Summary of Contents for Peimar PSI-X-DH1000

  • Page 1 PSI-X-DH1000 User manual...
  • Page 2 It should be noted that the technical data, information and representations contained in this document have a purely indicative value. Peimar reserves the right to modify the data, drawings and information contained in this document at any time and without notice.
  • Page 4: Table Of Contents

    Safety ....................6 Overview of PSI-X-DH1000 ............6 2.1. Introduction ....................6 Installation ...................8 3.1. Packing List ....................8 3.2. Device Installation ..................8 3.2.1. Indoor Wall Mounting ..............8 3.2.2. Guide Rail Mounting ..............9 Electrical Connection ...............10 4.1. Inverter Connection .................10 4.2. Installation of RS485 ................11 4.3.
  • Page 5 5.5. Inverter Upgrade ..................19 5.6. PSI-X-DH1000 Setting ................19 5.6.1. Internet Setting ................19 5.6.2. Time Setting ................20 5.6.3. Serial Port Settings ..............20 5.6.4. Other Setting ................20 5.6.5. Datahub Information ..............21 5.6.6. PSI-X-DH1000 Upgrade ............21 5.7. Password Modification ................21 5.8. System Resetting ..................21 6. Specifiche Tecniche ..............22...
  • Page 6: Safety

    Safety The PSI-X-DH1000 has been designed and tested strictly in accordance with relevant safety regulations. The safety instructions must be followed when installing and maintaining the electrical and electronic equipment. Improper operation will cause personal injury and property damage to the operator and the third party.
  • Page 7 Antenna Jack TF card socket (TF) RST button (RST) SIM card socket (SIM) USB socket (USB) TYPE-C socket LED indicator (RUN,SERVER,ALARM) Rail clip NET socket (NET) (10) RS485 socket (RS485) (11) CAN socket (CAN) (12) 12V power output (12V/GND) (13) DO socket (DO) (14) AI socket (AI)
  • Page 8: Installation

    NET Cable Cat 5e or higher standard network cable 3.2. Device Installation 3.2.1. Indoor Wall Mounting 1. Choose a flat and solid indoor wall to drill for installation; 2. Hang the PSI-X-DH1000 on the wall with the cable connection area facing down. NOTA BENE The outdoor installation must be in a waterproof housing.
  • Page 9: Guide Rail Mounting

    ( ) с ( ) d 3.2.2. Guide Rail Mounting 1. Use the four M3*L6 screws in the accessory bag to fix the buckle on the PSI-X- DH1000. 2. Please prepare 35mm standard rail (effective length ≥230mm) and install it firmly.
  • Page 10: Electrical Connection

    Electrical Connection 4.1. Inverter Connection 1. The inverter is connected to the PSI-X-DH1000 through the RS485. For the connection method of the inverter, please refer to the inverter installation manual; 2. It is recommended that the number of devices connected to each channel of RS485 is less than 20;...
  • Page 11: Installation Of Rs485

    4.2. Installation of RS485 Make sure that RS485+ is connected to PSI-X-DH1000’s RS485+, RS485- is connected to PSI-X-DH1000’s RS485-, RS485 GND is connected to the GND of PSI-X-DH1000. 8-10mm 8-10mm φ 2.5mm 0.4-0.5N·m Inverter RS485 Pocket Sign Illustrate RS485-1 RS485A,RS485Differential s ignal+ RS485-2 RS485B,RS485Differential s ignal-...
  • Page 12: Installation Of Di Signal Cable

    4.3. Installation of DI Signal Cable PSI-X-DH1000 can access DI signals such as remote control and alarms through the DI port. terminal 8-10mm DI1~DI4 Socket Mark Illustrate Support passive dry contact signal access...
  • Page 13: Installation Of Ai Signal Cable

    4.4. Installation of AI Signal Cable Installation advice: • It is recommended that the transmission distance does not exceed 10 m; • AI port 0 and AI port 1 are connected to AI signal +, and GND is connected to AI signal–. 8-10mm 8-10mm AI0~AI1 Socket Mark...
  • Page 14: Installation Of Do Signal Cable

    4.5. Installation of DO Signal Cable The DO port supports 30V signal voltage in maximum. The contact of four-group output is on by default. 8-10mm 8-10mm D01-D04 Socket Mark Illustrate Max. load 30V/2A...
  • Page 15: Installation Of Network Cable

    2. The communication distance does not exceed 100 m. 3. When crimping the network cable, ensure that the shielding layer of the network cable is properly connected to the metal shell of the RJ45 connector. 4.7. Connecting to Ripple Control Receiver Ripple Control PSI-X-DH1000 DI Port Receiver (RCR)
  • Page 16: Connecting To Dred

    4.8. Connecting to DRED 5. Configuration Function 5.1. Login Local login: connect the computer to the PSI-X-DH1000 hotspot (WiFi _xxxxxxx), and use the computer to access 5.8.8.8 to enter the login interface. LAN login: please refer to 5.6.1 Internet setting. Administrator account: admin, initial Password: (the same as Registration Number).
  • Page 17: Device Detail

    PLEASE NOTE Please refer to Appendix 1 to check whether the baud rate of the model is 19200 or not. If the baud rate is not 19200, please refer to 5.6.3 Serial port setting for more details of setting baud rate. PLEASE NOTE When connecting to PSI-X3P-TP, please make sure the meter is disabled.
  • Page 18: Power Control

    PLEASE NOTE Before using the “Export Limit Control” function, make sure that a meter has been connected to the PSI-X-DH1000. The output of device will be abnormal when connecting to three phase three wire under “Per Phase” mode. 5.3.2. Power Control Power control includes “Ripple Control Receiver”...
  • Page 19: Meter Reversion

    Opcode”, under which there are “READ_HOLDING_REGISTERS”,“READ_INPUT_ REGISTERS”,“WRITE_SINGLE_REGISTER”and“WRITE _MULTIPLE_REGISTERS”. (Can be operated in batches) 5.5. Inverter Upgrade Using PSI-X-DH1000 to upgrade the inverter. Click “Upgrade” to select the upgrade file types which include “ARM”, “MDSP”, “SDSP”, “ARC”, “ARM+DSP”, “BMS_M” and “BMS_S”. Select the corresponding file to upgrade the inverter. PLEASE NOTE It takes nearly 15-30 minutes to upgrade the inverter. During upgrading, no data will be...
  • Page 20: Psi-X-Dh1000 Setting

    “WiFi Setting” to select the WiFi and enter the password. Connect the computer and PSI-X-DH1000 to the same WiFi, and then visit http://datahub.local/ to log in. If there is no feedback of wireless connection within 30 seconds, please disconnect and reconnect the Datahub hotspot (WiFi_XXXXXX).
  • Page 21: Serial Port Settings

    Synchronization” mode. 5.6.3. Serial Port Settings Serial port settings is to set the baud rate of the four serial ports of PSI-X-DH1000, the default value of the baud rate is 19200. The user can change the baud rate under the serial port according to the model.
  • Page 22: Datahub Information

    Disk Space”, “Free TF Space”, “Wi-Fi Connection”, “LAN IP Address”, and “WiFi IP Address”. Clear historical data: Clear the historical data of the device. 5.6.6. PSI-X-DH1000 Upgrade Click the “Click to Upload and Upgrade” button to upload and upgrade the PSI-X- DH1000, then select the upgrade file and wait for the upgrading. (Only one file can be uploaded at a time, and the interface needs to be refreshed for continuous operation.)
  • Page 23: Specifiche Tecniche

    6. Specifiche Tecniche Product PSI-X-DH10001000 Hardware Power adapter 100-240V 50/60Hz AC Input, 12V 2A DC Input Rated power Data transfer interval 5 min Storage capacity 8G/16G TFcard The number of managed devices Communication Inverter communication 3x RS485 Wireless module WiFi 2.4GHz Access network WiFi Communication of electricity meters and...
  • Page 24: Certified Quality Assurance

    Devices with the CE mark meet the essential requirements of the Low Voltage Directive and the Electromagnetic Compatibility Directive. 7.2. Warranty Peimar grants a standard 24-month warranty, if it is otherwise stipulated in the contract, the contract shall prevail. 7.3. Warranty Conditions...
  • Page 25: Disposal

    Disposal This device MUST NOT be disposed as a municipal waste. The crossed-out wheeled bin symbol on the appliance's label indicates that the product, at the end of its useful life, must be collected separately from other waste to allow for proper treatment and recycling. Therefore, at the end of its useful life, the user must hand over the appliance free of charge to the appropriate municipal selective collection centres for electrical and electronic waste.
  • Page 28 | www.peimar.com Version: 2025_01_00...
