Page 5
1.1.1 Informationen zur Anleitung Die Anleitung gibt wichtige Hinweise und Tipps zur Montage eines LED Counters an eine LZA 500. Alle technischen Angaben in der Anleitung wurden mit größter Sorgfalt erarbeitet bzw. zusammengestellt. Trotzdem sind Fehler nicht auszuschließen. Wir sehen uns deshalb gezwungen, darauf hinzuweisen, dass weder eine Garantie noch eine juristische Verantwortung oder ir- gendeine Haftung für Folgen, die auf fehlerhafte Angaben zurückgehen, übernommen werden kann.
Page 6
Abnutzung durch den bestimmungsgemäßen Gebrauch handelt. 1.1.4 Garantiebestimmungen Die einzelnen Garantiebestimmungen befinden sich in den Verkaufsunterlagen. Generell gilt: Bei Umbauten oder technischen Veränderungen die nicht von der Adolf Nissen Elektrobau GmbH + Co. KG zertifiziert wurden, erlischt jeglicher Garantieanspruch! 1.1.5 Ersatzteile WARNUNG! Verletzungsgefahr durch falsche Ersatzteile! Falsche oder fehlerhafte Ersatzteile können zu Beschädigungen, Fehlfunktionen oder Totalausfall führen...
Page 7
Die Elektrofachkraft ist für den speziellen Einsatzort, in dem sie tätig ist, ausgebildet und kennt die rele- vanten Normen und Bestimmungen. · muss unterwiesen und befähigt sein, die Anlagen/ Maschinen der Adolf Nissen Elektrobau GmbH + Co. KG zu warten und ggf. Installationen vorzunehmen.
Page 9
3 Gehäuse grüne Signalgeberleuchte 6 Standrohr Kurzbeschreibung Das Counter Modul für LZA 500 zählt die noch verbleibende Zeit der Rotphase im Automatikprogramm herunter (max 9:59 min). Das Counter Modul kann bei Anlagen mit Grünzeitverlängerung und Kreu- zungen eingesetzt werden. Der Counter kann bei Anlagen ab Baujahr 2010 bzw. Softwareversion V2.03 eingesetzt werden. Ältere Anla- gen können ggf.
Page 14
Flügel- oder Rändelschraube* fixieren. 25. Anschlusskabel des Standrohrs mit der Spannungsversorgung verbinden. 26. Deckel des Steuergehäuses öffnen. 27. LZA 500 ggf. einschalten und den Parameter zur Erkennung des Counter Moduls aktivieren betriebnahme. 28. Funktionstest durchführen. 29. Deckel des Steuergehäuses verschließen.
Page 16
Information about these instructions These instructions provide important information on handling the assembly of LED counter on traffic light system LZA 500. All technical data in these instructions have been developed or compiled with the greatest of care. Errors cannot however be exclu- ded.
Page 17
2.1.4 Warranty conditions The warranty conditions are included in the separate sales documents. Generally valid: Alterations and technical modifications which have not been certified by Adolf Nissen Elektrobau Gm- bH + Co. KG void all warranty claims. 2.1.5 Spare parts...
Page 18
Electricians are trained for the specific place of use in which they are active, are trained and are familiar with the relevant standards and regulations. · must be instructed and qualified to maintain the systems/machines of Adolf Nissen Elektrobau GmbH + Co. KG and to carry out installations if necessary.
Page 20
6 Stand tube Short description The counter module for LZA 500 displays the remaining time of the red phase during the automatic program (9:59 minutes at maximum). The counter module can be used on systems with green time ex- tension and crossings.
Page 25
25. Connect the cable of the stand tube to the power supply. 26. Open the lid of the control housing. 27. Switch LZA 500 on if necessary and activate the parameter for recognising the counter module Starting up. 28. Check the functionality.
