- Page 1 ML-CP01-400K CORDLESS ORBITAL BUFFER User's Manual...
-
Page 2: Product Specification
Product specification Voltage 40V,120V-230V Motor Power 650 watts Working diameter 180mm Speed control 0~3000 rpm Weight 5.6 kg Both dry and wet, suitable for Product performance grinding and polishing of all hard ground corners, steps and countertops! - Page 3 Attentions Please keep the workplace clean and bright; 1）DO NOT keep the machine near a heat source nor contact with flammable, explosive and corrosive liquids and gases; 2）Protect the machine from being damaged by external force or sharp objects, and prevent it from dropping and causing damage; 3）DO NOT touch the wheel of the cordless orbital buffer in operation with hands nor let the cables enwind into the wheel;...
- Page 4 Attentions Please keep the workplace clean and bright; 6）This cordless orbital buffer can only be used on concrete surfaces other than on other materials; 7）Keep the wheel in the cordless orbital buffer sharp and clean, and replace it in time; 8）Ensure that the wheel in the cordless orbital buffer can rotate smoothly without stagnation;...
- Page 5 Schematic Diagram of the Parts On-off switch Speed control knob Cover plate of the dust cover Dust cover Dustproof brush Diamond cup wheel...
- Page 6 Operating Instructions...
- Page 7 Operating Instructions Step 1: As shown in Fig. I, connect F7619D dust suction pipe to the external dust suction pipe in a built-up way to complete the connection of dust suction pipes. Step 2: As shown in Fig. Ⅱ, hold the handles with both hands, place the machine on the working face, and gently apply pressure on it.
- Page 8 Operating Instructions Step 3: As shown in Fig. Ⅲ, open the cover plate of the dust cover in the direction of the arrow to make it separate from the dust cover. The edge of the diamond-impregnated wheel extends beyond that of the dust cover.
- Page 9 Operating Instructions Step 4: As shown in Fig. Ⅳ, after the operation, release both hands and place the machine on site for 30s. Press the on-off button after the dust in the dust cover is fully absorbed. Then the operation is concluded.
- Page 10 Operating Instructions Step 5: As shown in Fig. Ⅴ, to remove the wheel, firstly, clip the Y-type wrench into the holes on the outer ring of the diamond-impregnated wheel, then secure the hex wrench in the lock screw, and rotate the two wrenches in reverse. Unscrew the lock screw, and remove the wheel to be replaced.
- Page 11 Engineering case...
