Mycond BEEHEAT User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
USERS
MANUAL
MYCOND BEEHEAT
HEAT PUMP
12/2022 EN Ver.1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the BEEHEAT and is the answer not in the manual?

Questions and answers

Related Manuals for Mycond BEEHEAT

Summary of Contents for Mycond BEEHEAT

  • Page 1 USERS MANUAL MYCOND BEEHEAT HEAT PUMP 12/2022 EN Ver.1.0...
  • Page 3 MYCOND BEEHEAT HEAT PUMP CONTENTS I. Safety instruction ...........................4 1.1. About the manual ........................4 1.2. For the user ..........................5 II. Overview of wired controller ......................6 2.1. The appearance .........................6 2.2. State icons ..........................7 III. Home pages ..........................8 IV. Menu structure ........................... 13 4.1.
  • Page 4 I. SAFETY INSTRUCTION 1.1. ABOUT THE MANUAL DANGER Indicates a situation that results in death or serious injury. DANGER: RISK OF ELECTROCUTION Indicates a situation that could result in electrocution. DANGER: RISK OF BURNING Indicates a situation that could result in burning because of extreme hot or cold temperatures. WARNING Indicates a situation that could result in death or serious injury.
  • Page 5 MYCOND BEEHEAT HEAT PUMP 1.2. FOR THE USER ■ If you are not sure how to operate the unit, contact your installer. ■ The appliance is not intended for use by persons, including children, with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 6 II. OVERVIEW OF WIRED CONTROLLER 2.1. THE APPEARANCE MENU Enter the menu structure from the home page. ON/OFF Turn on or off the space operation mode、DHW mode or the function in the menu structure. ARROW Navigate the cursor on the display; Navigate in the menu structure; adjust the settings; Flip pages in the menu structure.
  • Page 7 MYCOND BEEHEAT HEAT PUMP 2.2. STATE ICONS Weekly schedule Daily schedule 10° Outside temp. WLAN Screen Lock Fan coil ° 01-01-2022 23:00 Disinfect Radiator Floor heating Turn on °c Turn o °c °c Desired or real °c water temp. Tank temp.
  • Page 8 III. HOME PAGES When you turn on the wired controller, the system will enter the language setting page, you can choose your preferred language, and then press OK to enter the home pages. If you don't press OK in 60 seconds, the system will enter in the currently selected language.
  • Page 9 MYCOND BEEHEAT HEAT PUMP Table 1 ZONE TYPE = ONE and ROOM THERMOSTAT = NON SINGLE ZONE OPERATION SET = 0 ZONE TYPE = ONE and ROOM THERMOSTAT = NON SINGLE ZONE OPERATION SET = 1 ROOM THERMOSTAT = MODE SET...
  • Page 10 The system has the function including floor heating and domestic water: Wire controller ······ FHL1 FHL2 FHLn Outdoor Indoor NOTE: The wired controller should be installed in the floor heating room to check the room temperature. Home page 3 If any one of the settings on Table 2 is set, there will be main page and second page. Home page 3 will appear: Main page Zone 1 target or DHW tank target or...
  • Page 11 MYCOND BEEHEAT HEAT PUMP Table 2 ZONE TYPE = TWO and ROOM THERMOSTAT = NON DUAL ZONE OPERATION SET = 0 ZONE TYPE = TWO and ROOM THERMOSTAT = NON DUAL ZONE OPERATION SET = 1 ZONE TYPE = TWO and ROOM THERMOSTAT = NON...
  • Page 12 Main page ° 01-01-2022 23:00 °c 2.0bar Zone 1 target or real water temp. Second page ° 01-01-2022 23:00 °c 26.0 Zone 2 target or real room temp. Table 3 ZONE TYPE = TWO and ROOM THERMOSTAT = NON DUAL ZONE OPERATION SET = 3 ZONE TYPE = TWO and ROOM THERMOSTAT = NON DUAL ZONE OPERATION SET = 7 Refer to “FUNCTION PARAMETER SET”...
  • Page 13 MYCOND BEEHEAT HEAT PUMP IV. MENU STRUCTURE 4.1. ABOUT THE MENU STRUCTURE You can use the menu structure to read out and configure settings that are NOT meant for daily usage. What you can see and do in the menu structure is described where applicable. For an overview of the menu structure, see " 7 Menu structure: Overview".
  • Page 14 V. BASIC USAGE 5.1. SCREEN LOCK If the icon appears on the screen, the controller is locked. The following page is displayed: ° 01-01-2022 23:00 °c °c 2.0bar Press any key, the icon will flash. ° 01-01-2022 23:00 °c °c 2.0bar Long press “...
  • Page 15 MYCOND BEEHEAT HEAT PUMP 5.2. TURNING ON/OFF CONTROLS Use the interface to turn on or off the unit for space heating or cooling. ■ The ON/OFF of the unit can be controlled by the interface if the ROOM THERMOSTAT is NON.(see ”FUNCTION PARAMETER SET”...
  • Page 16 If the DHW MODE DISABLE is set 1(1=YES), then following pages will display: ° 01-01-2022 23:00 °c 2.0bar ° 01-01-2022 23:00 °c 2.0bar If Temp. TYPE is set to ROOM TEMP., and then following pages will display: ° 01-01-2022 23:00 °c °c 26.5...
  • Page 17 MYCOND BEEHEAT HEAT PUMP Use the interface to turn on or off the unit for DHW. Press " " or " " on home page, the black cursor will appear: ° 01-01-2022 23:00 °c °c 2.0bar When the cursor is on the temperature of DHW mode, press " " key to turn on/off the DHW mode.
  • Page 18 ■ If the space operation mode is OFF, then following pages will display: ° 01-01-2022 23:00 °c °c 2.0bar ° 01-01-2022 23:00 °c °c 2.0bar ° 01-01-2022 23:00 °c °c 2.0bar 5.3. ADJUSTING THE TEMPERATURE Press " " or " " on home page, the black cursor will appear: °...
  • Page 19 MYCOND BEEHEAT HEAT PUMP ■ If the cursor is on the temperature, use the " " or " " to select and use " " or " " to adjust the temperature. ° 01-01-2022 23:00 °c °c 2.0bar ° 01-01-2022 23:00 °c...
  • Page 20 5.4. ADJUSTING SPACE OPERATION MODE ■ Adjusting space operation mode by interface Go to " " » "OPERATION MODE SET". Press " ", the following page will appear: OPERATION MODE SET COOL AUTO ■ There are three modes to be selected including HEAT, COOL and AUTO mode. Use the " " or " " to scroll, press "...
  • Page 21 MYCOND BEEHEAT HEAT PUMP VI. OPERATION 6.1. OPERATION MODE SET See "5.4 Adjusting space operation modes". 6.2. TEMP. CURVE SET TEMP. CURVE SET function is used to preset the desired water flow temperature depending on the outside air temperature. During the warmer weather the heating is reduced. To save energy, TEMP. CURVE SET can decrease the desired water flow temperature when the outdoor air temperature increased in heating mode.
  • Page 22 ■ If you want to use heat mode in zone 1(namely zone A), you select "LOW TEMP. FOR ZONE-A HEAT". If you want to use cool mode in zone 1(A), you select "LOW TEMP. FOR ZONE-A HEAT". If you press "OK", there are 9 curves to be select by pressing "...
  • Page 23 MYCOND BEEHEAT HEAT PUMP DHW ADDITIONAL FUNCTION DISINFECT DHW PUMP CURRENT STATE OPERATE DAY START 23:00 DHW ADDITIONAL FUNCTION DISINFECT DHW PUMP CURRENT STATE OPERATE DAY START 23:00 Use " ", " ", " ", " " to scroll and use " ", " " to adjust the parameters when setting “CURRENT STATE” and “OPERATION”...
  • Page 24 6.4. SCHEDULE SCHEDULE menu contents as follows: 1. TIMER 2. WEEKLY SCHEDULE 3. SCHEDULE CHECK 4. CANCEL TIMER and WEEKLY SCHEDULE 6.4.1 Timer schedule If the weekly schedule function is on, the timer is off, the later setting is effective, namely you can set TIMER schedule to be valid.
  • Page 25 MYCOND BEEHEAT HEAT PUMP There are 6 timers to be set. Use " ", " ", " " and " " to scroll and use to " ", " " adjust the time, the mode and the temperature. Move to "N", press " " to change “N” to “Y”, and then press " " to change “Y” to “N” again. “Y” is to enable the timer;...
  • Page 26 The operation of the controller at the following time: TIME The operation of the controller 1: 00 DHW mode is turned ON 3: 00 DHW mode is turned OFF 7: 00 HEAT MODE is turned ON 9: 00 HEAT MODE is turned OFF 11: 30 COOL MODE is turned ON 13: 00...
  • Page 27 MYCOND BEEHEAT HEAT PUMP SCHEDULE WEEKLY TIMER CHECK CANCEL Here Tuesday, Wednesday and Friday are selected to be scheduled and they have the same schedule. Press " " and then " " or press " " twice, the following pages will appear:...
  • Page 28 6.4.3 Schedule check Schedule check can only check the weekly schedule. Go to " " » "SCHEDULE" »"CHECK ". Press " ". The following page will appear: SCHEDULE CHECK TIMER WEEKLY CANCEL CHECK WEEKLY SCHEDULE 50°C 30°C 50°C 50°C 50°C 50°C Press "...
  • Page 29 MYCOND BEEHEAT HEAT PUMP ° 01-01-2022 23:00 °c °c 2.0bar If TIMER or WEEKLY SCHEDULE is canceled, timer icon " " or weekly schedule icon " " will disappear on the home page. ° 01-01-2022 23:00 °c °c 2.0bar INFORMATION ■...
  • Page 30 6.5. OPTIONAL SET OPTIONAL SET menu contents as following: 1. SILENT MODE 2. HOLIDAY 3. BACKUP HEATER 4. MANUAL DEFROST 6.5.1 SILENT MODE The SILENT MODE is used to decrease the sound of the unit. However, it also decreases the heating/cooling capacity of the system.
  • Page 31 MYCOND BEEHEAT HEAT PUMP 6.5.2 Holiday If the holiday away mode is activated, " " icon will display on the home page. The holiday function is used to prevent frozen in the winter during the outside holiday, and return the unit before the end of the holiday.
  • Page 32 6.5.3 BACKUP HEATER The BACKUP HEATER function is used to force to turn on the internal heater, AHS or WTH. Go to " " » "OPTIONAL SET" »"BACKUP HEATER", Press " ". The following page will appear: OPTIONAL SET BACKUP SILENT MANUAL HOLIDAY...
  • Page 33 MYCOND BEEHEAT HEAT PUMP 6.5.4 MANUAL DEFROST The MANUAL DEFROST function is used to force the unit to defrost when the unit operates in heat or DHW mode in winter. Go to " " » "OPTIONAL SET" »"MANUAL DEFROST", Press " ". The following page will appear:...
  • Page 34 6.6. SERVICE GUIDE 6.6.1 About SERVICE GUIDE Service guide menu contents as following: 1. DISPLAY 2. FAULT CODE 3. CLEAR FAULT 6.6.2 How to go to service guide menu Go to " " » "SERVICE GUIDE", Press " ". The DISPLAY function is used to set the interface: SERVICE GUIDE FAULT CLEAR...
  • Page 35 MYCOND BEEHEAT HEAT PUMP Use " " and " " to enter, and then use " ", " ", " " to make a scroll and an adjustment. Fault CODE is used to show the mean of the error or fault code when the error, fault or protection happens.
  • Page 36 CLEAR FAULT is used to clear all the faults or errors. Use " " and " " to enter ° 06-08-2022 10:40 CLEAR FAULT DISPLAY FAULT CODE CLEAR FAULT RECORD Use " ", " ", " " to make a scroll and an adjustment. °...
  • Page 37 MYCOND BEEHEAT HEAT PUMP PARAMETER VIEW 5/12 PARAMETER VIEW 9/12 21 BUS VOLTAGE 0VDC 41 SV3 22 COMP.CURRENT 0.0A 42 FINAL TEMP. TC 0°C 23 PFC TEMP. 0°C 43 SOLAR TEMP. Tso 90°C 24 IPM TEMP. 0°C 44 BUFFER TEMP. TE1 20°C...
  • Page 38 6.8.2 How to go to FUNCTION PARAMETER SET Go to " " » "FUNCTION PARAMETER SET ". Press " ". ■ The FUNCTION PARAMETER SET is used for installer or service engineer. It is NOT intended the home owner alters setting with this menu.
  • Page 39 MYCOND BEEHEAT HEAT PUMP VII. MENU STRUCTURE: OVERVIEW MENU OPERATION MODE SET OPERATION MODE SET HEAT FUNCTION PARAMETRE SET COOL TEMPERATURE PRESET AUTO DHW ADDITIONAL FUNCTION FUNCTION PARAMETER SET OPTIONAL SET 1 GENERAL PARAMETER SCHEDULE 2 DHW MODE SET SERVICE GUIDE...
  • Page 40 Table 4 the environment temperature curve of the low temperature setting for heating ≤ -20 -19 -18 -17 -16 -15 -14 -13 -12 -11 -10 -9 -8 -6 -5 -4 -3 -2 1-SPTc 38 38 38 38 37 37 37 37 37 37 36 36 36 36 36 36 35 35 35 35 2-SPTc 37 37 37 37 36 36 36 36 36 36 35 35 35 35 35 35 34 34 34 34 3-SPTc...
  • Page 41 MYCOND BEEHEAT HEAT PUMP The heating automatic setting curve The automatic setting curve is the ninth curve, this is the calculation: SPTc (Target temp.) SPTch_set1 SPTch_set2 T4_ha1 T4_ha2 State: In the setting the wired controller, if T4_ha2<T4_ha 1, then exchange their value; if SPTch_set1 < SPTch_set2, then exchange their value.
  • Page 42 Table 7 the environment temperature curve of the high temperature setting for cooling -10 ≤ T4 < 15 15 ≤ T4 < 22 22 ≤ T4 < 30 30 ≤ T4 1-SPTc 2-SPTc 3-SPTc 4-SPTc 5-SPTc 6-SPTc 7-SPTc 8-SPTc The cooling automatic setting curve The automatic setting curve is the ninth curve, this is the calculation: SPTc (Target temp.) SPTcc_SET1...
