Summary of Contents for hogar HSE-IM-CM-WF-IN
- Page 1 CURTAIN MODULE SMART MODULE SERIES #Switchtosmart...
- Page 3 Smart Spaces. Thank you for trusting us with your space & choosing Hogar Wi-Fi Curtain Module. This manual is designed to help you install your Hogar Wi-Fi Curtain Module in an easy and hassle-free manner. Please follow all the steps given below and experience the safety...
- Page 4 CURTAIN MODULE SMART MODULE SERIES TA B L E O F C O N T E N T S USAGE NOTICE 1.1. Warnings and Considerations 1.2. Precautions PRODUCT DETAILS 2.1. Description 2.2. Features 2.3. Technical Specifications 2.4 Installation 2.5 App Registration 2.6 Configuration 2.7 Reset WARRANTY...
- Page 5 USAGE N OT I C E 1.1. WARNINGS AND CONSIDERATIONS: Caution symbols highlighted across the manual represent the following: Indicates highlighted precautions/warnings that must be followed to prevent any serious problems. Indicates instructions followed during installation. Indicates suggestions and tips. Please follow the notices to ensure your safety as well as to prevent property loss.
- Page 6 Install this device by following all the national and local electrical codes. Using this product in any manner other than how it is referred to in this document voids your warranty. Further, Company is NOT liable for any damage incurred with the misuse of the product. DO NOT use an electric screwdriver to install this device, doing that might over-tighten the screws and strip them which may interfere with the proper switch operation.
- Page 7 1.2. PRECAUTIONS Ensure the below DOs & DON'Ts are adhered to enjoy a seamless product experience: DOs: - Locate the curtain module far from the metal elements. DON'Ts: - DON’T connect loads more than recommended - DON’T over tighten the screws and strip them. - DON’T paint the product.
- Page 8 2.2. FEATURES - With the timer feature on Hogar SE App, you can open and close your roller blinds at a specific time. - Automate your Home curtains via Rules, Scenes, Scheduling, and Voice Controlling.
- Page 9 2.3. TECHNICAL SPECIFICATIONS Product Number HSE-IM-CM-WF-IN Brand Name Hogar Voltage 90-250V AC Max. Power 500W (250V) Wi-Fi Frequency 2.4 GHz -10°C to 40°C Operating Temperature Dimensions 52 X 47 X 18 mm IP20 IP Rating...
- Page 10 2.4 INSTALLATION - Turn off the power supply before carrying out any electrical installation work. - Connecting the wires according to the wiring diagram - Insert the module into the junction box - Connect the power supply and follow curtain module configuration instructions.
- Page 11 2.5 APP REGISTRATION / LOGIN - Download the “Hogar SE” application at App Store or Google Playstore. - Enter the Register/Login interface - Tap “Register” to create an account. - Select Country. - Enter your email ID. - Check “I agree to User Agreement & Privacy Policy” (Please review the terms and conditions) - Click on “Get Verification Code”...
- Page 12 2.6 CONFIGURATION - Ensure your phone is connected to Wi-Fi and Bluetooth. - Open Hogar SE App and Click “+” then the prompt will automatically show on the screen. Click “Go to add” - Press the reset button for more the 7 seconds until the beep sounds continuously for entering the Wi-Fi pairing mode..
- Page 13 Warranty Exclusive 15-Month Warranty We offer an on any product that covers defects in materials and quality under normal use of the Product. The Terms and Conditions of this 1.3 YEARS LIMITED WARRANTY can be viewed on www.hogarcontrols.com or scan the QR code:...
- Page 14 CONGRATULATIONS You've successfully installed Hogar Wi-Fi Curtain Module and now you can start controlling your motrised curtains/blinds. Add more smart home devices to your home from our range of smart home solutions and live a smart life.
- Page 15 Hogar Controls Inc, 46040 Center Oak Plaza, Suite 125, Sterling, Virginia 20166 | Phone : +1 703 844 1160 INDIA Techno-1, Khajaguda X Road, support@hogarcontrols.com Radhe Nagar, Rai Durg, www.hogarcontrols.com Telangana 50008. Phone : +91 844 844 0789...
