REMOVING WASTE AND EMPTY REFILL 1. Lift the toilet seat and remove the underlying white Trim Top piece. 2. Please help us to recycle! Lift up the plastic cartridge rim and pull or cut the bag away from the bottom of the plastic rim so that the silver mylar bag is released easily into the black garbage bag below. -
Page 13: How To Use Your Laveo
HOW TO USE YOUR LAVEO In most respects your Laveo works like an ordinary porcelain toilet. After use, press the Flush Button. Your Laveo will turn on and run through a 16 second cycle that will close the Bagging Material around the waste, by twisting and compacting the waste, finally creating a new “bowl”... -
Page 14: Trouble Shooting Guide
TROUBLESHOOTING PROBLEM SOLUTION Toilet does not flush - no power Ensure that your Battery is fully charged. (Page 8) Ensure that the Power Cable is securely plugged into the Power Inlet. (Page 8) Remove the Battery and check to ensure the Battery Cable connections are connected securely. -
Page 15: Specifications
SPECIFICATIONS Electrical: 12 vdc 5amp during flush, 0.5 u-amp idle. Power Inlet 5.5mm OD, 2.1mm ID, 12mm Length Dimensions: 18.25” (464 mm) high 16” (407 mm) wide 20” (508 mm) deep Weight: 23.25 lbs. (10.57 kg) 29.00 lbs. (13.18 kg) with battery www.dry-flush.com...
