Summary of Contents for Montezuma EasyStream
- Page 1 EasyStream Audio Encoder 28608 12 Rd Montezuma, KS 67867 www.montezumasound.com...
- Page 2 EasyListen Table of Contents Part I Introduction Part II Unpacking your EasyStream Part III Obtaining Support Part IV Hardware 1 Front Panel ......................... 2 2 Rear Panel Connections ..................... 3 Part V Settings 1 Home Page ......................... 3 2 Player ..........................5 3 Streaming ...........................
- Page 3 Listentochurch.com. Unpacking your EasyStream Your EasyStream includes a 5VDC power supply with a USA style plug. Make sure you use the included power supply. Plug the power supply into an existing outlet to power up the EasyStream. The EasyStream should turn on within several seconds.
- Page 4 Connect + on the EasyStream Out to + on the input of the connected device. · Connect the ground and - on the EasyStream Out to the ground on the input of the connected device. Note: The line level input cannot handle a speaker level signal. DO NOT plug a speaker level input into the EasyStream.
- Page 5 Player status show the status of the audio player. Audio remaining shows the amount of buffer left in the audio player. Audio Peak displays the peak level of the EasyStream input. Audio Level displays the average level of the EasyStream input.
- Page 6 EasyListen 5.2 Player The Player page is used to program playlists into your EasyStream. Press Edit to add a stream to your player or to change an existing stream. Add the Url in the format shown. © 2020 Montezuma Sound...
- Page 7 Settings © 2020 Montezuma Sound...
- Page 8 SymNet: The stream will be controlled by a DSP as configured on the page. · Audio Level SymNet: Stream will be controlled by a DSP but will also auto start based on the Stream dB start level setting. © 2020 Montezuma Sound...
- Page 9 Settings Stream stop delay (S): The amount of time in seconds before the stream disconnects after the audio level has dropped below the Stream dB start level. © 2020 Montezuma Sound...
- Page 10 Input volume dB-+: Increase this value to increase the sensitivity of the input. This is useful if the output of the signal feeding the EasyStream is too low. Try to target a Peak of between 12 dB and 15 dB on the status page.
- Page 11 Settings Output test: Sends a test tone on the output of the EasyStream for testing purposes. © 2020 Montezuma Sound...
- Page 12 EasyListen 5.5 DSP The EasyStream is capable of being controlled from a Symetrix or Q-Sys digital signal processor (DSP). Use the settings on the DSP page to configure the DSP control communication. You will need to configure the DSP as well. Contact Montezuma Sound for details.
- Page 13 Settings 5.6 Scope Use the Scope to see a visual of the EasyStream input. © 2020 Montezuma Sound...
- Page 14 EasyListen 5.7 Services Firmware updates are handled on the Services page. Only make changes to this page if you are certain you understand what you are doing. © 2020 Montezuma Sound...
- Page 15 Montezuma Sound will not pay for warranty services performed by a non-authorized repair agent. To return a unit under warranty, pack the EasyStream in the the original packaging or using other proper packaging methods and send to Montezuma Sound, 28608 12 Rd, Montezuma, KS 67867.
