MX100
Rockman
X100
Analog
™
®
Tone Processor
The MXR Rockman X100 Analog Tone Processor
revives the signature sonic character of Tom Scholz's
celebrated headphone amp and signal processor
in pedal form. Offering crystalline cleans, crunchy
harmonics, and shimmering modulation, the original
X100 unit defined the sound of arena rock. This
faithful, all-analog recreation features the same four
tonal presets, carefully calibrated compression for
a clear sound whether clean or distorted, the same
bucket-brigade chorusing as the original, both mono
and stereo modes, and optional external mode
switching for an enhanced user experience.
jimdunlop.com/mx100
Advertisement
Summary of Contents for mxr Rockman X100
- Page 1 X100 Analog ™ ® Tone Processor The MXR Rockman X100 Analog Tone Processor revives the signature sonic character of Tom Scholz’s celebrated headphone amp and signal processor in pedal form. Offering crystalline cleans, crunchy harmonics, and shimmering modulation, the original X100 unit defined the sound of arena rock.
- Page 2 1 CTRL jack allows MODE function to be controlled with 6 Edge mode: Moderate clipping. Very sensitive to INPUT an off-board switch such as the MXR Tap or MXR TRS GAIN adjustments and cleans up nicely at low guitar Split + Tap.
- Page 3 ALTERNATE SETUP OPTIONS The Rockman X100 Analog Tone Processor is designed to enhance your tone through any setup. But if you want a subtler high-end response, try running the pedal into the return of your amp’s FX...
- Page 4 Specifications Input Impedance 700 kΩ Output Impedance 1.8 kΩ Current Draw 120 mA Bypass Buffered Bypass Power Supply 9 volts DC MX100 | MXR Rockman X100 Analog Tone Processor 4 ® ® ™...
Need help?
Do you have a question about the Rockman X100 and is the answer not in the manual?
Questions and answers
When using the stereo feature, how do you tell the right channel from the left channel?
