Serial numbers:
600 Series
202X-XX-DUO600-XXXX
202X-XX-DUO600S-XXXX
202X-XX-IC600-XXXX
2X-XX-DUO600FC-XXXX
2X-XX-DUO600FCS-XXXX
Cantaloupe Inc.
Connecting and first startup
600 IC* / DUO / DUO FLEX
700 IC* / DUO / DUO FLEX
850 IC* / DUO / DUO FLEX
700 Series
202X-XX-DUO700-XXXX
202X-XX-DUO700S-XXXX
202X-XX-IC700-XXXX
202X-XX-700SC-XXXX
2X-XX-700FCR-XXXX
2X-XX-700SC-XXXX
2X-XX-DUO700FC-XXXX
2X-XX-DUO700FCS-XXX
850 Series
202X-XX-DUO850-XXXX
202X-XX-DUO850S-XXXX
202X-XX-IC850-XXXX
202X-XX-850SC-XXXX
2X-XX-850FCR-XXXX
2X-XX-850SC-XXXX
2X-XX-DUO850FC-XXXX
2X-XX-DUO850FCS-XXXX
Advertisement
Summary of Contents for cantaloupe 600 IC
- Page 1 Cantaloupe Inc. Connecting and first startup 600 IC* / DUO / DUO FLEX 700 IC* / DUO / DUO FLEX 850 IC* / DUO / DUO FLEX Serial numbers: 600 Series 700 Series 850 Series 202X-XX-DUO600-XXXX 202X-XX-DUO700-XXXX 202X-XX-DUO850-XXXX 202X-XX-DUO600S-XXXX 202X-XX-DUO700S-XXXX...
- Page 2 Warning This appliance is not intended for use by persons (and children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 3 Depicted here is a 850 DUO, however, the middle section is the same for the different cooler models. * For IC (Instant Cooler) that does not have a second cabinett only opening the box to retrieve the power cable and step 1,2,8,9 and 10 are relevant.
- Page 4 The keys to open the box are taped to the back of the box, as depicted above. Unlock the box to find the cables located in the area as indicated in the circle. Once removed the box can then be closed again. When opening the box in the future please make sure to turn off the UPS and then pull out the power cord connected to the wall outlet.
- Page 5 1*. Connect the power cable meant for an outlet into the back of the box as depicted 2*. If using wired Internet, connect an ethernet cable into the Ethernet port marked with a 2 on the image above. (Connected to the WAN port in the router). If using a SIM card in the router ignore this step) 3.
- Page 6 5. Connect the power cable into the secondary unit as depicted above. If setting up a flex unit also plug these into the remaining units. 6. Connect the ethernet cable into the secondary unit as depicted above. If setting up a flex unit also plug these into the remaining units.
- Page 7 7. Plug the power cable from the technology box and the cooler(s). Then proceed to push the secondary unit into position with the back facing a wall or into a custom built enclosure to ensure that the back of the fridge is not exposed to customers. If setting up a Flex unit push the remaining secondary units into place.
- Page 8 8.* Push the main cabinett into place (the one containing the box with the computer inside it. 9*. Open the metal hatch at the front. * is an applicable step for IC single units...
- Page 9 10*. Press and hold the round button on the UPS (as depicted above) until the long beep is done (takes roughly 1-2 seconds). The computer will now boot up and the machine is ready to be calibrated and used. * is an applicable step for IC single units...
- Page 10 First Start Up When starting up a cooler, one of two things can happen depending on if the cooler has received a KioskID yet or not. If the vending interface loads up then the kiosk is already set up with a KioskID and we can continue down to the setup phase. Otherwise lets continue with setting up kioskID with the help of a kiosk reference set up in the Instant backend by an administrator for the kiosk network.
- Page 11 Setting up the kiosk To get the kiosk up and running now it needs to be calibrated and then have products assigned to the different slots inside the unit(s). To understand the setup steps, especially Shelf Calibration, Test System and Setup Inventory, one can view short videos showing those steps by going to https://instantsystems.se/support/instant-cooler/ (if prompted for a password enter...
- Page 12 A slot needs to be enabled for it to be possible to calibrate and setup inventories on it. If you have enabled a slot that does not exist, simply click it and uncheck the checkbox for Slot Enabled for that particular one. Calibrate the kiosk Go to Calibrate Shelves section by clicking on it in the menu to the left while logged in as a technician.
- Page 13 shelf. Press SKIP CELL if a letter (D) (for instance) is not present on that shelf. Then press FINISH. Repeat this calibration for all the shelves in the units placed at this location. Control the calibration – Test System Chose Test System in the menu to the left when logged in as a techinician, press ALL and then press CLEAR Place the same weight used for calibration on all shelves and check if the reading is correct (a few percentage up or down difference from the calibration weight is ok for...
- Page 14 When the system says STABLE add a product to the slot, wait until it says STABLE again and press the ADD button. When it's STABLE, add a second product (while leaving the first one on the slot), wait for it to become STABLE and press ADD. Recommended doing this for a number (minimum 3) products to get a good average value.
- Page 15 Once all slots have been set up log out from the technician interface and the machine is ready to vend to it's customers.
