Summary of Contents for Adobe A4CLR201 W
- Page 1 4L Cooler & Heater Model number: A4CLR201 W/B/P/BL IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Electrical Safety ………………………………………. Transportation and Handling ………………………………………. Installing and Switching on Your Appliance ………………………………………. Before Switching On ………………………………………. Your Appliance & the Compartments ………………………………………. Where to put Your Appliance ………………………………………. Usage Information ………………………………………. 10-13 Cleaning & Maintenance ………………………………………. -
Page 3: Safety Instructions
Safety Instructions This appliance is a Semi-conductor electric refrigerating appliance, which is a Category 10 other appliance, according to ErP 643/2009. Its design temperature is 17°C. Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. - Page 4 • D o not plug in damaged plugs. • D o not pull, twist or damage the power cable. • D o not plug-in or un-plug the appliance with wet hands to prevent electrical shock. • T his appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards...
-
Page 5: Electrical Safety
Electrical Safety • B efore switching on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 220 – 240V AC; 50/60Hz / DC 12V. Connection to any other power source may damage the unit. -
Page 6: Installing And Switching On Your Appliance
Installing and Switching on Your Appliance • Operating voltage for your appliance is 220-240V at 50/60Hz / DC 12V . • Before plugging in the power supply, ensure that the voltage on the rating label corresponds to the working voltage of your electrical system in your home or vehicle. -
Page 7: Before Switching On
WARNING! During use, service and disposal of the appliance, please pay attention to symbols similar to the one shown, which is located on rear of the appliance (rear panel or compressor) and with a yellow or orange colour. It’s a risk of fire warning symbol. There are flammable materials in refrigerant pipes and compressor. -
Page 8: Your Appliance & The Compartments
Your Appliance and the Compartments Door handle Heating indicator light Door shelf Off / Mode selection button Internal Shelf DC input Air outlet 10. AC input Air inlet 11. AC connection Cooling indicator light 12. DC connection Parts may vary according to the appliance model. -
Page 9: Where To Put Your Appliance
Where to put your appliance • This appliance should only be placed on a flat, solid surface. • Do not place your appliance on a carpeted surface as this will prevent adequate ventilation. • Choose a dry and well-ventilated space. No less than 100mm (10cms) must be left around the sides and 100mm (10cms) around the back of the appliance to allow sufficient cooling. -
Page 10: Usage Information
Usage Information Note: • Do not use this appliance when engine is off to avoid running down the car battery. • The ambient temperature and air circulation condition can affect the cooling speed and temperature of the appliance. • The cooling temperature range of the appliance is between 18-22℃ below ambient temperature. - Page 11 Usage Information • The unit should be kept away from direct sunlight. • Remove all transport tapes and foam protection pieces. Clean the interior of the appliance with a cloth dampened in lukewarm soap and water. Wipe with clean water and wipe dry. •...
- Page 12 Usage Information • Plug in the cooler/heater and move the mode switch at the rear of the appliance to the Cold or Hot modes. Close the door. • If you have selected the cold mode then leave the appliance for a minimum of 3 hours for the correct temperature to be reached before placing anything inside.
- Page 13 Usage Information Shelves • The shelf can be removed to allow for storage of larger items. • Removing a shelf: Remove all of the items from the shelf that you want to remove. Lift the shelf upwards and then gently pull the shelf away from the appliance.
-
Page 14: Cleaning & Maintenance
Cleaning and Maintenance • Disconnect the appliance from the power supply before cleaning. • Do not pour water directly over or on the appliance. • The compartment should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water. •... -
Page 15: Connection To The Mains Supply
Connection to the mains supply This appliance is designed to operate from a mains supply of 220- 240V AC 50/60Hz. Check that the voltage marked on the product corresponds with your supply voltage. For UK use only – Plug fitting details (where applicable): Slot the end of a screwdriver into the recess in the fuse holder of the plug. -
Page 16: Troubleshooting
Troubleshooting Problem Solution Check that the appliance is switched on. Check that there has not been a power cut. The appliance doesn't work Check that the plug is not faulty. Check that the fuse has not blown. Check that the voltage is correct for the appliance. Check that the appliance is not overfilled. - Page 17 Troubleshooting Problem Solution Check that nothing has leaked or any stagnant liquid is at Smell/odour the bottom of the appliance. Clean if required.
-
Page 18: Guarantee
Guarantee This product is guaranteed for 12 months from the date of original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 19: Technical Specification
Technical Specification Model number A4CLR201 W/B/P/BL Rated Voltage AC 220-240V~50/60Hz / DC 12V Net capacity (litres) 4 litres Cooling performance 18-22°C below ambient temperature Heating performance 52-55°C +/-5°C Dimensions (CMs): (H)27.5 x (W)18.5 x (D)28.0... - Page 20 Made by Product Care Trading Limited. Product Care Trading Ltd, Unit 1, Green Bank Business Park, Swan Lane, Hindley Green, Wigan, WN2 4AY, United Kingdom Product Care (Ireland) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, T23 AT2P, Ireland. Abode is a registered trademark of Product Care Trading Limited.
