Summary of Contents for TRI-M ENGINEERING MZ-6SER

  • Page 1 Tri-M Engineering MZ-6SER PC/104 Bus Compatible ZFx86 SBC In Stock Used and in Excellent Condition Open Web Page https://www.artisantg.com/75477-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 MZ-6SER Manual PC/104 bus compatible ZFx86 SBC with six serial ports Manufactured by TRI-M ENGINEERING Engineered Solutions for Embedded Applications Technical Manual P/N: MZ-6SER-MAN-V2 Revision: 24/04/03 TRI-M ENGINEERING 1407 Kebet Way, Unit 100 Port Coquitlam, BC V3C 6L3 Canada http://www.Tri-M.com Tel 604.945.9565...
  • Page 3 This document is for information use only. Tri-M Engineering makes no representations or warranties with respect to the content of this manual and specifically disclaims any implied warranty of merchantability or fitness for any particular purpose. Tri-M Engineering is under no circumstances liable for incidental or consequential damages or related expenses resulting from the use of this product, even if it has been notified of the possibility of such damage.
  • Page 5 MZ-6SER Manual 24/04/2003 Table of contents CHAPTER 1: GENERAL INFORMATION ......................4 ..........................4 ENERAL ESCRIPTION ............................5 PECIFICATIONS ..........................6 MBEDDED EATURES CHAPTER2: INSTALLATION..........................7 & J ....................7 OCATING THE ONNECTORS UMPERS CHAPTER 3: JUMPERS............................10 (JP1)......................10...
  • Page 6 Table 30: I/O Port........................27 Table 31: MZ104+UTIL104 Interface ..................29 List of Figures Figure 1: Connector and Jumper location MZ-6SER top............8 Figure 2: Connector and Jumper location MZ-6SER back ............9 Figure 3: MZ104+UTIL Utility Connector Board ...............29 Tri-M Engineering Tel: 800.665.5600, 604.945.9565...
  • Page 7 GENERAL INFORMATION General Description The MZ-6SER is an embedded system controller measuring just 3.63 inches x 4.86 inches, which incorporates the revolutionary ZFx86 “PC-on-a-chip” processor. The MZ-6SER offers the quickest route of integrating a full x86 AT-compatible computer into your embedded control application.
  • Page 8 MZ-6SER Manual 24/04/2003 Specifications 586 CPU 32-bit CPU core operating at 33Mhz to 128Mhz 8K byte Level 1 cache, write back and write through support Floating point unit PC Core Logic with PCI enhancement 32 bit 33MHz PCI rev 2.1 compliant “Northbridge” and “Southbridge”...
  • Page 9 MZ-6SER Manual 24/04/2003 Solid State Flash Storage Can be supplied with M-System 32Mbyte TSOP Millennium Plus DiskOnChip or Millennium DiskOnChip in byte wide socket. Expansion Bus - ISA PC/104 signals Fully compliant with the PC/104 expansion bus Mechanical/Environmental 3.63 inches x 4.86 inches...
  • Page 10 MZ-6SER Manual 24/04/2003 CHAPTER2: INSTALLATION Locating the Connectors & Jumpers Jumpers on the MZ-6SER are provided to configure the board for different functionality. Table 1: Jumper List Label Function CPU CLOCK MULTIPLIER & PCI CLOCK DIVIDE BIOS WRITE ENABLE WATCH DOG SOURCE...
  • Page 11 MZ-6SER Manual 24/04/2003 Figure 1: Connector and Jumper Location MZ-6SER Top CN16 CN14 CN15 CN1 & CN2 CN13 CN3 & CN4 CN12 CN5 & CN6 JP10 CN11 Tri-M Engineering Tel: 800.665.5600, 604.945.9565 1407 Kebet Way, Unit 100 Fax: 604.945.9566 Port Coquitlam, BC V3C 6L3 E-mail: info@tri-m.com...
  • Page 12 MZ-6SER Manual 24/04/2003 Figure 2: Connector Location MZ-6SER Bottom CN10 CN18 CN17 Tri-M Engineering Tel: 800.665.5600, 604.945.9565 1407 Kebet Way, Unit 100 Fax: 604.945.9566 Port Coquitlam, BC V3C 6L3 E-mail: info@tri-m.com Canada Web site: www.tri-m.com...
  • Page 13 JUMPERS Clock Multiplier select (JP1) The clock multiplier selection jumper sets the clock frequency multiplier for the MZ-6SER core. Each setting will put the MZ-6SER core at a different operating speed. The CPU operating speed is determined by the CPU clock (33MHz or 64MHz) multiplied by the CPU frequency ratio.
  • Page 14 Watchdog Timer (JP3) The MZ-6SER has two watchdog timers, WD1 and WD2. Both timers are programmable. WD1 counter expires in 2 seconds and WD2 in 7ms. WD2 starts counting down after WD1 expires. When WD2 counter reaches zero, it will unconditionally cause a system reset.
  • Page 15 Disable watchdog Note: The watchdog timer is not enabled at power up by the BIOS. Therefore, the position of the jumper at CN16 does not affect the operation of the MZ-6SER. Master /Slave Mode Select (JP4) JP4 configures the compact flash device inserted into CN18 either as a master or slave IDE device.
  • Page 16 MZ-6SER Manual 24/04/2003 CPU Core Voltage Select (JP6) At a CPU speed of 128 MHz, the core voltage must be set for 2.75 volts. At frequencies below 128 MHz, the core voltage should be lowered to conserve power, and to reduce the dissipated heat.
  • Page 17 3.11 BUR/Boot ROM Select (JP10) JP10 allows the MZ-6SER to boot from standard BIOS or BUR. If boot ROM mode is selected, the MZ-6SER will startup normally by executing the BIOS code and transfer control to a boot device. If BUR mode is selected, the MZ-6SER will execute the BUR code to update the flash BIOS using the Z-Tag interface.
  • Page 18 CN17 Compact flash connector CN18 Note: Pin-1 of each connector on the MZ-6SER is designated by a small white dot on the PCB. Pin-1 on the connector should line up with pin-1 of the corresponding mating connector on the cable.
  • Page 19 MZ-6SER Manual 24/04/2003 an automatic power down mode that turns off the driver outputs. This occurs whenever there isn't a valid signal level on any of the receive pins on the driver chip. Serial port one and Serial port two can be disabled using BIOS SETUP. The IOCS (I/O chip select) signals the quad UART uses for Serial ports 3 to 6 can be disabled through the BIOS SETUP.
  • Page 20 References to DB-9 connectors are for cross-reference only since they are not present on the MZ-6SER but only at the end of an attached cable. The connector description of DB-9 is used in this manual for clarity even though the correct technical term is DE-9. The second letter of DE-9 designates the shell size (per EIA standard).
  • Page 21 MZ-6SER Manual 24/04/2003 Table 16: RS485 Serial Connector (CN7) for Half Duplex Mode Pin# Signal Function Input/Output TR1A 100 ohm termination resistor 1 TR1B 100 ohm termination resistor 1 CMD6+ Serial 6 RS-422 Data + Input/Output CMD6- Serial 6 RS-422 Data -...
  • Page 22 • Watchdog trigger source • Hardware reset • Hard drive LED The MZ104+UTIL card supports the flat ribbon cable from the MZ-6SER card. This provides an easy and quick method to connect to the external "utility" devices to the MZ-6SER.
  • Page 23 The Z-Tag Dongle, part number ZFx86DONGLE-1, is available from Tri-M Systems. USB 1,2 Connector (CN11) The MZ-6SER provides two USB (Universal Serial BUS) interfaces, which give complete plug and play, for external devices. Table 20: USB 1,2 Connector (CN11)
  • Page 24 24/04/2003 IDE Interface (CN12) The MZ-6SER has a PCI bus mastering ATA-4 compatible IDE controller. The IDE controller supports Ultra DMA, Multi-word DMA, and all Programmed I/O (PIO) modes. Up to two drives can be connected, in a master-slave arrangement. Generally, the first hard disk drive (master) will appear as C drive.
  • Page 25 24/04/2003 Parallel (CN13) The MZ-6SER parallel port is fully compatible with the PC/AT parallel port. In the extended mode, it functions as a PS/2-like bi-directional port. In Extended Capabilities Port (ECP) mode, it is IEEE 1284 compliant, including level 2...
  • Page 26 MZ-6SER Manual 24/04/2003 PC/104 connectors (CN14, AND CN15) CN14 and CN15 allow PC/104 expansion modules to be added the MZ-6SER. All data, address and control signals are able to sink 10mA and source 8mA. Table 25: PC/104 8bit Connector (CN14)
  • Page 27 SD15 External Power (CN16) The MZ-6SER can be powered by supplying 5VDC and common to CN4. Alternatively, the MZ-6SER can be powered by supplying 5VDC through the 16-bit PC104 connector (CN14 & CN15) with a PC/104 power supply such as the Tri-M Engineering HE104 or HESC-104.
  • Page 28 MZ-6SER Manual 24/04/2003 4.10 CMOS & RTC Battery Holder (CN17) A lithium battery, model CR2032 is used to maintain the RTC (real time clock) operation when +5VDC main power is removed. The battery can be inserted into battery holder CN17 or it can be connected to the utility connector CN8.
  • Page 29 24/04/2003 4.12 Interrupt and I/O Port assignments Table 29: IRQ Interrupt IRQ Number MZ-6SER Assignment Systems timer (not available for other devices) Keyboard controller (not available for other devices) Second PIC cascade (not available for other devices) Serial port two (COM2:)
  • Page 30 MZ-6SER Manual 24/04/2003 Table 30: I/O Port I/O Address Hardware DMA Controller 0000 - 000F 0020 - 0021 Motherboard Resources 0022 - 0021 System Timer 0040 - 0043 Keyboard 0060 - 0060 Systems Speaker 0061 - 0061 Keyboard 0064 - 0064...
  • Page 31 For details about how to set the various parameters using SETUP, please refer to the MachZ BIOS Users Manual Supplement and the Phoenix BIOS 4.0 Rev 6 manual. Customizing BIOS CMOS default The CMOS default settings of the MZ-6SER can be customized by using the ZEB and AMDFLASH utilities from ZFMicro. www.zflinux.com The ZEB utility allows the majority of the CMOS parameters to be set to a particular value which become the default settings when the MZ-6SER is powered up.
  • Page 32 GPS receiver, the Utility Board also acts as carrier board to mate with several models of Royaltek GPS receivers available from Tri-M Systems. The MZ104+UTIL interfaces to the MZ-6SER CPU module via three ribbon cables and one flex-foil cable. The MZ104+UTIL can be mounted above the MZ-6SER with PC/104 stand offs.
  • Page 33 MZ-6SER Manual 24/04/2003 APPENDIX 2: LITERATURE REFERENCES The following references are for information about the PC/104 architecture, the PC DOS, and the PC BIOS. ISA System Architecture DiskOnChip MindShare, Inc., Tom Shanley and Don M-Systems Corp Anderson 8371 Central Avenue Suite A Internet: mindshar@interserv.com...
