Summary of Contents for MULE BAKINI BELT
- Page 1 I N STA L L AT I O N G U I D E B A K I N I B E L T...
- Page 2 N OT E INSTALLATION HELP Please review terms and conditions for details Recommended purchaser review Welcome Guide at time of purchase for details Care and Maintenance available at www.exp-one.com/resources We do our best to offer timely assistance with your installation questions however as most of our team members are primarily engaged in the manufacturing process and packaging processes, we do not currently offer a tech for on-demand calls and inquiries.
-
Page 3: Install Guide
INSTALL GUIDE HARDWARE GUIDE ASSEMBLY + MOUNTING SUPPLEMENTAL 1/4”- 20 X 1/2” BUTTON HEAD BOLT KNOB 1/4”- 20 NYLOC NUT LINCH PIN 5/16”- 18 X 1/2” BUTTON HEAD BOLT T-SLOT INSERTS 3/8” – 16 CLIP NUT EXTRA HARDWARE MAY BE LEFT OVER DUE TO MODEL OR OPTION SPECIFIC HARDWARE THAT MAY NOT BE REQUIRED FOR THE INSTALL. -
Page 4: Holder Installation
I N STA L L AT I O N HOLDER INSTALLATION Attach the 2 holder brackets as shown using the provided 1/4“ hardware. These will the boards in place. Rotate or adjust as needed to fit board type. LATCH BRACKET Attach the provided 3/8”... - Page 5 LATCH SIDE MOUNT Attach the mount and riser as shown below for the latch bracket using the provided 1/4” hardware. 2 BOARD RISER SHOWN 4 BOARD RISER SHOWN...
-
Page 6: Assembly Mounting
HINGE SIDE MOUNT Repeat step 3 for the mount and riser as shown below for the hinge bracket using the provided 1/4” hardware. 2 BOARD RISER SHOWN 4 BOARD RISER SHOWN ASSEMBLY MOUNTING Mount the assembly to the rack using the provided carriage bolts or t-slot insert hardware options TIGHTEN ALL HARDWARE AFTER EVERYTHING IS INSTALLED ON THE VEHICLE.
