AEG T8DEA68S User Manual

AEG T8DEA68S User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
T8DEA68S
USER
MANUAL
EN
User Manual
Tumble Dryer

Advertisement

loading
Need help?

Need help?

Do you have a question about the T8DEA68S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AEG T8DEA68S

Summary of Contents for AEG T8DEA68S

  • Page 1 T8DEA68S User Manual Tumble Dryer USER MANUAL...

  • Page 2: Table Of Contents

    CONTENTS 1. SAFETY INFORMATION..................... 3 2. SAFETY INSTRUCTIONS.....................6 3. PRODUCT DESCRIPTION...................8 4. CONTROL PANEL....................... 9 5. FIRST TIME START-UP....................9 6. USING THE TOUCH SCREEN.................. 11 WI-FI - CONNECTIVITY SETUP................12 8. BEFORE FIRST USE....................14 9. PROGRAMMES......................14 10. OPTIONS......................... 17 11.

  • Page 3: Customer Care And Service

    ENGLISH FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 4: General Safety

    Children between 3 and 8 years of age and persons •...
  • Page 5 ENGLISH The ventilation opening in the base must not be • covered by a carpet, mat, or any floor covering. CAUTION: The appliance must not be supplied • through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.

  • Page 6: Safety Instructions

    Before any maintenance operation, deactivate the • appliance and disconnect the mains plug from the socket. 2. SAFETY INSTRUCTIONS 2.1 Installation • Do not use multi-plug adapters and extension cables.
  • Page 7 ENGLISH • To replace the internal lighting, • The compressor and its system in the contact the Authorised Service tumble dryer is filled with a special Centre. agent which is free from fluoro-chloro- hydrocarbons. This system must stay 2.5 Care and cleaning tight.

  • Page 8: Product Description

    3. PRODUCT DESCRIPTION Water container Airflow slots Control panel Condenser lid Internal lighting Condenser cover Appliance door Adjustable feet Filter Rating plate For ease of loading laundry or ease of installation the door is reversible. (see separate leaflet).

  • Page 9: Control Panel

    Start/Pause button 5. FIRST TIME START-UP When you turn on your dryer for the first Language time, the Start-up Screen (shows the AEG logo and the time ) appears on the touch Svenska screen and plays each time you turn on Deutch the dryer.

  • Page 10: Time Setup

    5.2 Time setup change in to the summary screen. The dryer is ready to use. 1. Scroll the bar of hours and minutes to the right or left to set the current time. Clock Cupb. Clock 01:00 30min More 2.

  • Page 11: Water Tank Warning

    ENGLISH If you press OK, the warnings of full Water Hardness water tank is still enabled. The program list appears and in a few Soft Water Hardness seconds it will change in to the summary screen. Soft Cupb. 4. To accept the water hardness level 30min press OK, if you want to change it press Change.

  • Page 12: Wi-Fi - Connectivity Setup

    Make sure that your smart device is network. connected to the wireless network. 1. Go to the App Store on your smart Frequency 2.412 - 2.472 GHz for Eu- device. ropean market 2. Download and install App My AEG .

  • Page 13: Over-The-Air Update

    7.4 Over-the-air update Cancel The App may propose an update for downloading new features. 2. Configure the My AEG app on your The update is accepted via App only. smart device. 3. If the connectivity is configured, a If a programme is running, the App...

  • Page 14: Before First Use

    During the update, the appliance shows If an error occurs, the appliance shows in the display. in the display: just press any buttons or turn the knob to return to The appliance will usable again at the normal use.
  • Page 15 ENGLISH Programmes Properties / Fabric mark Load Woollen fabrics. Gentle drying for hand-washa- ble woollens. Remove items immediately when the programme is completed. 1 kg Wool The wool drying cycle of this machine has been approved by The Woolmark Company for the drying of machine washable wool products pro- vided that the products are washed and dried according to the instructions on the garment la-...

  • Page 16: Programs And Options Selection

    Programmes Properties / Fabric mark Load Easy care fabrics for which a mini- mum of ironing is necessary. The drying results can be different from one type of fabric to the other. 1,5kg (or 7 Business Shirts Shake the items before you put shirts)/ them in the appliance.

  • Page 17: Options

    ENGLISH Options Extra Dry- Time Anti- Programs Load Silent ness Level crease Silks Outdoor Sports Jeans Business Shirts Refresh Easy Iron Duvet Bed Linen Mixed 1) Together with the program you can set 1 or more options. 10. OPTIONS 10.1 Extra Silent 10.4 Time Dry...

  • Page 18: Delay Start

    • Normal Any time you can stop the • Light countdown of the delay time by pressing the Reset 10.7 Delay Start button. Lets to delay the start of a 10.8 Memory drying program from minimum of 10 minutes to Lets you memorise up to 2 of your maximum of 24 hours.

  • Page 19: Loading The Laundry

    ENGLISH Fabric label Description Laundry is suitable for tumble drying at low temperatures only. Laundry is not suitable for tumble drying. 11.2 Loading the laundry CAUTION! Ensure the laundry is not trapped between the appliance door and the rubber seal. 1.
  • Page 20 The possible time to complete the program comes into the time bar. The drying time you see on the display, when the cotton programme is selected, is related to the load of 5 kg and standard conditions . Real drying time will depend on type of the load (quantity 3.
  • Page 21 ENGLISH Child lock option activation: At any time during the drying you can activate the child lock option. 1. Tap on the option icon to get to Cupb. the option list. 2. Tap on the child lock option. The option icon will change into the child lock icon.

  • Page 22: Machine Settings

    To remove the laundry: If you do not turn off the 1. Push the On/Off button for 2 appliance, the anti-crease seconds to turn the appliance off. phase starts (not active with 2. Open the appliance door. all programs). Laundry can 3.
  • Page 23 ENGLISH tap on <Programmes bar to get to To improve readability of the the summary screen. display when a dryer is stacked over a washing 12.5 Water Hardness machine set the 6th level of the display brightness. When To change the default water hardness the dryer is not stacked level level: 1 to 5 are suggested.

  • Page 24: Machine Information

    1000 1200 1400 12.9 Shortcuts To activate the desirable shortcuts: 1. Tap on the Shortcuts bar to expand the list of available shortcuts. 1000 1200 1400 4. Tap on the Cottons bar or Other programmes bar to close the choice.

  • Page 25: Hints And Tips

    ENGLISH 2. To confirm the factory reset tap on 12.11 Factory Reset OK or Cancel to leave the current Factory Reset restores the settings to the settings. state where it was made out in the factory. To activate the factory reset : 1.

  • Page 26: Emptying The Water Container

    2. Pull the plastic connection out and drain the water into a basin or equivalent receptacle. 4. If necessary, clean the filter with a vacuum cleaner. Close the filter. 5. If necessary, remove fluff from the filter socket and gasket. You can use a vacuum cleaner.

  • Page 27: Cleaning The Drum

    ENGLISH 2. Open the condenser cover. 6. Close the condenser lid. 7. Turn the lever until it clicks into position. 8. Put the filter back. 14.4 Cleaning the drum WARNING! Disconnect the appliance before you clean it. Use a standard neutral soap detergent to clean the inner surface of the drum and 3.

  • Page 28: Troubleshooting

    15. TROUBLESHOOTING Possible cause Remedy Problem The tumble dryer is not connected Connect to the mains socket. to the mains supply. Check fuse in fuse box (domestic installation). The door is open. Close the door. The tumble dry- er does not op- The On/Off button was not push- Push the On/Off button.
  • Page 29 ENGLISH Possible cause Remedy Problem Unexpected du- The drying duration is calculated This is automated — the appliance ration time on according to load size and damp- is working correctly. the display. ness. The water container is full. Drain the water container, push Program inac- tive.

  • Page 30: Technical Data

    Possible cause Remedy Problem The wireless signal does not reach Try to move the home router as the dryer. near the dryer as possible or con- sider purchasing a wireless range The App fre- extender. quently cannot The wireless signal is disrupted by Turn the microwave off.

  • Page 31: Consumption Data

    ENGLISH 0,05 W Off mode power absorption 2,00 W Power consumption in networked standby 15 min. Time to networked standby Type of use Household Allowed ambient temperature + 5°C to + 35°C Level of protection against ingress of solid IPX4 particles and moisture ensured by the pro- tective cover, except where the low voltage equipment has no protection against mois-...

  • Page 32: Accessories

    Energy consump- Programme Spun at / residual humidity Drying time tion Synthetics 3,5 kg Cupboard Dry 1200 rpm / 40% 65 min. 0,47 kWh 800 rpm / 50% 80 min. 0,60 kWh 1) For partial loads, the cycle time is shorter and appliance uses less energy.

  • Page 33: Pedestal With Drawer

    ENGLISH 17.3 Pedestal with drawer Accessory name: PDSTP10, E6WHPED2. Available from your authorised vendor. For increasing the height of the appliance in order to ease loading and unloading of laundry. The drawer can be used for laundry storage e.g. : towels, cleaning products etc.
  • Page 34 18.2 Cleaning the filter At the end of each cycle the message Clean the lint filter comes on the display and you must clean the filter. 18.3 Programmes Programmes Load Properties / Fabric mark Cottons 8,0 kg Cotton fabrics.

  • Page 35: Product Information Sheet In Reference To E.u. Regulation 1369/2017

    1) The maximum weight refers to dry items. 19. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017 Product Information Sheet Trade Mark Model T8DEA68S PNC916098064 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class...

  • Page 36: Environmental Concerns

    The 'standard cotton programme' used at full and partial load is the standard drying programme to which the information in the label and the fiche relates, this programme is suitable for drying normal wet cotton laundry and it is the most efficient programme in terms of energy consumption for cotton.
  • Page 37 ENGLISH...
  • Page 38 www.aeg.com...
  • Page 39 ENGLISH...
  • Page 40 LGPL-2.0, LGPL-2.1, zLib, MIT, ISC, Apache 2.0 and others. It is possible to display the complete copy of the licenses in the AEG App that can be downloaded from the corresponding App store from the License menu section. It is possible to download the source code of the open source software used in the product by searching for Wi-Fi Module Software version in NIUX subfolder at the following website: http://aeg.opensoftwarerepository.com.
