Garmin APK 10 Installation Instructions Manual

Important Safety Information
Failure to follow these warnings, cautions, and notices could result in personal injury, damage to the vessel or
device, or poor product performance.
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
To avoid possible personal injury or damage to the device and vessel, disconnect the vessel's power supply
before beginning to install the device.
To avoid possible personal injury or damage to the device or vessel, before applying power to the device, make
sure that it has been properly grounded, following the instructions in the guide.
For the best possible performance, the device must be installed according to these instructions.
When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.
Tools Needed
• Drill and drill bits
◦ Needed for flush mounting:
5
2 mm ( / in.) bit
64
7
11.2 mm ( / in.)
16
◦ Needed for surface mounting:
5
2 mm ( / in.) bit
64
13
20 mm ( / in.) bit
16
• #2 Phillips screwdriver
• Jigsaw or rotary tool (for flush mounting)
• File and sandpaper
• Marine sealant (recommended)
January 2025
APK 10 AUTOPILOT KEYPAD
™
INSTALLATION INSTRUCTIONS
WARNING
CAUTION
NOTICE
GUID-ECDEE7E0-F12E-4700-8A8C-300A4CD5953A v1
