Ecco M50 Maintenance Service Manual

*** RECHARGE EXTINGUISHERS IMMEDIATELY AFTER USE ***
All fire extinguishers should be installed as per AS-2444 and maintained in accordance with AS 1851 and the
requirements of all authorities that have jurisdiction in relation to fire extinguishers.
Maintenance should be performed by trained persons using proper equipment. Fire extinguishers are pressure vessels
and must be treated with respect and handled with care. They are mechanical devices and require periodic maintenance
to be sure that they are ready to operate properly and safely.
Extinguishers should be serviced only with original and genuine spare parts – the use of substitute parts constitutes the
void of any warranty covering the equipment.
PREPARING YOUR NEW EXTINGUISHER FOR USE
1. Examine the extinguisher for evidence of damage – Notify the supplier immediately if any damage is discovered.
2. Remove all wrappings and straps.
3. Check to ensure that the hose connection to the operating valve and nozzle are tight.
4. Check that the safety seal is intact.
5. Check that the gauge is showing pressure, and that the pressure is in the "Green" zone on the gauge. Note
slight pressure variances may be found if the extinguisher has been subjected to extremes of heat or cold. When
in doubt, condition the extinguisher to 22°C for several hours to obtain more accurate pressure readings.
INSTALLATION
DO NOT place extinguisher close to a potential fire hazard. We recommend locations no less than 15m distance from the
hazard while leaving an unobstructed access. Avoid placing the unit in an extremely hot or cold place. The extinguisher
should be adequately protected if extreme temperatures are expected in the location. Keep the extinguisher clean and
free from dirt, ice, chemicals, and any contaminants which may interfere with its proper operation.
OPERATION
Persons expected to use this extinguisher should be trained in initiating its operation
and the proper fire fighting technique.
1. Move extinguisher to within approximately 15 meters of the fire site.
Keep extinguisher upright. This extinguisher must be operated in the
upright position.
2. Pull Travel Pin.
alternate position. The hose is now pressurised with agent.
3. Remove the Nozzle from its holder, be careful to not squeeze the
trigger as this will discharge the agent.
4. Unroll the hose completely.
5. Stand back 10 meters fro the fire and aim the nozzle at the base of
the flames nearest you. Squeeze the trigger on the nozzle.
6. Sweep from side to side across the base of the fire and past both edges. Progressively follow up until fire is
extinguished. Work the fire away from you while being alert for any flashbacks.
7. When the fire is out, evacuate and ventilate the area immediately. The fumes and smoke from any fire may be
deadly.
Fire Extinguisher Maintenance Recharge and Service Manual – M100
MODEL M50 / M100 – Wheeled Fire Extinguisher
DO NOT functionally test the extinguisher.
Open cylinder discharge sliding the valve to the
WHEELED UNIT - FIRE EXTINGUISHER
Maintenance, Recharge & Service Manual
Rev 2.1
P a g e | 1
