ASSEMBLY INSTRUCTIONS
64650–64652 – Pop-up Tent 4 x 4 m with Mosquito Net
Scope of delivery
A – Large canopy – 1×
B – Small canopy – 1×
C – Frame – 1×
D – Bag – 1×
E – Mosquito net – 1×
F – Tent pegs – 1×
G – Hex wrench (only for maintenance) – 1×
H – Rope – 4×
D – Weight bag – 4×
Assembly
© by WilTec Wildanger Technik GmbH
Item 64650–64651
Page 1
http://www.wiltec.de
11 2024-1
Advertisement
Summary of Contents for WilTec 64650
- Page 1 ASSEMBLY INSTRUCTIONS 64650–64652 – Pop-up Tent 4 x 4 m with Mosquito Net Scope of delivery A – Large canopy – 1× B – Small canopy – 1× C – Frame – 1× D – Bag – 1× E – Mosquito net – 1×...
-
Page 2: Step 1 - Opening The Frame
TIPS: Lift the frame slightly while pushing the roof connector upwards. Press the connection point upwards with both hands. © by WilTec Wildanger Technik GmbH Item 64650–64651 Page 2 http://www.wiltec.de... -
Page 3: Step 4 - Adjust The Height
Attach the tensioning ropes to these pegs. Tension the ropes using the plastic plates provided TIPS: Always secure the gazebo with the tensioning ropes and pegs. © by WilTec Wildanger Technik GmbH Item 64650–64651 Page 3 http://www.wiltec.de... - Page 4 Step 1 – REMOVING THE MOSQUITO NET Open one zip of the mosquito net (E). Go under the canopy and detach the plastic hooks from the frame (C) to remove the net. © by WilTec Wildanger Technik GmbH Item 64650–64651 Page 4 http://www.wiltec.de...
- Page 5 Press the red button on the bar and retract the frame completely. Raise the gazebo 5–8 cm and push it together from both sides until the frame is completely folded. © by WilTec Wildanger Technik GmbH Item 64650–64651 Page 5 http://www.wiltec.de...
- Page 6 Loosen the belts and insert the red plugs into the openings on the rollers. Pull the belts tight by pulling the belt loop downwards. © by WilTec Wildanger Technik GmbH Item 64650–64651 Page 6 http://www.wiltec.de...
- Page 7 Letter Part Letter Part Middle bar Bolt set M5 (A) Roof connector Bolt set M5 (clips) Leg connector Bolt set M4 Sliding connector Bolt set M5 (B) © by WilTec Wildanger Technik GmbH Item 64650–64651 Page 7 http://www.wiltec.de 11 2024-1...
- Page 8 Gazebo legs with roller (right side) Gazebo legs without roller Important note: Reproduction and any commercial use (of parts) of this operating manual, requires a written permis- sion of WilTec Wildanger Technik GmbH. © by WilTec Wildanger Technik GmbH Item 64650–64651 Page 8 http://www.wiltec.de...
