Page 1
EXR-D WATER HEATER Installation & Operation Manual Water is essential to life. And Essency brings water to your life in amazing ways. We design water heaters built to outlast other tanks. Water heaters intelligent enough to give you greater control and peace-of-mind. All while delivering the highest performance in the industry in a design that’s both aesthetically appealing and...
Page 2
In this box, you will find : 1. Your Essency EXR or EXR-D water heater. The EXR-D has an additional CTA-2045 port available compared to the EXR. This port allows to connect to the electric grid to optimize energy usage and savings.
Page 3
CONGRATULATIONS! By purchasing an Essency EXR Water Heater, you have chosen the most innovative technology in domestic water heating on the market. Once properly installed, you can relax and enjoy many years of trouble-free service. Thanks to their innovative design, Essency water heaters offer a much longer life span than traditional water heaters, as well as superior performance for optimal user comfort.
Page 4
TABLE OF CONTENTS SAFETY INFORMATION General Information ............5 Important Safety Precautions ..........7 Transportation & Storage (At Warehouse) ....... 9 Water Quality ............... 9 INSTALLING THE WATER HEATER Location and Specifics ............10 Seasonal Dwellings............... 11 1. Connecting the Battery ..........13 2.
Page 5
DO NOT install any damaged components. If damage is evident, please contact the supplier where the water heater was purchased or the manufacturer listed on the rating plate for replacement parts. Once installed, DO NOT return to wholesaler. Professional installers should contact Essency for troubleshooting according to warranty terms.
Page 6
This device must be professionally installed. Your water heater is FCC compliant. This equipment complies with FCC’s radiation Essency is not responsible for any changes or exposure limits set forth for an uncontrolled modifications not expressly approved by the party environment under the following conditions : responsible for compliance.
Page 7
IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this water heater. WATER TEMPERATURE SETTING DANGER! Safety and energy conservation are important factors to be considered when selecting the water temperature setting of your water heater. Water temperatures above 125°F, and above 120°F for households with small children, disabled, or elderly persons, can cause severe burns or death from scalding.
Page 8
• DO NOT attempt to repair or replace any part of your water heater unless it is specifically recommended in this manual or advised to you by an Essency representative. All other servicing should be referred to a profesionnal service contractor.
Page 9
TRANSPORTATION & STORAGE (AT WAREHOUSE) Do not lift or carry using the front bottom part of the water heater. The water heater should be stored in a dry place, and at a temperature between 32°F and 140°F. In case the water heater is stored without its packaging, the floor’s slope should be less than 7°...
Page 10
In case of any doubt or you have tighter clearances, LOCATION & WATER please check your local codes or contact Essency. HEATER CLEARANCE NOTICE: Please be aware that installation of the Locate the water heater in a clean dry area as near...
Page 11
CAUTION! Make certain the floor underneath the Essency manufactures a custom fit drain pan. water heater is : NOTICE: We recommend the use of a drain pan, • strong enough to sufficiently support the weight especially if the water heater is installed in the attic.
Page 12
INSULATION BLANKETS Insulation blankets, available to the general public, for external use on electric water heaters are not necessary. The purpose of an insulation blanket is to reduce the standby heat loss encountered with storage tank heaters. This water heater meets or exceeds the National Appliance Energy Conservation Act standards with respect to insulation and standby loss requirements making an insulation blanket unnecessary.
Page 13
1. CONNECTING THE BATTERY As a back-up in case of power failure, the water heater is equipped with a lithium-ion battery located behind the lower cover of the unit. To connect this battery, before powering the unit, follow the steps as indicated on the illustration below: 1) Unscrew the 4 screws 2) Remove the cover...
Page 14
2. CONNECTING THE WATER SUPPLY 2.1. TYPICAL INSTALLATION Electrical junction box To electric distribution panel (Use only copper conductor) Hot water outlet to fixture Overflow line to suitable open drain Shutoff valve Service valve Union Service valve Union To cold water supply Touchscreen Shutoff valve Upper element access panel...
Page 15
T/P VALVE Unlike other tank water heaters, the water in the tank of the Essency EXR is at atmospheric pressure. Per its construction, UL has evaluated that this water heater does not need a T/P valve. However please refer to your local codes for specific local requirements (See Recirculation Section for exceptions page 16).
Page 16
If you don’t have another way of confirming flow rate delivered by the recirculation pump, the EXR’s touchscreen does have the capability of displaying real-time flow rate by following the instructions in the Useful tips section (see page 38).
Page 17
In addition to the guidelines above, installers must follow all applicable codes and recirculation pump manufacturer instructions. For the unit to refill properly and to avoid unwanted alarms, the recirculation pump must be programmed to shut off at least once per day. Recirculation pumps designed for systems without a dedicated return line typically generate lower flow rates.
Page 18
3. ELECTRICAL CONNECTION We require that you contact a fully licensed plumbing or electrical professional for the electrical installation of the water heater. A separate branch circuit with copper conductors, overcurrent protective device and suitable disconnecting means must be provided by a qualified electrician. All wiring must conform to local codes or latest edition of National Electrical Code ANSI/NFPA 70.
Page 19
SINGLE PHASE WIRING WARNING: Poor wiring connections, incorrect wire size/type, or wires with too much tension may result in loss of conductivity or overheating. Take special care that wire jacket is securely connected with proper means of strain relief before connecting ground and phase wires. Confirm wire connection tabs are securely closed, tight, and secure before installing junction box cover or turning on power.
Page 20
B. Off-Peak This configuration is for Off-Peak installations and ensures a minimum hot water capacity at any time and a full capacity when Off-Peak is powered. Upper and lower heating elements are wired separately. Ph 1 - 208VAC/240VAC - 19A. Phase 1 to heating elements (T02), electronic control (T01) and CTA module (T08).
Page 21
“Fill” will appear again. Restart step 4 to resume filling the unit. NOTICE: Unlike traditional storage water heaters, the Essency water heater doesn’t require to open any hot water fixture for the filling process. Opening the cold water supply shutoff valve is sufficient.
Page 22
5. Follow the instructions from the app. TIP: For tutorials and instructions please visit our website www.essencyhome.com. TIP: The yellow Energy Guide label is easily removable. During the installation, or later, don't hesitate to remove it so that your Essency water heater will look even better!
Page 23
Your water heater makes sure CTA-2045 goal is fulfilled while ensuring hot water when needed. I HAVE AN EXR-D Your water heater is ready to be connected using its existing CTA-2045 port, please contact your electric utility to provide a UCM (Universal Control Module). Further instructions will be provided by the utility.
Page 24
INSTALLATION CHECKLIST A. Water Heater Location Close to area of heated water demand. Indoors and protected from freezing temperatures. Area free of flammable vapors. Provisions made to protect area from water damage. Meets requirements in location and water heater clearance section. ...
Page 25
GENERAL PRINCIPLE OF OPERATION HOW DOES IT WORK? Your EXR is the first water heater of its kind: it brings you the advantages of tankless combined with a tank: that’s how we achieve performance and durability. Your Essency water heater works a bit differently from other water heaters: you are not consuming the 55 gallons of water that are stored in the tank, but this “static water”...
Page 26
SCHEMATIC DIAGRAM : Hot water Cold water line line Control Filling valve unit Float switch Upper heating element Internal pump Static water Lower heating Plate heat element exchanger Cooled water...
Page 27
1. Software updates are done automatically, provided that your water heater is connected to a WiFi network, and you have downloaded the Essency App on your smartphone or tablet. Every time a software update has taken place, you will be notified via the App.
Page 28
TOUCHSCREEN Installers: before you install your first unit, we highly recommend familiarizing yourself with the Fig 1. Status Indicator touchscreen. We've built a comprehensive tool, called the 'Touchscreen Simulator', which simulates The color of the banner indicates the heating mode the physical touchscreen very accurately.
Page 29
CAPACITY INDICATOR The Essency EXR is equipped with two heating elements, one at the bottom of the tank and one at the top, that operate independently. When the water heater starts cold, it will always start by switching on the upper element first, so as to ensure that hot water is available as quickly as possible.
Page 30
SCREENSAVER AND HOMEPAGE Home Screen Inactive State (Confirm) Press the button to activate the screen Home Screen Active State SMART...
Page 31
SETTING THE WATER TEMPERATURE To set the temperature, use the + and – buttons on the touchscreen until the desired temperature is SMART shown, and press the “confirm” button. To set the temperature, press and hold the button. Once the temperature indication flashes, press button to decrease the temperature OR press the button to increase the temperature.
Page 32
HEATING MODES TO SELECT A HEATING MODE: SMART This is the default mode in which the water heater operates. In Smart mode the electronic control HEAT+ CUSTOM SMART system will automatically manage the 2 heating elements, according to the quantity of hot water used, so as to optimize delivery and consume the least amount of energy.
Page 33
TEMPORARY FUNCTIONS The water heater features a number of temporary functions (also available in the App), which allow you to temporarily override the active heating mode for a selected period of time. At the end of the selected period of time, the water heater will return automatically to the initial setting. A temporary function can be interrupted at any time before the end of the selected period by selecting OFF.
Page 34
OFF. To do so, press the button until OFF is (Confirm) displayed. Then press the button. TIP: We highly recommend to use the Essency App to program the Vacation function with a better accuracy (date to date).
Page 35
WATER SAVER This function is intended to limit the time spent in the shower by an overly indulgent user. It was SMART specifically designed for parents of teenagers, to act like a remote control to turn off the hot water if they’re spending too much time in the shower.
Page 36
PARAMETER SETTINGS (Multi Function) button for 2 seconds (1). To explore the useful menus, make a long press on the (Confirm) You can navigate through the menus described below by using button, validate with the (Multi Function) button, and go back with short tap on the button.
Page 37
The functions, sensors and actuators available are the following : : Domestic Cold Water Temperature (DCWT) : Internal Pump Command (%) : Domestic Hot Water Temperature (DHWT1) : Lower Level Sensor : Domestic Hot Water Temperature (DHWT2) : Upper Level Sensor : Static Hot Water Temperature (SHWT) : Status of the filling valve : Static Hot Water Temperature Lower (SHWTL)
Page 38
3. Scroll with to Connection (highly recommended at the unit ). (Confirm). installation) or pair the unit to your 4. Scroll with to On ( ) or Essency account and use all the Off ( features of the MyEssency App.
Page 39
FEATURE PATH WHY? 1. From the home page, long tap on (Multi Function) button. • In case of software issue or if you Checking Current 2. Scroll with to Settings want to get the documentation in ). (Confirm). Software Version relation with your software version.
Page 40
MYESSENCY CLIENT APP 1. MANUALLY REFILL YOUR WATER Thanks to the MyEssency App, it is possible to control one or several Essency water heaters from HEATER AFTER MAINTENANCE your smart phone. During the life of the water heater there may be...
Page 41
CARE AND CLEANING CAUTION! Shut off power to the water heater before draining your unit. DANGER! Before manually operating the drain valve, make certain no one will be exposed to the hot water released by the valve. The water drained from the tank may be hot enough to present a scald hazard and should be directed to a suitable drain to prevent injury or damage.
Page 42
FLUSHING THE WATER HEATER Based on your water conditions, the heat exchanger may need to be flushed. Contact Essency for more information. Save time and money by installing service valves in outlet and inlet water circuits of the water heater.
Page 43
When installed properly and operated in normal Inherent to the design of the EXR, condensation standard conditions, your water heater will require may also form during normal operation (heavy water very little periodic maintenance.
Page 44
To display this alarm, perform a short push on the confirm button from the homepage. TIP: With the alarm number you can have detailed information and self-diagnose your water heater using the step-by-step Troubleshooting Tool on our website https://essencyhome.com/troubleshooting-guide-exr/. WARNING CODE EXPLANATION...
Page 45
WARNING CODE EXPLANATION WHAT TO DO • Check that the shutoff valves are open. No flow has been detected • Wait for 10 minutes before attempting during a filling or a water a new filling in case the filling valve adjustment.
Page 46
PROBLEM POSSIBLE CAUSES WHAT TO DO The temperature set point may • See Setting the temperature section page 31. be set too low. • In case of very hard water, the heat exchanger of Not enough The heat exchanger is scaled. your water heater may need to be descaled or no hot water (see page 42).
Page 47
CAUTION! The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not disassemble, heat above 160°F, or incinerate. Replace battery with Essency original part only (refer to our website for the service part list). Use of another battery may present a risk of fire or explosion.
Page 48
SERVICE LOG Please record any replacement of components below to allow proper tracking of the water heater status. DATE PART NUMBER OBSERVATION...
Page 49
WIRING DIAGRAM This water heater is wired as indicated in the schematic below. θ θ CTA1 CTA2 CTA3 CTA1 CTA2 CTA3 HMI_5V ON/OFF GND OPWM GND SCT GND GND AIN_PWR AIN10V GND CAN_H CAN_L SHWTL DHWT2 DCWT DHWT1 +VDC +VDC UART1 UART2...
Page 50
When contacting the manufacturer, the following information will be requested: 5. Repair any leaks as soon as identified: Essency has a leak detector, which will alert you in case of • Model and serial number of the water heater as...
