Summary of Contents for UROVO FR2000
- Page 1 Urovo Technology Co., Ltd. FR2000 Desktop RFID (UHF) Reader User Manual...
-
Page 2: Fr2000 Desktop Rfid (Uhf) Reader
Urovo. Unless permitted by copyright law, the user has no right to copy all or part of the licensed program. Without written permission from Urovo, the user may... -
Page 3: Table Of Contents
Urovo Technology Co., Ltd. index FR2000 Desktop RFID (UHF) Reader ....................1 Statement ............................1 index ............................2 Chapter 1. Appearance ....................... 3 Chapter 2. Indicator Light Explanation ..................6 Chapter 3. Get Started ........................ 7 3.1 Connection ........................7 3.2 Connection and Power Supply ..................7 3.2.1 To Windows ....................... -
Page 4: Chapter 1. Appearance
Urovo Technology Co., Ltd. Chapter 1. Appearance FR2000 is a state-of-the-art desktop UHF reader developed by Urovo Technology. This reader is versatile, supporting applications on Windows, Android, and iOS platforms. With its cutting-edge E710 RFID chip and proprietary high-efficiency signal processing algorithms, FR2000 excels in read-write capabilities across a broad reading range. - Page 5 Urovo Technology Co., Ltd.
- Page 6 Urovo Technology Co., Ltd.
-
Page 7: Chapter 2. Indicator Light Explanation
Urovo Technology Co., Ltd. Chapter 2. Indicator Light Explanation The indicator lights on the device display different statuses, including power on, communication status, etc. -
Page 8: Chapter 3. Get Started
Urovo Technology Co., Ltd. Chapter 3. Get Started 3.1 Connection Real-time communication, interconnection Support Type-C USB 2.0, Bluetooth BT5.0, RJ45 network port and other communication methods can be interconnected with Windows, Android, iOS and other devices with different operating systems to meet the needs of different operational scenarios. -
Page 9: To Windows
Urovo Technology Co., Ltd. 3.2.1 To Windows 3.2.1.1 Install the Driver If you are using USB for data communication, install the USB driver first,... -
Page 10: Connect
Urovo Technology Co., Ltd. 3.2.1.2 Connect Open the “UHF Reader Pad\Demo\Demo\c#\EXE\UHFReader288Demo.exe” or some other demo Select the com port shown in your device manager... -
Page 11: To Android
Urovo Technology Co., Ltd. If the device have RJ45-LAN port, you can use the IP to connect the device 3.2.2 To Android 3.2.2.1 Search the BT of the device You can find the name in the bottom label, or you can read it in the UHFReader288Demo.exe,... -
Page 12: Open The App And Demonstration
Urovo Technology Co., Ltd. 3.2.2.2 Open the APP and Demonstration 3.2.2.2.1 Connect to RFID device. Open-connect Bluetooth, then the firmware version will be shown: Buzzer on/off option... - Page 13 Urovo Technology Co., Ltd. 3.2.2.2.2 Setting page Power(0-27dBm), only one Antenna.
-
Page 14: Chapter 4. Setup
Urovo Technology Co., Ltd. 3.2.2.2.3 Reading tags Chapter 4. Setup 4.1 Baud rate... -
Page 15: Output Power (0~27Dbm)
Urovo Technology Co., Ltd. 4.2 Output power (0~27dBm) 4.3 Protocol Only support ISO18000-6C 4.4 Region 4.5 Buzzer... -
Page 16: Temperature
Urovo Technology Co., Ltd. 4.6 Temperature... -
Page 17: Chapter 5. Rfid Tag Read And Write Operations
Urovo Technology Co., Ltd. Chapter 5. RFID Tag Read and Write Operations - Place the RFID tag to be read or written within the device's reading range, - Start the software, select the read or write operation, and follow the on-screen prompts. -
Page 18: Chapter 6. Rfid Tag Lock And Kill
Urovo Technology Co., Ltd. Chapter 6. RFID Tag Lock and Kill... -
Page 19: Chapter 7. Environmental
Urovo Technology Co., Ltd. Chapter 7. Environmental - Position the FR2000 on a stable surface, ensuring good ventilation in the surrounding environment. - Avoid use in humid, high-temperature, or extreme temperature conditions to prevent affecting device performance. Operating Temp. -20℃... -
Page 20: Chapter 8. Safety Precautions
Urovo Technology Co., Ltd. Chapter 8. Safety Precautions When operating the desktop UHF reader (such as the FR2000) from Urovo Technology, it is essential to observe the following safety precautions to ensure a secure and efficient usage environment: Electrical Safety: Connect the UHF reader only to power sources that comply with the specified voltage and power requirements outlined in the user manual. -
Page 21: Chapter 9. Develop Option
Urovo Technology Co., Ltd. Chapter 9. Develop option Please maintain continuous communication with technical personnel to obtain development mat erials. -
Page 22: Chapter 10. Troubleshooting
If you have any questions or need further support, feel free to contact our customer service team. Thank you for choosing the FR2000 Desktop RFID (UHF) Reader, and we wish you a pleasant user experience! - Page 23 Urovo Technology Co., Ltd. Appendix 1 Specifications Model UROVO FR2000 Dimensions 325mmx325mmx20mm weight 1850g Based on Impinj E710 design, fully support 18000-6C (EPC CLASS1 G2) protocol tags 840~960MHz frequency band (frequency customization optional) Basic RFID FHSS or Fix Frequency transmission, support RSSI...
- Page 24 Urovo Technology Co., Ltd. and indicator lights of the fuselage may be slightly adjusted, please refer to the actual situation. Accessories Type Standard Accessory Type-C cable*1...
