INSTRUCTION MANUAL
- OPERATION
- INSTALLATION
- MAINTENANCE
Carefully read this instruc-
tions before use.
DLS AC 230AC / 300AC / 450AC
GB
TRANSLATED FROM
THE ORIGINAL IN
ITALIAN LANGUAGE
Code: 240.010.0047
Date: 28/01/2022
Rev.: 00
