MAS003876 MCL 24-35
Circular Letter
FROM: Maserati TSO
TO: Maserati Network
Introduction to Maserati Folgore
DATE: JULY 10 2024
Maserati is an innovative brand by nature, with a unique style fuelled by inexhaustible passion. These
values inspired the Maserati brothers almost 109 years ago and are still driving us today to play a
leading role on the e-mobility world stage. With a unique blend of tradition and innovation, Maserati
is ready to launch Folgore, the new 100% electric range.
Please read and review this bulletin first before ordering parts and/or starting the procedure.
Contact your Regional AfterSales Manager (RAM) or the Technical Support Helpdesk if you have any
questions.
Thank You for your continued support and cooperation.
Maserati North America
Aftersales Dept.
© 2024 Maserati North
America. Aftersales
www.maseratiusa.com
All rights reserved. Reproduction or translation in
whole or in part is not permitted without
MAS003876
authorization from the publisher. Printed in USA
Page 1 of 23
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Maserati Folgore 2024
Summary of Contents for Maserati Folgore 2024
- Page 1 Maserati is an innovative brand by nature, with a unique style fuelled by inexhaustible passion. These values inspired the Maserati brothers almost 109 years ago and are still driving us today to play a leading role on the e-mobility world stage. With a unique blend of tradition and innovation, Maserati is ready to launch Folgore, the new 100% electric range.
- Page 2 High-voltage system overview ....................... 3 Service requirements ........................7 Training courses and workshop personnel ..................8 Securing the vehicle........................8 Activation of the Maserati Technical Team ................... 9 Warranty Conditions ........................9 7.1. Circular Economy – Refurbished batteries ................9 Vehicle and new spare batteries acceptance ................
- Page 3 1. Folgore vehicle description The Maserati Folgore are 100% battery electric vehicles, also known as BEVs. They are powered by the energy stored in the battery, which is used by the electric motors for vehicle propulsion. Differently from an internal combustion engine that burns fossil fuels and produces polluting exhaust gases, the Folgore vehicles are zero- emission.
- Page 4 The battery must always be in a well-defined temperature range to operate correctly. New GranTurismo ECH Grecale ECH1 & ECH2 Page 4 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com MAS003876 authorization from the publisher.
- Page 5 On-Board Charger Module (OBCM): It is the high-voltage AC/DC converter, it converts AC from the electric grid into high-voltage DC to charge the battery pack. It only works for AC charging. Page 5 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 6 In this eventuality, an external 12V power source will be needed to start the charging phase and restore normal vehicle functionality. Page 6 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 7 Figure 4.1: A= distance from unauthorised personnel. B= distance from other vehicles, structures, or flammable components. Staff training: The following training is mandatory to be able to manage all aspects of the new Folgore Maserati vehicles and to be able to access the Academy training courses.
- Page 8 (BEVs). The employer is always responsible for complying with local law regarding the training and certification of its personnel working on these systems. It is important to note that Maserati, as an OEM, will not provide such training or certification for dealership personnel.
- Page 9 Service Entry so that it reflects the actual state of the repair. With a view to product improvement, and to allow Maserati to improve the diagnostic effectiveness, you will also need to analyze promptly the defective replaced components.
- Page 10 No specific form is necessary to be filled. The process described above will be mentioned in the Maserati Whitebook; a specific checklist will be published in the Reception Section of the WHITEBOOK will be issued for the purpose;...
- Page 11 Figure 3 – EV Preliminary Checklist for Folgore. The layout can be subject to updates. Page 11 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 12 Please refer to Chapter 6 for any issues encountered during or before the diagnosis phase. Page 12 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 13 Verify how to manage these risks following all local health and environmental safety regulations. Page 13 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 14 Above / Underground Best to have: low profile arms; non-protruding arms end; flat rubber pads Page 14 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 15 Dealers that do not have a compatible lift will have to either buy one or independently assess how to meet the required specifications with the current supplier of the equipment. Page 15 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 16 In case the battery will have to be disposed of, the disposal channel must be used (see paragraph 10.8). Page 16 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 17 This means that when the instrument panel indicator shows 0%, the real state of the battery is higher, to preserve the integrity of the battery. Page 17 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 18 For vehicle lifting operations and the removal of the high-voltage battery, it will be necessary to have a lift compatible with the Folgore vehicles (see paragraph 10.4) and a battery lifter as described in Chapter 14. Page 18 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com...
- Page 19 According to the spare parts management policy, the E- Axle component is considered an assembly under restriction along the whole FEW durations: every intervention on it must be priorly agreed upon and committed to by the Maserati technical team. Management of other high-voltage components All components of the high-voltage system listed below will be managed as an assembly and cannot be repaired at the dealer.
- Page 20 Only to be used for damaged batteries that leak Respiratory protection mask according electrolyte to EN149 Page 20 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com MAS003876 authorization from the publisher.
- Page 21 Safety sticker To demarcate working areas for electric vehicles and batteries Page 21 of 23 © 2024 Maserati North All rights reserved. Reproduction or translation in America. Aftersales whole or in part is not permitted without www.maseratiusa.com MAS003876 authorization from the publisher.
- Page 22 According to the local regulations and the equipment already available in each workshop, please assess whether to buy a generic set of equipment for handling Folgore vehicles and high-voltage batteries. Maserati offers a partnership with a third-party supplier to get the full range of generic insulated tools and workshop alerts/si;...
- Page 23 Each dealership must have a fork adapter with load capacity according to the weight of the Grecale battery. A version validated by Maserati of the fork adapter will soon be available in the workshop equipment catalog.
