- Page 1 99642001_A.qxp 27/03/2007 16:31 Page 1 EN GUIDE TO INSTALLATION We cook so well together Oven SFE 720...
-
Page 2: Dear Customer
99642001_A.qxp 27/03/2007 16:31 Page 2 Dear Customer, You have just acquired a S S A A U U T T E E R R oven and we would like to thank you. We have invested all our dedication and know-how in this appliance so that it would best meet your needs. -
Page 3: Table Of Contents
99642001_A.qxp 27/03/2007 16:31 Page 3 TABLE OF CONTENTS 1 / NOTICES TO THE USER • • Safety Recommendations ___________________________________ • • Environment ______________________________________________ 2 / INSTALLING YOUR APPLIANCE • • Choice of location __________________________________________ • • Building in ________________________________________________ • • Electrical connection _______________________________________ •... -
Page 4: Safety Recommendations
99642001_A.qxp 27/03/2007 16:31 Page 4 1 1 / / NOTICES TO THE USER — During cooking, ensure that the door of your Warning oven is firmly closed so that the seal can prop- Keep this user guide with your appli- erly fulfil its function. -
Page 5: Notices To The User
99642001_A.qxp 27/03/2007 16:31 Page 5 1 / NOTICES TO THE USER • • CARE FOR THE ENVIRONMENT — This appliance’s packing materials are recyclable. Recycle them and play a role in protecting the environment by depositing them in municipal containers provided for this purpose. —... -
Page 6: Installing Your Appliance
99642001_A.qxp 27/03/2007 16:31 Page 6 2 / INSTALLING YOUR APPLIANCE Fig. 01 provided for this purpose on either side of the • • CHOICE OF LOCATION front side panels (fig.1). The diagrams above indicate the dimensions • • BUILD-IN of a cabinet that would be acceptable for your oven. -
Page 7: Electrical Outlet
99642001_A.qxp 27/03/2007 16:31 Page 7 2 / INSTALLING YOUR APPLIANCE Monophase 20A Meter 220-240V~ 50Hz Monophase line 220-240 V ~ A fuse or differential circuit breaker Electrical outlet Power cable length 1.50 m approximately • • ELECTRICAL CONNECTION Electrical safety must be provided by a cor- work via a CEI 60083 standardised recepta- rect build-in. -
Page 8: Changing The Power Cord
99642001_A.qxp 27/03/2007 16:31 Page 8 2 / INSTALLING YOUR APPLIANCE Warning W W e e c c a a n n n n o o t t b b e e h h e e l l d d r r e e s s p p o o n n s s i i b b l l e e f f o o r r a a n n y y a a c c c c i i d d e e n n t t r r e e s s u u l l t t i i n n g g f f r r o o m m a a n n i i n n e e x x i i s s t t e e n n t t , , d d e e f f e e c c t t i i v v e e o o r r i i n n c c o o r r r r e e c c t t g g r r o o u u n n d d l l e e a a d d . -
Page 9: Description Of Your Appliance
99642001_A.qxp 27/03/2007 16:31 Page 9 3 / DESCRIPTION OF YOUR APPLIANCE • • INTRODUCTION TO YOUR OVEN Programmer Lamp Temperature selector Shelf support indicator Function selector This Guide to Installation and Use is valid for several models. Minor differences in details and fittings may emerge between your appliance and the descriptions provided. -
Page 10: Description Of The Accessories
99642001_A.qxp 27/03/2007 16:31 Page 10 3 / DESCRIPTION OF YOUR APPLIANCE • • ACCESSORIES • • Anti-tipping safety grid (fig.1) REAR The grid can be used to hold all dishes and moulds containing foodstuffs to be cooked or browned. It can be used for barbecues (to be placed di- rectly on the grid). -
Page 11: Description Of Your Programmer
99642001_A.qxp 27/03/2007 16:31 Page 11 3 / DESCRIPTION OF YOUR APPLIANCE • • PRESENTATION OF THE PROGRAMME SELECTOR Temperature display Touch controls for setting time ECO indicator (cooking and self-cleaning) Timer touch control Time and duration display Cooking end time touch control Shelf number indicator Cooking time touch control EASY COOK function button... -
Page 12: 4/Using Your Appliance
99642001_A.qxp 27/03/2007 16:31 Page 12 4 / USING YOUR APPLIANCE • How to set the time. When the power is on The display flashes 12:00. (fig.1) fig.1 Set the time by pressing the + or - buttons (continued pressure on the button runs through the numbers quickly) (fig.2). -
Page 13: º Immediate Cooking
99642001_A.qxp 27/03/2007 16:31 Page 13 4 / USING YOUR APPLIANCE •Immediate cooking — The analog programmer should display only the time; It should not be flashing (fig 1). fig.1 Turn the function selector to the position of your choice. Example: position (fig.2). -
Page 14: Programmed Cooking
99642001_A.qxp 27/03/2007 16:31 Page 14 4 / USING YOUR APPLIANCE • • PROGRAMMED COOKING Cooking with immediate start and programmed cooking time - Select the cooking mode desired and adjust the temperature (fig. fig.1 - Press the “ ” button until the cooking “... - Page 15 99642001_A.qxp 27/03/2007 16:31 Page 15 4 / USING YOUR APPLIANCE • • PROGRAMMED COOKING Cooking with delayed start and selected end time P P r r o o c c e e e e d d a a s s w w i i t t h h p p r r o o g g r r a a m m m m e e d d c c o o o o k k i i n n g g . . - After setting the cooking time, press the “...
-
Page 16: º Economic Cooking
99642001_A.qxp 27/03/2007 16:32 Page 16 4 / USING YOUR APPLIANCE • • ECONOMIC * COOKING — The analog programmer should display only the time (fig. fig.1 — Rotate the function selector to the “ ” . L’The “ECO” indicator comes on on POSITION the display (fig. -
Page 17: º Grill
99642001_A.qxp 27/03/2007 16:32 Page 17 4 / USING YOUR APPLIANCE GRILL + • • — This function allows you to combine the cho- sen cooking method with a function that “browns” your dish at the end of cooking; this can be accomplished by turning on the grill for the last five minutes of the programme. -
Page 18: º Use Of The Timer Function
99642001_A.qxp 27/03/2007 16:32 Page 18 4 / USING YOUR APPLIANCE • • USE OF THE TIMER FUNCTION T T h h e e p p r r o o g g r r a a m m m m e e s s e e l l e e c c t t o o r r o o n n y y o o u u r r o o v v e e n n c c a a n n b b e e u u s s e e d d a a s s a a s s e e p p a a r r a a t t e e t t i i m m e e r r w w h h i i c c h h c c a a n n b b e e u u s s e e d d w w h h e e n n t t h h e e o o v v e e n n i i s s o o f f f f . -
Page 19: Oven Cooking Modes
99642001_A.qxp 27/03/2007 16:32 Page 19 5 / OVEN COOKING MODES C C I I R R C C U U L L A A T T I I N N G G H H E E A A T T (recommended temperature 1 1 8 8 0 0 °... -
Page 20: Caring For And Cleaning Your Appliance
99642001_A.qxp 27/03/2007 16:32 Page 20 6 / CARING FOR AND CLEANING YOUR APPLIANCE • • CLEANING THE OUTER SURFACES To clean the window of the electronic timer, as well as the oven door, use a soft cloth moistened with a glass cleaner. Do not use abrasive cleaning products or hard, metallic scrubbers to clean the oven’s glass door, which could scratch the surface and cause the glass to shatter. -
Page 21: Changing The Catalitic Walls
99642001_A.qxp 27/03/2007 16:32 Page 21 6 / CARING FOR AND CLEANING YOUR APPLIANCE CHANGING THE CATALYTIC WALLS (OPTIONAL) • Before commencing disassembly, allow the appliance to cool down and check that the cooking selector switch is in the 0 position. Lateral walls (1) Unhook the wire shelf support (2) at the front by lifting it ( diagram A). -
Page 22: Troubleshooting
99642001_A.qxp 27/03/2007 16:32 Page 22 7 / TROUBLESHOOTING If you have a doubt about the correct functioning of your oven, this does not neces- sarily mean that there is a malfunction. In any event, check the following items: WHAT SHOULD YOU OBSERVE POSSIBLE THAT…... -
Page 23: Changing The Bulb
99642001_A.qxp 27/03/2007 16:32 Page 23 7 / TROUBLESHOOTING Warning - Disconnect your oven before performing any task on the bulb to avoid the risk of electric shock and, if necessary, let the appliance cool down. To unscrew the port and the bulb, use a rubber glove, which will make disassembly easier. -
Page 24: How To Use The Appliance
99642001_A.qxp 27/03/2007 16:32 Page 24 • • ADVANTAGES AND PRINCIPLES Using the “ ” function means you no longer have to select the temperature and cooking time These two parameters are automatically calculated by your oven in order to give you optimal cooking. -
Page 25: Easy Cook Advantages And Principles
99642001_A.qxp 27/03/2007 16:32 Page 25 8 / “EASY COOK” ADVANTAGES AND PRINCIPLES • • TIPS As soon as the icon “ ” stops flashing, you may open the oven door If, however, you open the door while the icon is lit, your oven sounds a warning beep and the dish icons flash. -
Page 26: Easy Cook Cooking Modes
99642001_A.qxp 27/03/2007 16:32 Page 26 EASY COOK COOKING MODES F F I I S S H H Whole fish (sea bream, hake, trout, mackerel, etc.) with herbs and spices • • and white wine, roast fish TIPS : - use this function for whole fish, cooked in the dish (for grilled fish or fish cooked in foil, the oven must be preheated). -
Page 27: Tips And Hints
99642001_A.qxp 27/03/2007 16:32 Page 27 TIPS AND HINTS F F I I S S H H When you buy fish, the smell should be pleasant and not too fishy. The body should be firm and rigid and the scales should be firmly stuck to the skin; the eye should be bright and rounded and gills will appear shiny and moist. - Page 28 99642001_A.qxp 27/03/2007 16:32 Page 28 A FEW RECIPES F F I I S S H H Black sea bream with dry cider : 1 black sea bream weighing 1.5 kg. 500 g button mushrooms. 2 tart apples. 2 shallots 2 tablespoons of heavy cream 100 g butter.
-
Page 29: A Few Recipes
99642001_A.qxp 27/03/2007 16:32 Page 29 A FEW RECIPES C C H H I I C C K K E E N N Stuff with a good bunch of fresh tarragon or coat it with a mixture made of 6 cloves of crushed garlic and a big pinch of salt and a few peppercorns. - Page 30 99642001_A.qxp 27/03/2007 16:32 Page 32 99642001 02/07...
