HDWR wagPRO-P600L Manual

Platform scale with verification
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
Platform scale with
verification
wagPRO-P600L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the wagPRO-P600L and is the answer not in the manual?

Questions and answers

Related Manuals for HDWR wagPRO-P600L

Summary of Contents for HDWR wagPRO-P600L

  • Page 1 Manual Platform scale with verification wagPRO-P600L...

  • Page 2: Table Of Contents

    Table of contents Specifications: ................................3 Set contents: ................................... 4 Features: .................................... 4 Display and keypad ..............................5 First run ....................................6 Product Weighing ................................ 7 Memory function ................................. 8 Silo Mode ..................................10 Display backlighting ..............................10 Constraints ..................................11 Settings ....................................

  • Page 3: Specifications

    Specifications: • Warranty: 1 year • Material: steel, plastic • Maximum nominal load: 600 kg • Minimum nominal load: 4 kg • Accuracy: 200 g • Maximum permissible load: 100% of nominal load • Available units: kg • Display: LCD, backlit •...

  • Page 4: Set Contents

    Set contents: Weighing platform, • display • power supply for the display, • wall mount for the display, • 7-pin connector connecting the screen to the platform, • Manual. • Features: • Measurement accuracy: 200 g • Display: LCD • Power supply: battery, mains •...

  • Page 5: Display And Keypad

    Display and keypad Zero Indicator: Indicates that the balance plate is empty. Before weighing the product, make sure the balance plate is empty and press the "O" button to set zero if the "O" indicator is off. Otherwise, an error may occur. Balance Index: Shows that the load on the weighing plate is stable.

  • Page 6: First Run

    W1 and W2 indicators: Shows the actual weighing range. Check the max, min, e values of each range on the nameplates. T button: Used to accept the load as tare. O button: Used to zero the balance when the balance plate is empty.

  • Page 7: Product Weighing

    Product Weighing Place the product on the scale plate. Wait for the balance indicator to turn on. The weight of the product will then be displayed. The display should show "0.000" and the balance and zero indicators should be on when the balance plate is empty. If the display is not zero (or the balance indicator is not on), press the reset button to reset the display.

  • Page 8: Memory Function

    Memory function The total memory is used to add the weight and price of the products to the previously calculated weight and price. There are two M+, MR/MC keys on the keyboard to operate this function. Adding to total memory: 1.
  • Page 9 Recalling and deleting the whole: • Press the MR/MC button. First, the message "Top AG" will be displayed for 2 seconds. The total weight will then be displayed for 2 seconds. • Press the MR/MC button to clear the total memory or press the F button to return to normal weighing mode.

  • Page 10: Silo Mode

    Silo Mode Only the TEB series models have this feature. • To enable Silo mode, 12.1 must be disabled (uncommitted mode) and 2.7 must be enabled (Silo mode is active). • In this mode, the initial zero setting check is not applied. When the device is turned off and on, the same weight value is displayed.

  • Page 11: Constraints

    Constraints When this function is activated, an audible signal is generated between two predefined weight values. To use this feature; go to Setting 4.1 to set the minimum weight value limit and go to Setting 4.2 to set the maximum weight value limit. To activate this feature, setting 4.3 must be enabled.

  • Page 12: Settings

    7. Press the MR/MC button. The fourth digit from the right will flash. Press the M+ button to change the value to "2". "XX2000" will appear on the display.5 8. Press the MR/MC button. The fifth digit from the right will start flashing.

  • Page 13: Settings Menu

    • You must use the numeric keys. • Press the F button to store the number. • Press the F button for 3 seconds to return to normal weighing mode. NOTE: When exiting the setup menu, the balance must be turned off and on for reliable weighing.
  • Page 14 1.3 Tare Through Interface (Off). It does not apply to models without an interface. 1.4 Temporary Tare Cancellation (Off). If enabled, when you press the tare button, the tare will be done permanently. 2. Zero setting: 2.1 Controlling the Initial Zero Setting Range ±10% (On). Once committed, the default value is ON and cannot be changed.
  • Page 15 3. Total memory, unit price: 3.1 Adding without displaying total memory (On). If it is ON: The total will not be displayed after M+. The weighing value is displayed. If it is OFF: After M+, the total will be displayed until the pan is empty.
  • Page 16 5. LCD/Time Settings: 5.1 LCD Contrast Level (57). It can be adjusted from 0 to 99.. First Decimal: Contrast when the backlight is not on. Second decimal place: Contrast with backlight on. 5.2 Backlight brightness level (7). Can be adjusted from 1 to 9 5.3 Date (optional).
  • Page 17 If the scale is an approved model, it cannot be changed. Some models may not have this menu. The minimum value is 1, the maximum value is 9. If a value other than these is entered, the filter uses the default value. 7.2 Average length (50) If the scale is an approved model, it cannot be changed.
  • Page 18 It can only be changed if the calibration button is enabled.9 8.2 Maximum Capacity It can only be changed if the calibration button is enabled. 8.3 Division (1) 0: 3000 1: 2 x 3000 2: 3 x 3000 (not valid for approved models) 3: 6000 / 7500 (not applicable to approved models) 4: 12000 / 15000 (not applicable to approved models) 6:1500 (can only be changed when the calibration button is on).
  • Page 19 8.8 Load Cell mV/V Value The mv/V value of the load cell being used. 9. Interface Settings: (Only applies to PRINTER/PC balances) 9.1 Communication ON/OFF (On) If it is ON: RS232 communication is active. If it is OFF: RS232 communication is inactive. (It must be active only for printer/computer scales;...

  • Page 20: Error Messages

    10.2 Start-up delay (10 sec) (On) If the scale is an approved model, it cannot be changed.11 10.3 Calibration Switch (Off) If the calibration switch is disabled, the settings related to the calibration switch cannot be changed. A password is required to enable the calibration switch.
  • Page 21 ERROR6: Turn the scale off and on again. If the fault persists, call for service. ERROR7: Turn the scale off and on again. If the malfunction persists, call for service. ERROR8: Interface communication error. Turn the scale off and then on again. If the scale is not of the computer/printer type and the error persists, call for service.
  • Page 22 ERROR16: See "PrinterUserManualAnnex.doc". If the malfunction persists, call for service. Lo bAtt: The battery is discharged. The scale does not work. It should be charged or replaced as soon as possible. nnnnnn: The platform or scale plate is not placed, or the scale has attempted to be turned on with the weight on it.
