Target 3DPro™
3D Imaging Wheel Alignment System
Model: 3DP4100
RECEIVING
The shipment should be thoroughly inspected as soon as it
is received. The signed Bill of Lading is acknowledgement
by the shipping carrier as receipt of this product as listed
in your invoice as being in a good condition of shipment. If
any of these goods listed on this Bill of Lading are missing
or damaged, do not accept merchandise until the shipping
carrier makes a notation on the freight bill of the missing or
damaged goods. Do this for your own protection.
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO INSTALLATION AND
OPERATION. BY PROCEEDING WITH THIS 3-D ALIGNER INSTALLATION AND OPERATION
YOU AGREE THAT YOU FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS
OF THIS DOCUMENT. FORWARD THIS IMPORTANT MANUAL TO ALL OPERATORS.
INSTALLATION MANUAL
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
BE SAFE
Your new alignment system was designed and built
with safety in mind. However, your overall safety
can be increased with proper training and thoughtful
operation on the part of the operator. DO NOT operate or
repair this equipment without reading this manual and the
important safety instructions shown inside. Keep this operation
manual near the alignment system at all times. Make sure
that ALL USERS read and understand this manual.
Revision B 10-14-16
P/N 5900957
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Toll Free 1-800-253-2363
Tel: 1-805-933-9970
Fax: 1-805-933-9160
www.rangerproducts.com
