Summary of Contents for Fredette AR-S04
- Page 1 AR-S04...
- Page 2 Product Introduction ▶ The electric mini double-brush scrubber is a new generation of sanitation and cleaning appliances launched by our company. This machine is exquisite in design and unique in technology. This machine can complete the two tasks of washing the floor and drying the sewage in one step. It is suitable for civil and industrial flat ground or moderately rough ground.
- Page 3 Warning Please strictly abide by this manual (especially the important information involving danger or warning) and accompanying safety instructions. The manufacturer will not be responsible for any serious consequences caused by not following these instructions. ● The machine can only be operated by trained and competent staff. ●...
-
Page 4: Install Battery
Install battery When installing or maintaining the battery, the operator must wear necessary protective devices (gloves, goggles, etc.) to reduce the risk of accidents. Keep away from open flames, avoid short circuits between electrodes, avoid electric sparks, and do not smoke. Install the battery on the machine (follow the steps below): ●... - Page 5 Operation Guide Power display switch button diagram: the remaining power can be displayed in the working state. Operation panel diagram: Brush plate motor button: Run the ground brush motor, stop the ground brush motor. Water switch button: The water switch can be switched on and off according to the ground material to scrub the ground.
- Page 6 Clean water tank: The water tank located on the rear side of the machine is a clean water tank, with a solvent volume of 4.5L. You can remove the clean water tank by pulling it from the outside. As shown in the picture above, remove the clean water and open the blue cover to add clean water.
- Page 7 Installation and adjustment of the squeegee: The squeegee is the first process to dry the ground. The squeegee has been installed on the machine before leaving the factory, and there is no need for installation and adjustment; ·Pay attention to whether the suction pipe is correctly inserted into the protruding part of the middle ring of the squeegee.
-
Page 8: Daily Maintenance
Pull out the suction hose from the squeegee; Loosen the 8 knobs on the inside of the squeegee, and remove the squeegee pressure plate from the squeegee mounting bracket; Loosen the lock of the squeegee rubber strip; ·Pull out the rubber strip pressure strip to the outside of the water-absorbing grill frame, and remove the water-absorbing rubber strip;...
