- Page 1 FORBICI ELETTRICHE PRUNING SHEARS SÉCATEUR ELECTRONIQUE KRATOS 25 Manuale dell’utente User manual Manuel d’utilisation et d’entretien...
-
Page 2: Table Of Contents
INDEX Package Content ........Product Overview ........Note ...................... Product Description ................ Technical Speci cations ..............Product Components ..............Product Operation ........Setting up ................... Packing up ..................Use, Maintenance and Precautions of Battery, Battery Charging ................Blade Replacement ................ Operation Precautions ...... -
Page 3: Packing List
Dear customer, thank you for choosing an Ibea product. In order to use at best this product, we advise you to read this manual in all its parts and keep it carefully for future reference. If you nd any anomalies or malfunctions, do not hesitate to contact Ibea assistance center closest to you. -
Page 4: Product Description
Product Description This product is a battery-driven electric pruning shear, comprises a xed blade, a movable blade, a lithium battery, a battery charger, a power cord and other components. Designed for cutting or trimming 25mm or less branches in fruit orchards, vineyards, etc. -
Page 5: Product Components
Product Components 1. Movable blade 2. Fixed blade 3. Latch pin 4. Trigger 5. Power switch 6. Lubrication hole 7. Charger plug 8. AC charger socket 9. Charging jack 10. Battery release button 11. Battery input connector 12. Battery output connector 13. -
Page 6: Product Operation - Setting Up
Product Operation - Setting Up 1. Insert the battery into the power connector of the pruner. 2. Switch on the power switch of the pruner. Due to rst time usage, the LED display indicator will be green and the buzzer will sound 1 time. 3. -
Page 7: Use, Maintenance And Precautions Of Battery Battery Charging
Use, Maintenance and Precautions of Battery Battery Charging The battery of the new product is not fully charged. Place the battery on the desktop, insert the charger output jack into the battery socket, as illustrated in Fig. 1 and then plug the charger plug into the power socket. When the indicator light lights up, charging starts. -
Page 8: Blade Replacement
To charge two batteries with one charger: as shown in the gure 1. Not charging 2. Charging 3. Fully charged Order of the indicator light Note: In case that two or three batteries are connected, charging will start by the order from 1 to 2 then to 3, during which the indicator light is red and will turn green when the battery is fully charged. -
Page 9: Operation Precautions
Fixed and movabe blades can be replaced individually; do not worry about the size of the replacement blade aperture, the opening will automatically return to normal size during power ON after completing blade replacement. Operation Precautions Usage and Care for Pruning Shear Do not cut branches beyond speci ed diameter indicated, do not cut hard items such as metals, stones or any other non-plants materials. -
Page 10: Safety Notes
Only use battery charger supplied with the pruning shear, the use of any other charger not matching to the speci cation of the battery may cause re. Item such as paper clips, coins, keys, nails, screws or any other conductive items must be keep away from battery when not in use. Do not disassemble the battery. -
Page 11: Human Safety
3. Do not misuse the power cord. Do not lift or pull up the pruning shear by the power cord. Keep the pruning shear away from heat, oil, sharp edges or moving parts. Human Safety Use suitable clothing and protective shoes with non-slip soles. Use protective gloves. -
Page 12: Irregularity Measures
Irregularity Measures In the event the pruning shear is not able to cut through an object, release trigger immediately, the moving blade will return to its open position automatically. In the event the pruning shear is cutting through a particularly hard branch, release the trigger immediately, the moving blade will return to its open position automatically. -
Page 13: Warranty
Warranty This machine has been conceived and manufactured through the most modern productive techniques. The manufacturer guarantees its products for a period of 24 months from the date of purchase except for professional continuous service products, used for work on behalf of third parties, for which the warranty is 12 months from purchase date. - Page 14 CE DECLARATION OF CONFORMITY Translation of the original text The Company IBEA s.r.l. Via Milano, 15/17 - 21049 Tradate (VA) ITALY DECLARES THAT THE MACHINE Denomination: Electric pruner Type: Kratos Model: Kratos 25 - Kratos 40 Year of construction: 201 9 IS IN CONFORMITY WITH THE RELEVANT COMMUNITY HARMONISATION LEGISLATION: DIRECTIVE 2006/42/CE Machinery Directive...
-
Page 15: Error Reports
Error reports In case of any fault, please handle it according to the prompt code on the disply screen. Fault prompt on the display screen: When using this product, if the following code appears on the screen, repair or handle it according to the corresponding fault prompt. - Page 16 Scheda prodotto / Product sheet / Fiche produit Modello / Model / Modèle ..............................................Rivenditore / Retailer / Détaillant ............... Data / Date ...........................
- Page 17 Notes...
- Page 18 Notes...
- Page 19 ACTIVE s.r.l. - Via Delmoncello, 12 - 26037 San Giovanni in Croce (CR) Tel. 0375.91742 - Fax 0375.91684 - email: info@active-srl.com www.active-srl.com...
