- Page 1 ULTRA QUIET & OIL FREE AIR COMPRESSOR OWNER'S MANUAL CALIFORNIA AIR TOOLS 20020CTR-22060 2.0 HP 220 VOLTS 60 HERTZ 1-PHASE 6.40 CFM @ 40 PSI 5.30 CFM @ 90 PSI 20.0 GALLON STEEL TANK WWW.CALIFORNIAAIRTOOLS.COM Customer Support 1-866-409-4581...
-
Page 2: Table Of Contents
Package Contents & Assembly____________________8 Inspect for Damage _____________________________9 Save Packaging ________________________________9 Compressor Location ___________________________9 Electrical Power _______________________________11 Thank you for purchasing a California Air Tools, Inc. Air OPERATING THE AIR COMPRESSOR_______________12 Compressor. Introduction __________________________________12 Assembly ____________________________________12 Please contact us if you have any questions. -
Page 3: Important Safety Instructions
AIR COMPRESSOR Even quality-built equipment might need service or repair parts. Contact the California Air Tools Customer Service Department: Phone: 1-866-409-4581 Online: WWW.CALIFORNIAAIRTOOLS.COM Please provide the information below: Model number and Serial number and specifications shown on the Model number/Serial number plate. - Page 4 AIR COMPRESSOR WARNING WARNING FLYING OBJECTS RISK TO BREATHING Dust or dust-like particulates caused by power- Flying objects can cause injury to the eyes, head and sanding, sawing, grinding, drilling or any other other parts of the body. construction-like activities can contain contaminants Air-powered equipment and power tools are capable that are harmful to breathe.
- Page 5 AIR COMPRESSOR Exercise caution when using pressurized air. To prevent injury and for your general safety, only use high-pressure hoses, fittings and couplings designed for use with air compressors. Inspect all hoses, fittings and couplings for leaks and wear. When leaks and wear are detected, stop use and replace those items immediately.
- Page 6 AIR COMPRESSOR Check with a qualified electrician or serviceman when the grounding instructions are not completely understood, or when in doubt as to whether the product is properly grounded. Do not modify the plug provided. If it does not fit the outlet, have the proper outlet installed by a qualified electrician.
-
Page 7: Locations Of Important Labels
These labels provide important safety and maintenance information. These labels should be considered as permanent parts of the air compressor. Should any of these labels become illegible, damaged or removed, please contact California Air Tools Customer Service department at 1-866-409-4581 for replacements Customer Support: 1-866-409-4581... - Page 8 AIR COMPRESSOR Customer Support: 1-866-409-4581...
-
Page 9: Air Compressor Components
AIR COMPRESSOR PRE-OPERATION CHECKLIST Package Contents & Assembly Model: 20020CTR-22060 Package contents: Air Compressor Owner's Manual (2) 2.0 Hp Air Filters (2) Air Filter Intake Tubes (4” long) Assembly: Install the two (2) 2.0 Air Filters & Air Filter Intake Tubes. -
Page 10: Inspect For Damage
AIR COMPRESSOR Customer Support: 1-866-409-4581 Inspect for Damage Maintain a Clear Area It is very important that the air compressor is positioned so Before using the air compressor, make sure the air tank is not that there is adequate airflow around the machine. There damaged, inspect all parts for damage, and check that all must be at least 2 feet of obstacle-free space surrounding pipes are firmly connected. -
Page 11: Electrical Power
AIR COMPRESSOR DANGER Electrical Power Electrical Extension Cords Electrical Power Requirements SHOCK Inspect all electrical extension cords to ensure that they are free of damage. There is a danger of electric shock. When using an extension cord, use a heavy-duty cord that is no more Use only undamaged electrical cords. -
Page 12: Operating The Air Compressor
AIR COMPRESSOR OPERATING THE AIR COMPRESSOR Save this manual for future reference. Introduction This air compressor features a compact structure, stable performance, a high airflow rate, easy operation and maintenance. Because the air compressor produces no oil in the airflow, it can be used as an independent air supply machine for situations in which oil in the airflow is an issue. -
Page 13: Daily Operation
AIR COMPRESSOR WARNING When the gauge reading reaches 120 PSI - 125 PSI, the pressure switch will automatically turn the power off. This indicates the compressor is working normally. Turn the power switch to the Off position, unplug the power supply cord and release the air in the tank by pulling on the safety valve or via connected air hose. -
Page 14: Maintenance
AIR COMPRESSOR 6. Turn the power switch to the ON position. 7. Let the motor run and tank fill until motor turns off (i.e. 120 PSI +/-5 PSI). 8. To regulate the air flow. While the air compressor is running, turn “On” your tool and turn the regulator knob to the right (clockwise) increasing the output pressure or left (counter-clockwise) to decrease output pressure. -
Page 15: Storage
AIR COMPRESSOR 6. Do not stack or store any items on top of or around the air STORAGE compressor. Damage could occur. Before storing for a prolonged period of time: 1. Turn off the power supply. 2. Disconnect the power cord from the power supply and wrap the power cord around the air compressor handle to reduce the risk of damage. -
Page 16: Specifications
AIR COMPRESSOR Check that the main voltage corresponds to the air compressor specifications. Low voltage supply to the motor. Voltage An extension cord that is too thin or too long can The motor does not start or cause a voltage drop. Use heavy duty extension should be from ~215VAC to 240VAC starts slowly. -
Page 17: Limited Warranty Periods
This warranty does not transfer to subsequent owners. California Air Tools Inc. will repair or replace, at its option, any parts of the portable air compressor that are proven by an authorized service center to be defective in material or workmanship under normal use during the applicable warranty time period as stated below. - Page 18 3. Accident, damage, abuse or misuse. 4. Abnormal operating conditions or applications. 5. Repair or modification by customer or any third party without written consent of California Air Tools Inc. 6. Use under operating conditions or in applications not recommended by California Air Tools Inc.
