Summary of Contents for CleanFreak ACF4-4000
- Page 1 Operators Manual ACF4-4000 CFH-3530G Do not use or operate machine until this manual has been read and fully understood...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION & IMPORTANT SAFETY INFORMATION..... S SETUP....................1-0 INSPECTION and IDENTIFICATION........1-2 LOCATION................1-2 MACHINE SETUP..............1-3 INITIAL MACHINE STARTUP..........1-6 OPERATING INSTRUCTIONS............2-0 OPERATING INSTRUCTIONS..........2-1 PRESSURE CLEANING TIPS..........2-4 SHUTTING DOWN AFTER USE..........2-5 SPECIFICATIONS................3-0 MAINTENANCE................ -
Page 4: Introduction & Important Safety Information
INTRODUCTION & IMPORTANT SAFETY INFORMATION Thank you for purchasing this hot water pressure 3. Stay alert - watch what you are doing. washer. We reserve the right to make changes to the 4. Do not add fuel while the pressure washer is pressure washer at any time, without incurring any running. - Page 5 IMPORTANT SAFETY INFORMATION WARNING WARNING: High pressure spray 11. Be certain all quick coupler fittings are secured can cause paint chips or other before using this pressure washer. particles to become airborne and WARNING fly at high speeds. To avoid WARNING: The high pressure personal injury, eye, hand, developed by this pressure...
- Page 6 S - 3 IMPORTANT SAFETY INFORMATION WARNING WARNING: Be extremely careful CHEMICAL WARNING: when using a ladder, Chemicals used for cleaning are scaffolding, or any other dangerous! Keep all chemicals out of the relatively unstable location. The reach of children and untrained adults. Proper safety precautions must be taken before han- cleaning area should have RISK OF INJURY FROM...
- Page 7 IMPORTANT SAFETY INFORMATION • Never leave the discharge hose lying on the floor or ground where it could be driven over by vehicles or damaged by falling objects. Always coil and hang the hose immediately after use. • If there is any doubt about the hose condition, replace the hose immediately.
-
Page 8: Instructions De Sécurité Importantes
INSTRUCTIONS DE SÉCURITÉ IMPORTANTES Merci d’avoir acheté ce nettoyeur haute pression à toutes les commandes. l’eau chaude. Nous nous réservons le droit de 3. Il convient d’être alerte et de bien faire attention à la modifier ce nettoyeur haute pression en tout temps et procédure. - Page 9 INSTRUCTIONS DE SÉCURITÉ IMPORTANTES WARNING 7. Veillez à ce qu’il n’y ait personne dans la zone de AVERTISSEMENT: Agrippez le nettoyage. tube de nettoyage à l’aide des deux mains avant de WARNING AVERTISSEMENT: La commencer. Sinon le tube de pulvérisation à haute pression nettoyage peut être source de TRIGGER GUN KICKS peut entraîner l’écaillement de la...
- Page 10 INSTRUCTIONS DE SÉCURITÉ IMPORTANTES 14. Évitez d’installer ce nettoyeur dans des 21. Ne laissez pas d’acides ou de fluides abrasifs ou endroits confinés ou près de ventilateurs. Une quantité caustiques pénétrer par la pompe. d’oxygène adéquate est nécessaire pour la 22.
- Page 11 INSTRUCTIONS DE SÉCURITÉ IMPORTANTES...
-
Page 12: Setup
SETUP INSPECTION and IDENTIFICATION LOCATION MACHINE SETUP INITIAL MACHINE STARTUP... -
Page 13: Inspection And Identification
SETUP INSPECTION and When locating the machine (whether it will be portable or stationary) it is important to position the machine for IDENTIFICATION easy access to all operating controls and an adequate water supply. Consideration must also be given to Machine Delivery Inspection adequate ventilation and for the best possible access Examine the shipping crate and machine carefully for... - Page 14 SETUP - OR - • If the machine is used inside an enclosed van-type vehicle, provisions must be made to vent all combus- tion exhaust outside the vehicle. All engine cooling air must be supplied by controlled means, such as dedi- cated vent openings, powered fans, or properly lo- cated vehicle doors.
- Page 15 SETUP 1- 4 IMPORTANT: Use ONLY regular gasoline (unleaded Providing the Proper Burner Fuel or leaded) in the gas tank. Do not add oil to the gaso- IMPORTANT: The burner heats the water and uses line. Do not use diesel fuel or burner oil. Do not overfill home heating oil, kerosene, or diesel fuel.
-
Page 16: Initial Machine Startup
SETUP INITIAL MACHINE STARTUP Control Panel and Monitor Light Operation After the machine has been properly set up, fueled, Depending on your machine model and optional and prepared for use, perform the following initial start equipment, the control panel may vary somewhat. up procedures before using the machine for cleaning. - Page 17 SETUP 8. Turn the key switch to the center position to shut down the engine and pump. Turn off the fuel valve. 9. Apply thread sealant (Loctite red) to the first few threads of the high pressure discharge hose. Connect the wash gun or wand securely to the discharge hose.
- Page 18 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS PRESSURE CLEANING TIPS SHUTTING DOWN AFTER USE...
-
Page 19: General Information
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS 6. Select and install a high-pressure quick-coupled tip on the wand. Turn the tip nozzle in the quick-coupler WARNING: Always wear full eye protection for the desired spray pattern (vertical or horizontal). (preferably a face shield), protective NOTE: Some machines are supplied with two or more clothing, rubber gloves, and boots when high-pressure spray tips. -
Page 20: Pressure Cleaning Tips
OPERATING INSTRUCTIONS PRESSURE CLEANING TIPS WARNING: DO NOT allow the burner to operate without igniting! If the burner fails to WARNING: On gun control models, to ignite, shut the machine down immediately minimize the possibility of machine and check for accumulation of oil or gas overloading or relief valve actuation, DO before proceeding. -
Page 21: Cleaning Tips
OPERATING INSTRUCTIONS Cleaning Tips The wash nozzle supplied with the machine will pro- vide optimum hot water cleaning for most universal- type cleaning requirements, if used properly. For the best results, the gun should always be used with long slow deliberate strokes, 6-12 inches away from the surface, in much the same manner as us- ing a paint sprayer. -
Page 22: Specifications
SPECIFICATIONS SPECIFICATIONS... - Page 23 SPECIFICATIONS SPECIFICATIONS Hot Water Pressure Cleaner MODEL CFH-3530G Flow Output (GPM) Pressure Ratings (PSI) 3000 Output Temperature 160° 105° Heat Rise Degrees Farenheit Cleaning Comparison Index (1) 18,107 Engine Vanguard Engine Horsepower Engine/Pump Drive Direct Engine Fuel Engine Fuel Capacity (U.S. Gal.) Engine Start Recoil Oil Fired Burner System...
-
Page 24: Maintenance
MAINTENANCE ROUTINE MAINTENANCE WINTERIZING AND STORAGE... -
Page 25: Maintenance And Service
MAINTENANCE & SERVICE A Properly Maintained Annually • Tune up the fuel burner (this should be done by a Machine is a Safe Machine qualified Service Technician, please consult your local AaLadin Distributor). It is the operator’s responsibility to make daily inspec- •... -
Page 26: Changing Pump Oil
MAINTENANCE & SERVICE Pump Lubrication Requirements Fill plug/dipstick The pump is pre-lubed from the factory. After the first 50 hours of operation, change the crankcase oil. Change oil every three months or 500 hours (whichever occurs first) thereafter. Use SAE 30W non-detergent motor oil. -
Page 27: Charging The Battery
MAINTENANCE & SERVICE WARNING: To prevent personal injury or electrical • Never pull on the hose to move the machine or place system damage, connect cables carefully and never undue stress on the hose. reverse polarity when connecting cables. Always wear •... -
Page 28: Cleaning Coils
MAINTENANCE & SERVICE HIGH PRESSURE GUN WINTERIZING AND STORAGE Trigger gun and wand assembly To protect the machine from severe damage resulting from water freezing inside the pump, heating coil, or other components, or from corrosion resulting from long periods of inactivity or storage, use the following proce- dure: To winterize and store your pressure washer: •... - Page 29 MAINTENANCE & SERVICE...
-
Page 30: Troubleshooting
TROUBLESHOOTING... - Page 31 TROUBLESHOOTING WARNING: Before attempting any repairs or maintenance, be sure the machine is shut off and disconnected from electrical supply. Troubleshooting is an organized study of the problem and a planned method or procedure for investigation and correction of the difficulty. The following troubleshooting guide includes some of the problems that you may encounter during the service life of the machine.
- Page 32 TROUBLESHOOTING OIL BURNER MALFUNCTION PROBLEM POSSIBLE CAUSE SOLUTION 1. Allow motor to cool. Push reset button 2. Check the power cord, circuit breaker, switched, internal 1. Overload protection tripped wiring, and wiring terminals. Re-establish power by replac- 2. No power reaching burner Burner motor does ing bad switch, etc.
- Page 33 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION 1. Partially clogged fuel nozzle 1. Clean or replace fuel nozzle 2. Significant scale deposits in 2. Conduct back pressure test to determine extent of heating coil scaling (see ROUTINE MAINTENANCE on page 4-2 in this Low temperature 3.
- Page 34 TROUBLESHOOTING DETERGENT SYSTEM MALFUNCTION PROBLEM POSSIBLE CAUSE SOLUTION 1. Suction tube not below liquid 1. Completely submerge suction tube and strainer in surface Washer fails to detergent solution 2. Clogged or damaged suction draw detergent 2. Clean or replace strainer strainer 3.
- Page 35 TROUBLESHOOTING...
-
Page 36: Legal Notices
LEGAL NOTICES... - Page 37 LEGAL NOTICES California Proposition 65 Warning WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov...
