Henden HWQH Installation & Owner's Manual

Water quality hub
Hide thumbs

Advertisement

Quick Links

Download this manual
Henden Water Quality Hub
HWQH
INSTALLATION &
OWNERS MANUAL
WARNING:
Failure to follow
these instructions
and comply with all
applicable codes
may cause serious
bodily injury and/or
property damage.
The installation of
Always ensure you're
this product should
working from the
be carried out by a
current revision
person knowledgeable
of this manual.
in swimming
Refer to www.bit.
pool plumbing
ly/HendenHWQH
requirements following
the installation
instructions provided
in this manual.
Please pass these instructions on to the operator of this equipment
IMPORTANT
Please read carefully

Advertisement

loading
Need help?

Need help?

Do you have a question about the HWQH and is the answer not in the manual?

Questions and answers

Summary of Contents for Henden HWQH

  • Page 1 Henden Water Quality Hub HWQH INSTALLATION & OWNERS MANUAL IMPORTANT Please read carefully WARNING: The installation of Always ensure you’re Failure to follow this product should working from the these instructions be carried out by a current revision and comply with all person knowledgeable of this manual.
  • Page 2 8.1.3.2. Overriding the pH probe using the Henden Smart Chlorinator App 36 8.2. ORP/chlorine control 8.2.1. Adjusting ORP set point 8.2.1.1. Adjusting the ORP set point on the HWQH control panel 8.2.1.2. Adjusting the ORP set point using the Henden Smart Chlorinator App 40...
  • Page 3 8.2.2.2. Re-calibrating ORP probe using the Henden Smart Chlorinator App 43 8.2.3. Overriding/ignoring orp probe 8.2.3.1. Overriding the ORP probe on the HWQH control panel 8.2.3.2. Over-riding the ORP probe using the Henden Smart Chlorinator App 45 8.3. Add salt warning 8.4.
  • Page 4 Henden Water Quality Hub Installation Manual 1. IN THE BOX A. 1 x Henden Water Quality Hub (HWQH) 1 x Salt/temperature probe J. 1 x Acid feed injection point B. 2 x 40/50mm unions C. 1 x QRG (Quick Reference Guide) K.
  • Page 5 • ppm: An abbreviation of parts per million. • Probe (a.k.a. Sensor or Electrode): A device placed in the pool water piping system that measures specific water properties. The measurements provided are interpreted by the HWQH controller to either take corrective action or to send a warning.
  • Page 6 4.2 INSTALLATION OF THE HENDEN SALT AND MINERAL CHLORINATOR Before installing the Henden Water Quality Hub (HWQH), you must first install the Henden Salt & Mineral Chlorinator (HSMC) according to the instructions supplied with the unit. For access to a full digital version of the installation and operating instructions, visit https://bit.ly/hendenchlioi or by scanning this QR code...
  • Page 7 ATTENTION: If any of the instructions here contained is not respected, there can be damage to persons &/or incorrect working, or damage to the apparatus. Henden recommends the use of 5L HCl acid, added to 15L of tap water or a ratio of 1 part acid, added to 3 parts of tap water. This should be done in a container suitable of use with HCl acid.
  • Page 8 A: 3 x probe sealing blanks B: 3 x probe locking nut with o-rings and washers C: Probe housing D: 2 x barrel unions with tail, nut & o-ring E: Acid feed injection point Figure 4.4 8 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 9 Figure 4.5 • The housing is installed so as water flow moves in the correct direction, shown by arrow markings on the housing (refer Figure 4.6) û ü PUMP FILTER PUMP FILTER Figure 4.6 HENDEN INSTALLATION & OWNERS MANUAL | 9...
  • Page 10 Where pipework is found to drain, the probe housing should be installed to allow a low point, to keep water in the housing, ensuring the probe ends remain submerged (refer Figure 4.9). Figure 4.9 10 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 11 (represented on the lid with s), and tightened with the locking nut. IMPORTANT: Henden recommends ensuring that all feeder tubing and probe cables be attached to pipework where possible. Use “cable ties” or “sticky/electrical tape”. This is good practice, not only as the installation looks more professional, but it also limits potential damage to feeder tubes and probe cables by becoming entangled, or pulled by users during servicing of equipment etc.
  • Page 12 The acid dosing pump is powered by an ELV (extra low voltage) 24VDC supply. On the end of the acid dosing pump power lead is a Tamiya connector (refer Figure 4.13). The Tamiya connector needs to fit into the back of the HWQH controller (refer Figure 4.13). The connector is deliberately designed such that it fits only one way.
  • Page 13 On the end of the temperature sensor and TDS probe lead is a locking BNC plug and an RCA plug. Both the BNC plug and the RCA plug needs to fit into the back of the HWQH controller controller. The BNC plug for the TDS probe needs to fit into the first socket (refer Figure 4.18) and the RCA plug for the temperature sensor needs to plug into the RCA socket...
  • Page 14 For pluggable equipment, the socket-outlet shall be easily accessible On the back of the controller is an IEC input power socket. • Connect the incoming power lead (supplied) into the IEC power socket on the rear of the HWQH controller (refer Figure 4.21).
  • Page 15 For the HWQH controller to communicate to the H8VSPBT pool pump, an RJ45 connection cable must be used. Plug the RJ45 connection cable into the back of the HWQH controller (refer Figure 4.25). Plug the other end of the RJ45 connection cable into the port of the H8VSPBT (as explained in its I&OI).
  • Page 16 For adequate weatherproofing, the wall or post that the HWQH is mounted to should be flat and at least as wide as the unit. Ensure the top and bottom of the HWQH is not protruding higher than what it is mounted to. Henden recommends installation under cover or eaves.
  • Page 17 6. FIRST TIME START-UP PROCEDURE 6.1 LANGUAGE MENU Upon initial power up, HWQH runs through a start-up process. This process is also run if the system is put through a “factory reset”. The first screen displayed is the LANGUAGE menu (refer Figure 6.1).
  • Page 18 • Repeat this process with clock minutes adjustment and AM/PM toggle (if 12 hour clock format has been chosen); • The display will then request clock confirmation (refer Figure 6.4) CLOCK: HRS: MINS –>OK Figure 6.4 • Press menu/setting select to save and continue. 18 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 19 • If you’ve chosen to use the pH probe, the next screen will instruct you to put the pH probe into pH 7 solution (ref Figure 6.7) • Once correct, then press menu/setting select ph calibration: put probe into ph 7 solution –>ok Figure 6.7 HENDEN INSTALLATION & OWNERS MANUAL | 19...
  • Page 20 • The screen will next display pH calibration in progress (refer Figure 6.11). A count will commence. Typically, the calibration will take less than 15 seconds, but may take up to a minute; 20 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 21 • The probe can then be removed from the pH calibration solution and installed into the probe and injection housing. The injection housing has written in the moulding which probe is mounted where (refer Figure 6.13) Salt & Temperature Figure 6.13 HENDEN INSTALLATION & OWNERS MANUAL | 21...
  • Page 22 • When sliding the probe into the probe housing, ensure that the probe is located approximately half way into the probe housing (refer Figure 6.16). û û ü Probe not in Probe in far enough too far Figure 6.16 22 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 23 (refer Figure 6.17); The factory default pH set point is 7.4, however you may wish to change this once the HWQH is installed. It should be noted that chlorine’s effectivity is greatly influenced if pH levels are too high, or too low. Henden recommends the pool chemistry levels shown in section 10.
  • Page 24 • On the probe and injection housing, under each of the 3 x probe locking nuts, is an o-ring and washer (refer Figure 6.22). Remove the second probe locking nut on the housing (where it’s marked ORP) 24 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 25 Figure 6.23 It should be noted that chlorine’s effectivity is directly related to the pool water’s ORP level as explained in section 3. Henden recommends following the pool levels shown in section 10. Adjustment to the ORP set point can be made as follows: •...
  • Page 26 • The next screen asks if the temperature probe is currently connected and to be used (refer Figure 6.26). The temperature probe is the same probe as the salt probe, but it does plug into the HWQH controller by a separate socket...
  • Page 27 7. CONNECTING THE HWQH TO Wi-Fi Download the Henden Smart Chlorinator App from the Switching on Bluetooth App store or Google play. From the menu on your HWQH unit, go into settings and then to Bluetooth. Henden Smart Chlorinator main: modes ->...
  • Page 28 Figure 7.2 As is the case with most “smart devices”, it is important to ensure that your HWQH and HSMC have the latest revision of firmware. When a critical firmware update is released, your HWQH &/or HSMC will be able to update over the air (OTA), as long as they are correctly connected to the internet.
  • Page 29 8.1.1. Adjusting pH set point The factory default pH set point is 7.4, however you may wish to change this once the HWQH is installed. It should be noted that chlorine’s effectivity is greatly influenced if pH levels are too high, or too low. Henden recommends following the pool chemistry levels shown in section 10.
  • Page 30 The change is then saved, and the display reverts back to the settings menu. • Press the menu/setting cancel (go back) button twice to revert back to the HOME SCREEN. 30 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 31 Henden Water Quality Hub Installation Manual 8.1.1.2. Adjusting the pH set point using the Henden Smart Chlorinator App • From the dashboard of the Henden Smart Chlorinator App, press “Probes” (refer figure 8.8); Figure 8.8 • In the probe setting menu, you’ll notice that the current pH set point. From the probe settings menu, press “edit”...
  • Page 32 • Once you’re back to the probe setting menu, you’ll notice that the pH set point has changed (refer figure 8.12) Figure 8.12 • Now simply press the back arrow button at the top left corner to return to the home screen of the Henden Smart Chlorinator App (refer figure 8.13). Figure 8.13...
  • Page 33 Checking the calibration of the probe is a good practice to do on a 3-monthly basis. Conduct a water analysis with a reliable pool water test kit and compare the reading from the test kit, to the reading from the HWQH probe.
  • Page 34 Should the need arise whereby the pH probe needs to be isolated (turned off, or ignored) this is possible both via the HWQH control panel, or via the Henden Smart Chlorinator App. This may become necessary if the probe is damaged during a maintenance clean.
  • Page 35 “NO” (refer figure 8.22) is the ph probe connected? ->no Figure 8.22 • Then press the menu/setting select button. The change is then saved, and the display reverts back to the settings menu. HENDEN INSTALLATION & OWNERS MANUAL | 35...
  • Page 36 Henden Water Quality Hub Installation Manual 8.1.3.2. Overriding the pH probe on the Henden Smart Chlorinator App • From the dashboard of the Henden Smart Chlorinator App, press “probe settings” (refer figure 8.23) Figure 8.23 • In the probe setting menu, press “edit” (refer figure 8.24) Figure 8.24...
  • Page 37 • Once you’re back in the probe setting menu, where the pH reading was previously shown, it will now read “no probe” (refer figure 8.26). Figure 8.26 • Press the back arrow to return to the home screen of the Henden Smart Chlorinator App (refer figure 8.27). Figure 8.27 HENDEN INSTALLATION & OWNERS MANUAL | 37...
  • Page 38 8.2.1. Adjusting ORP set point The factory default ORP set point is 650mV, however you may wish to change this once the HWQH is installed. It should be noted that chlorine’s effectivity is greatly influenced if pH levels are too high, or too low. Henden recommends following the pool levels shown in section 10.
  • Page 39 The next screen will ask “is the ORP probe connected?” (Refer Figure 8.34) is the orp probe connected? ->yes Figure 8.34 • Press the menu/setting select button. The next screen shows the current ORP set point (Refer Figure 8.35) HENDEN INSTALLATION & OWNERS MANUAL | 39...
  • Page 40 (go back) button twice to revert back to the HOME SCREEN. 8.2.1.2. Adjusting the ORP set point using the Henden Smart Chlorinator App • From the home screen of the Henden Smart Chlorinator App, press “probe settings” (refer figure 8.36) Figure 8.36 •...
  • Page 41 • Once your preferred set point is shown, press “save” (refer figure 8.39) Figure 8.39 • Once you’re back to the probe setting menu, you’ll notice that the ORP set point has changed (ref figure 8.40) HENDEN INSTALLATION & OWNERS MANUAL | 41...
  • Page 42 Checking the calibration of the probe is a good practice to do on a 3-monthly basis. Conduct a water analysis with a reliable pool water test kit and compare the reading from the test kit, to the reading from the Henden HWQH probe.
  • Page 43 Should the need arise whereby the ORP probe needs to be isolated (turned off, or ignored) this is possible both via the HWQH control panel, or via the Henden Smart Chlorinator App. This may become necessary if the probe is damaged during a maintenance clean.
  • Page 44 Henden Water Quality Hub Installation Manual 8.2.3.1. Overriding the ORP probe on the HWQH control panel • From the HOME SCREEN, press the menu/setting select button. This will now show the main menu (Figure 8.46) main: -> modes settings maintenance Figure 8.46...
  • Page 45 • This step is only necessary if you select NO ORP probe. Should you wish to control the chlorine output manually, HWQH’s chlorine output works the same as explained in the HSMC manual. Refer to the relevant section following URL https://bit.ly/hendenchlioi chlorine output: >100%...
  • Page 46 “save” (refer figure 8.54) Figure 8.54 • Once you’re back in the probe setting menu, where the ORP reading was previously shown, it will now read “no probe” (refer figure 8.55). Figure 8.55 46 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 47 Once the salt concentration is back within range (refer to recommended salt range section in the manual), the HWQH will resume normal operation. 9. ADVANCED FEATURES There are several advanced features available in the HWQH. These modes can be found in the main menu (Figure 9.1). For any modes to be active the HWQH must be on. main: ->...
  • Page 48 9.1 VSD SET POINT The HWQH controller can control the speed of your connected circulation pump (if compatible. The Henden 8 star Variable speed pump (H8VSPBT only) is an example of a compatible pump). To correctly operate the VSD pool pump control, ensure that the compatible pump is wired into the HWQH controller (refer Section 4.6.3).
  • Page 49 Figure 9.7), and the circulating pump will not run. Nor will the salt cell produce chlorine, or acid dosing pump feed acid. 02:38PM slt –––– t –––°c orp –––– ph ––– Figure 9.7 HENDEN INSTALLATION & OWNERS MANUAL | 49...
  • Page 50 Henden Water Quality Hub Installation Manual 9.2.1. Activating system mode on the HWQH control panel System Mode can change between System on or off by pressing the Manual on/off button from the HOME SCREEN or via the Modes section in settings.
  • Page 51 Henden Water Quality Hub Installation Manual 9.2.2. Activating system mode using the Henden Smart Chlorinator App • From the dashboard of the Henden Smart Chlorinator App, go to the “modes” menu by using the modes button (refer Figure 9.11). Figure 9.11 •...
  • Page 52 9.3 SCHEDULE MODE Schedule mode allows the HWQH to run the system at specific times of the day. It also enables your circulation pump to run at selected speeds, during specific times of the day (if compatible – refer Section 9.1). This could be particularly handy if you wish to run your pump, for example:: •...
  • Page 53 • Once time settings have been made to TIMER 1, press the menu/setting select button to re-enter the TIMER 1 menu (refer Figure 9.20). mODES: SCHEDULE -> TIMER 1 TIMER 2 Figure 9.20 HENDEN INSTALLATION & OWNERS MANUAL | 53...
  • Page 54 • From the MODES menu, use the menu up/down buttons to scroll down to SCHEDULE (refer Figure 9.23). Then press the menu/setting select button to confirm. mODES: SYSTEM -> SCHEDULE TIMER 1 Figure 9.23 54 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 55 SYSTEM -> SCHEDULE TIMER 1 Figure 9.25 9.3.2.Adjusting Schedule Mode on the Henden Smart Chlorinator App 9.3.2.1. Adding a timer • From the dashboard, go to the “modes” menu by using the modes button (refer Figure 9.26). Figure 9.26 HENDEN INSTALLATION & OWNERS MANUAL | 55...
  • Page 56 If you have compatible equipment, you can also elect a pump run speed, for this timer (refer Section 9.1). Figure 9.28 • Adjustments can be made to the scheduled start time by scrolling the hours &/or minutes up and down with your finger on the screen (refer Figure 9.29). Figure 9.29 56 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 57 (refer Figure 9.31), or activate Schedule Mode (refer Section 9.3.2.3). Figure 9.31 • Should you wish to add two separate timers, repeat the process above. They will appear in the Modes menu as shown (ref Figure 9.32). HENDEN INSTALLATION & OWNERS MANUAL | 57...
  • Page 58 • From the dashboard, go to the “modes” menu by using the modes button (refer Figure 9.33). Figure 9.33 • In the “modes” menu, click the timer you wish to remove (refer Figure 9.34). Figure 9.34 58 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 59 Figure 9.36 9.3.2.3. Activating Schedule Mode • Ensure Manual Mode is off (refer Section 9.2). To activate system mode, go to the “modes” menu by using the modes button (refer Figure 9.37). Figure 9.37 HENDEN INSTALLATION & OWNERS MANUAL | 59...
  • Page 60 Probes aren’t resistant to high levels of chlorine for extended periods of time as it may reduce the life of the probe. Henden recommends removing the probes from the manifold when increasing chlorine in the pool. 9.4.1. Activating Boost Mode on HWQH control panel •...
  • Page 61 BOOST mODE: -> Off Figure 9.42 • Press the menu/setting cancel (go back) button twice to revert back to the HOME SCREEN (refer Figure 9.43). mODES: TIMER 2 -> BOOST WINTER Figure 9.43 HENDEN INSTALLATION & OWNERS MANUAL | 61...
  • Page 62 • To turn off BOOST MODE, repeat the process shown above, but opt for “BOOST MODE: OFF”. 9.4.2. Activating Boost Mode on the Henden Smart Chlorinator App • From the dashboard of the the Henden Smart Chlorinator, go to the “modes” menu by using the modes button (refer Figure 9.45).
  • Page 63 For example: • When the HWQH is running the chlorinator and WINTER MODE is off. The chlorinator cell current (typically measured in Amps) will be operating at 100% capacity. • When the HWQH is running the chlorinator, but WINTER MODE is on, the chlorinator cell current (typically measured in Amps) will only be operating at 85% capacity.
  • Page 64 Henden Water Quality Hub Installation Manual 9.5.1. Activating Winter Mode on the HWQH control panel • From the HOME SCREEN, press the menu/setting select button. Press the menu up/down buttons to scroll down to MODES (ref Figure 9.49), then select by pressing the menu/setting select button.
  • Page 65 • To turn off WINTER MODE, repeat the process shown above, but opt for “WINTER MODE: OFF”. 9.5.2. Activating Winter Mode on the Henden Smart Chlorinator App • From the dashboard, go to the “modes” menu by using the modes button (refer Figure 9.54).
  • Page 66 • Once back at the dashboard “Winter Mode Active” will now appear (refer Figure 9.57). Figure 9.57 • To turn off WINTER MODE, repeat the process shown above, but opt for “WINTER MODE: OFF”. 66 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 67 (rather than through the salt cell & back to the pool). The backwash mode in HWQH disables the Henden Smart Chlorinator App, to ensure that the pumps are only turned on &...
  • Page 68 If the sight glass did clear, turn your media filter to rinse setting and allow the pump to run again for another 2-minute cycle. When the pump again stops, your filter can be returned to its normal/filter setting. HWQH BACKWASH mode should now be returned to normal (refer Figure 9.62), following the steps above. RUN A BACKWASH? ->...
  • Page 69 9.7.2. Operating backwash mode using the Henden Smart Chlorinator App Backwash mode control is not available via the app and must be controlled by the HWQH control panel. This ensures that the operator is present, with the pool equipment during the maintenance.
  • Page 70 • To turn off SPA MODE, repeat the process shown above, but opt for “SPA MODE: OFF”. 9.8.2. Activating Spa Mode using the Henden Smart Chlorinator App • From the dashboard of the Henden Smart Chlorinator App, go to the “modes” menu by using the modes button (refer Figure 9.69).
  • Page 71 Figure 9.70 • Return to the dashboard now by using the home button (refer Figure 9.71). Figure 9.71 • Once back at the dashboard “Spa Mode Active” will now appear (refer Figure 9.72). HENDEN INSTALLATION & OWNERS MANUAL | 71...
  • Page 72 9.9 COVER MODE (for use if NO ORP probe is connected): The HWQH is compatible with large swimming pool applications as well as much smaller spa applications. Turning on the COVER MODE reduces the chlorinator cell duty cycle by 80% of its current setting.
  • Page 73 -> Off Figure 9.75 • Press the menu/setting cancel (go back) button twice to revert back to the HOME SCREEN (refer Figure 9.76). mODES: backwash -> cover Figure 9.76 HENDEN INSTALLATION & OWNERS MANUAL | 73...
  • Page 74 • To turn off COVER MODE, repeat the process shown above, but opt for “COVER MODE: OFF”. 9.9.2. Activating Cover Mode using Henden Smart Chlorinator App • From the dashboard, go to the “modes” menu by using the modes button (refer Figure 9.78).
  • Page 75 • COVER MODE can also be triggered remotely by an automated pool cover controller. By closing the terminal block contacts on the rear of the HSMC power supply (ref Figure 9.82), the HWQH will remotely switch to COVER MODE. This can be overridden by user intervention, by following the steps explained previously.
  • Page 76 COVER MODE can also be triggered remotely by an automated pool cover controller. By closing the terminal block contacts on the rear of the HSMC power supply (ref figure 9.2), HWQH will remotely switch to COVER MODE. This can be overridden by user intervention, by following the steps explained previously.
  • Page 77 Figure 9.85 • If you are looking to sync a “Davey Heat pump”, then press the respective button (refer Figure 9.86). If you are looking to sync a “Henden Heat Pump”, go to section 9.11.2 of this manual. Figure 9.86 •...
  • Page 78 Figure 9.88 • Allow a couple of minutes to connect the Henden Smart Chlorinator App to your Davey Heat Pump. Your app with show the connection is in progress (refer Figure 9.89). This screen will continue for ~ 10 seconds.
  • Page 79 9.11.2. Connecting the Henden Smart Chlorinator App to a “Henden Heat Pump” • If you are looking to sync a “Davey Heat Pump”, go to section 9.11.1 of this manual. • On your Henden Heat Pump, press the menu button to go into the main menu. • Use the...
  • Page 80 Please enter your Wi-Fi SSID or username and password and click connect. Figure 9.97 • The Henden Heat Pump screen will show the below message: ‘RECONFIGURE WIFI SUCESS! CONNECTED TO WEB SERVICE’ 80 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 81 Henden Water Quality Hub Installation Manual • From the dashboard, go to the “settings” menu and select “Heat Pump” from the list. Then select the “Henden Heat Pump” option and “Connect now”. Figure 9.98 • Enter your MAC or heat pump ID in the format shown. Then press “Connect Now”...
  • Page 82 Henden Water Quality Hub Installation Manual 9.11.3. Adjusting set temperature of a heat pump using the Henden Smart Chlorinator App • From the dashboard of the Henden Smart Chlorinator App, press “probe settings” (refer figure 10.0) Figure 10.0 • With the heater already on, press the button for “Water Temp” “Edit” (refer Figure 10.1).
  • Page 83 • Once you’re happy with the change, press “Save” (refer Figure 10.3). Figure 10.3 • Now the change is reflected in the Probe Settings screen, press the back button to return to the dashboard (refer Figure 10.4). Figure 10.4 HENDEN INSTALLATION & OWNERS MANUAL | 83...
  • Page 84 Add Cyanuric Acid Monthly & refill pool to dilute Not to be used (ppm) for indoor pools. Recommended Partially drain salt Levels 3000-6000ppm Add salt Monthly & refill pool to dilute (ppm) Figure 10.1 84 | HENDEN INSTALLATION & OWNERS MANUAL...
  • Page 85 Figure 10.2 This reduction of ORP can be confused by HWQH to be a low chlorine level. In reaction to the perceived low chlorine level, HWQH will increase it’s chlorine production (unnecessarily) and elevate the chlorine level in the pool.
  • Page 86 To fit the probe blanks, follow the relevant part of section 4. IMPORTANT: Be sure to turn off the probe in the HWQH menu, following the relevant part from section 6. When re-fitting the replacement probe, following the relevant part from section 6.
  • Page 87 12.1 WARNINGS AND ALARMS Message on Warning or Alarm Cause for Alarm Clearing the Alarm HWQH Once the HWQH registers a salt Low Salt Warning SALT LOW Salt reading of 3000ppm or below. concentration within range the warning will clear.
  • Page 88 ORP probe using the app or at the HWQH unit and correct the levels of the other chemistry. If your stabiliser/cyanuric acid levels remain out of range, adjust your ORP setpoint down to compensate when the probe is reconnected and recalibrated.
  • Page 89 3 months to maintain accuracy. If the problem isn’t resolved you may need to replace the probe. • The low salt models of the HWQH and HSMC are designed to operate down to 1500ppm TDS, check if you have a low salt model.
  • Page 90 • HWQH will need to be powered before the HSMC on first time start up. • It may be necessary to force a software update – make sure your HWQH is connected to Wi-Fi then hold the down button on your HWQH down until the screen goes blank, it will update your HWQH to the latest version. Once complete, hold the back button down until the screen goes blank, this will update your HSMC chlorinator.
  • Page 91 MUST provide evidence of the date of original purchase when making a claim. Henden shall not be liable for any loss of profits or any consequential, indirect or special loss, damage or injury of any kind whatsoever arising directly or indirectly from Henden products.
