QuadBoss QBRC14544CP Owner's Manual

Commercial pro 44” country cut trail cutter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S
MANUAL
MODEL NO.
STARTING SERIAL #:
L118-001001
QBRC14544CP
QBRC14544CP-CA
IMPORTANT
IMPORTANT
Read and follow all
Read and follow all
Safety Precautions
Safety Precautions
and Instructions
and Instructions
before operating this
before operating this
equipment.
equipment.
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
20949 REV 18-001
COMMERCIAL PRO
44" COUNTRY CUT
TRAIL CUTTER
Assembly
Operation
Service and Adjustment
Repair Parts
SWISHER ACQUISITION INC.
PHONE (660) 747-8183 FAX (660) 747-8650
ade I The
USA
of US and Global Parts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QBRC14544CP and is the answer not in the manual?

Questions and answers

Related Manuals for QuadBoss QBRC14544CP

Summary of Contents for QuadBoss QBRC14544CP

  • Page 1 OWNER’S MANUAL MODEL NO. STARTING SERIAL #: L118-001001 QBRC14544CP QBRC14544CP-CA COMMERCIAL PRO 44” COUNTRY CUT TRAIL CUTTER Assembly IMPORTANT IMPORTANT Operation Read and follow all Read and follow all Safety Precautions Safety Precautions Service and Adjustment and Instructions and Instructions...

  • Page 2: Limited Warranty

    LIMITED WARRANTY The manufacturer’s warranty to the original consumer purchaser is: This product is free from defects in materials and workmanship for the period's shown below beginning from the date of purchase by the original consumer purchaser. We will repair or replace, at our discretion, parts found to be defective due to materials or workmanship.

  • Page 3: Safety Precautions

    Thank you for choosing Swisher’s 44” Trail Cutter. Before operating your cutter, please read, understand and follow all of the safety precautions and other instructions explained in this manual. As with all power equipment, lawn mowers and cutters can be potentially dangerous if improperly used.
  • Page 4 • Turn off the blades when not cutting. Before leaving the machine, turn off the blades and stop the engine. • Watch for traffic when operating near or crossing roadways. • Do not operate the cutter if it has been dropped or damaged in any manner or if the mower vibrates excessively.
  • Page 5 OPERATING YOUR TRAIL CUTTER The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine. The operation of any mower produces sound waves that are damaging to the human ear.
  • Page 6 ENGAGING BLADES Note: Do not attempt to start the unit with the PTO switch in the “ENGAGED” position. • Engage blades by pulling out on the PTO switch. • Push PTO switch in to disengage blades. See detail on page 17 figure – 10 •...
  • Page 7 CUTTER HEIGHT ADJUSTMENT • There is approximately 4” of height adjustment. • Rotate height adjust crank handle in a clockwise direction to lower the mower deck. Rotate counterclockwise to lift the mower deck. • Dense areas should be cut twice. •...

  • Page 8: Cutter Maintenance

    • Reducing the travel speed will help cut dense growth. This allows the blades the time necessary to make its initial cut, and regain momentum to continue cutting. The engine may stall if you are mowing too fast! • Do not attempt to cut areas that the tow vehicle cannot maneuver through and/or slopes that you do not feel comfortable riding.

  • Page 9: General Troubleshooting

    GENERAL TROUBLESHOOTING The unit is not cutting level. • Level deck. Check air pressure of all tires; make sure they are equal. See tires for maximum inflation. • Without the engine running, make certain blades are installed identically. The engine will not start. •...

  • Page 10: Safety And Operational Decals

    SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. Order by part number from Swisher. 1-800-222-8183, 8-5 CT M-F 19976-SWISHER FLAG DECAL OD33-5MPH DECAL OD29-DANGER DECAL OD36-DEFLECTOR DECAL OD55-DANGER DECAL OD10-ENGAGE DECAL OD45-WARNING DECAL OD28-OFF/RUN/START DECAL...
  • Page 11 UNCRATING & SET-UP DIAGRAM Description Part # Weldment - Hitch Mount; RC44 21114* 3/8-16 Nyloc Nut NB182 3/4-10 Nyloc Nut 21132 3/4" Sae Flat Washer NB146 5/8-11 Nyloc Nut 21138 Pin - Clevis 3/8 X 3 ZP 21131 Bolt - Hex, 5/8-11 X 2 1/2" NB667 Top Link - Cat 0 W/ Adjusting Rod 21103...

  • Page 12: Hitch Assembly

    FRONT SKIRT ASSEMBLY Item # Description Part # Nut - Serr Flange, 1/4-20 Grade 5 ZY NB524 Rubber Flapper 10384 Washer - Fender, 1/4X1 1/4OD Gr 2 ZY 11520 Bolt - Serr Flange, 1/4-20 X 3/4 GR5 ZY NB690 Nut - Serr Flange, 1/4-20 Grade 5 ZY NB180 Plate - Harness, Mount 20910*...
  • Page 13 MOTOR BASE, WHEEL & HEIGHT ADJUSTMENT ASSEMBLIES FIGURE 5 Item # Description Part # Item # Description Part # Motor Base 20908* Nut - 5/16-18 Serrated Flange NB170 Cover - Rear, RC14544CPKA 20941* Nut, Push - 5/16 NB117 Belt - B X 55" 20937 Knob Height Adjustment 1/2-13 Nyloc Nut...

  • Page 14: Deck Assembly

    DECK ASSEMBLY Item # Description Part # FIGURE 6 Deck - Weldment 15727* Screw - .312-18 x .75 26X249 Side Gusset - Left 15056* Nut - 5/16-18 Serrated Flange NB170 Side Gusset - Right 15057* Z Bracket, Jack Support 15055* Front Rail/Deck Support 15054* Rail - RT44, Right...
  • Page 15 BLADE DRIVER ASSEMBLY FIGURE 7 Item # Description Part # Nut - Nyloc 1"-8 NB612 Washer - 1" X 2" X 14GA NB738 Pulley - Blade, 12" 20920 Spacer - Pulley 19822 Bearing - Blade 4845 Shaft - Blade 18844 NB281 Nut - Nyloc 1/2"-13 Washer - USS Flat, 1/2"...
  • Page 16 ENGINE PULLEY/BELT ASSEMBLY FIGURE 8 Item # Description Part # Engine (Reference Model Shown) Spacer - 1.25OD X 1.032 ID X .90 Txt Blk 20572* Washer - Split Lock, 3/8 ZY, Medium NB711 Bolt - 3/8-16 X 1 1/4 GR5 ZY NB618 Nut - Nyloc 5/16-18 ZY NB181...

  • Page 17: Console Assembly

    CONSOLE ASSEMBLY FIGURE 10 Item No. Description Part # THROTTLE KNOB 686K PTO SWITCH 3605 KEY SWITCH 3623 PLASTIC CONSOLE COVER 686C mod 8-32 X KEP NUT NB201 1/4'' SAE WASHER NB274 8-32 X 1/2'' PHIL TRUSS NB197 CONSOLE PLATE WELDMENT 6108TK THROTTLE CABLE 20915...

  • Page 18: Repair Parts

    REPAIR PARTS Your 44’’ Trailcutter has been produced with components designed specific to this machine. Although standard V- belts, springs, bearings, blades, pulleys, hardware, etc. look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials. Mowers equipped with a 14.5HP engine have a separate 2.5 gallon fuel tank.
  • Page 19 BATTERY HOLDER CONFIGURATION Mower require a U1 battery (not included). Lid Opened Position Lid Closed Position FIGURE 14 Note: Use Thumbscrew [item #3] to hold lid in the open position as shown in illustration above. Item # Description Part # Guard - Battery Box Lid 21211* Bolt - Flange 5/16-18...
  • Page 20 RECOMMENDED HITCH CONFIGURATIONS AND POSITIONS FIGURE 16 FIGURE 17 FIGURE 18 FIGURE 19 FIGURE 20 Unlocked Locked...
  • Page 22 MODEL NO. All engine parts may be ordered from the nearest dealer of the engine supplied with your mower WHEN ORDERING PARTS, PLEASE HAVE THE QBRC14544CP FOLLOWING INFORMATION AVAILABLE: QBRC14544CP-CA * PRODUCT – RC44’’ COUNTRY CUT TRAIL CUTTER * SERIAL NUMBER - _______________...
