Summary of Contents for Horizon Hobby Spektrum AVIAN 130 Pro
- Page 1 ® Spektrum AVIAN 130 Pro Brushless Smart ESC ™ ™ Spektrum™ AVIAN™ 130 Pro Bürstenloser Smart- Geschwindigkeitsregler ESC Smart sans balais Spektrum™ AVIAN™ 130 Pro Spektrum AVIAN 130 Pro Brushless Smart ESC ™ ™...
- Page 2 SPMXAE2130 Scan the QR code and select the Support tab from the product page for the most up-to-date manual information. Scannen Sie den QR-Code und wählen Sie auf der Produktseite die Registerkarte „Support“, um die aktuellsten Informationen zu Handbücher. Scannez le code QR et sélectionnez l’onglet Support sur la page du produit pour obtenir les informations les plus récentes sur le manuel.
- Page 3 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support or resources tab for this product. Meaning of Special Language...
- Page 4 Age Recommendation: Not for children under 14 years. This is not a toy. NOTICE: This product is only intended for use with un- manned, hobby-grade, remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside of the intended purpose and will not provide warranty service related thereto.
-
Page 5: Table Of Contents
Contents Specifications ..............5 Wiring Diagram ..............6 Throttle Signal ..............7 Installation and Wiring ............7 ESC/Radio Calibration ............8 Stick Programming ............. 9 Programming Parameters ..........10 Programmable Values ............11 Programming Options Descriptions ........12 Programming with the SMART Programmer Box ....16 Operation ................. -
Page 6: Wiring Diagram
Wiring Diagram Motor Leads Motor* Throttle Connection Receiver* Programming Port** Battery* Battery Leads *Not Included **Programming port located directly on ESC case on some models... -
Page 7: Throttle Signal
Throttle Signal SMART Throttle* Spektrum™ Avian™ ESCs are compatible with SMART Throttle. SMART Throttle combines throttle signals with te- lemetry data from the ESC on one normal three-wire servo connector. SMART Throttle compatible receivers will automati- cally detect a SMART Throttle ESC and begin to send telemetry information to your transmitter. -
Page 8: Esc/Radio Calibration
2. Connect the three motor wires from the ESC to the motor wires in any order. In the event the motor spins the wrong direction, reverse any two wires. 3. Connect the throttle lead to the throttle channel on your receiver. -
Page 9: Stick Programming
Stick Programming TIP: If a selection is not made, Power on your transmitter with the throttle at the full the ESC will return to the position. beginning of the list and cycle through the options again. TIP: There are twelve programming parameters. -
Page 10: Programming Parameters
Select the last After exiting programing and parameter (#13) to with the throttle at the low save the settings and position, the ESC will arm and exit programming. operate normally. Programming Parameters Other programming options include the SPMXCA200 Smart Avian ESC programming box and the SmartLink USB updating and programmer application. -
Page 12: Programming Options Descriptions
Programming Options Descriptions 1. Aircraft Type • Fixed-Wing: In this mode, the motor only starts up when the throttle amount reaches 5% or above and it responds to the throttle input rapidly. • Helicopter (Governor): In this mode, the motor only starts up when the throttle amount reaches 40% or above. - Page 13 Normal Brake The motor brake will activate when the throttle stick is moved to the low position. In this mode the strength of the braking is set with the Brake Force selection. Throttle Signal 100% Throttle and Brake Response Brake activates at low throttle 100% Proportional Brake...
- Page 14 3. Brake Force This option is adjustable from level 1 to level 7. The higher the level, the stronger the braking effect. Brake Force is only effective in the “Normal brake” mode. 4. Voltage Cutoff Type Soft Cutoff: Selecting this option will gradually reduce the ESC output to 50% of the full power within 3 seconds after the low-voltage cutoff protection is activated.
- Page 15 8. Start-Up Mode Normal Start-Up: If this mode is selected, the motor will immediately start spinning, then quickly reach the cor- responding speed when you move the throttle stick from bottom position to top position. Soft Start-Up: If this mode is selected, the motor will gradually increase in RPM to correspond to the throttle stick input.
-
Page 16: Programming With The Smart Programmer Box
13. Auto Restart Time The ESC will cut off its output when throttle is between 25–40%. If you increase throttle above 40% within the preset time (0,45,90s), the motor will rapidly accelerate to the speed selected in the programmed Restart Acceleration Time (corresponding to the specific throttle amount), com- plete the shutdown, and restart. -
Page 17: Operation
Operation 1. Leave the transmitter throttle at the low position and connect a battery to the ESC. The ESC will cause the motor to make several tones. The number of tones indicates (1) the ESC is in operation (2) the LiPo cell count detected and (3) the ESC is in a ready-to-use state. - Page 18 Throttle Signal Loss Protection When the ESC detects loss of signal for over 0.25 second, it will cut off power to the motor immediately. The ESC will resu- me normal operation when throttle signals are received. Overload Protection The ESC will cut off power to the motor if there is a sudden load that exceeds predetermined limits.
-
Page 19: Troubleshooting Guide
Troubleshooting Guide Possible Problem Solution Tones Causes Input voltage Two short Ensure the operating is beyond the tones voltage is within the operating range repeating specs for the ESC of the ESC Verify the transmitter and The ESC is receiver are connected, One long Motor won’t not receiving a... - Page 20 Verify battery is charged Change to a larger battery or a higher C rated battery to increase the load the battery can Motor output is The voltage of handle suddenly limited Three the battery has to 60% power short tones Verify the motor is not dropped too during operation...
-
Page 21: 1-Year Limited Warranty
(iii) modification of or to any part of the Product, (iv) attempted service by anyone other than a Horizon Hobby authorized service center, (v) Product not purchased from an authorized Horizon dealer, (vi) Product not com- pliant with applicable technical regulations, or (vii) use that violates any applicable laws, rules, or regulations. - Page 22 LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the liability of Horizon exceed the individual price of the Product on which liability is asserted.
- Page 23 chandise Authorization (RMA) number. Pack the Product securely using a shipping carton. Please note that original boxes may be in- cluded, but are not designed to withstand the rigors of shipping with- out additional protection. Ship via a carrier that provides tracking and insurance for lost or damaged parcels, as Horizon is not responsible for merchandise until it arrives and is accepted at our facility.
-
Page 24: Warranty And Service Contract Information
Horizon will hold non-compliant Product for a period of 60 days from notification, after which it will be discarded. 10/15 Warranty and Service Contact Information Country of Contact Informa- Horizon Hobby Address Purchase tion Horizon Service servicecenter. Center horizonhobby.com/... -
Page 25: Fcc Information
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Horizon Hobby, LLC 2904 Research Rd., Champaign, IL 61822 Email: compliance@horizonhobby.com | Web: HorizonHobby.com... -
Page 26: Compliance Information For Canada
EU Compliance Statement: Avian 130A Brushless Smart ESC (SPMXAE2130): Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the EMC Directive, RoHS 2 Directive 2011/65/EU, RoHS 3 Directive - Amending 2011/65/EU Annex II 2015/863 A copy of the EU Declaration of Conformity is available online at: http://www.horizonhobby.com/content/support-render-... - Page 27 Instructions for disposal of WEEE by users in the European Union This product must not be disposed of with other waste. Instead, it is the user’s respon- sibility to dispose of their waste equipment by handing it over to a designated collections point for the recycling of waste electrical and electronic equipment.
- Page 28 ©2024 Horizon Hobby, LLC. Avian, the Avian Logo, IC3, EC3, DSM2, DSMR, the Smart Technology logo, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
