IP amplifier AF 20H
20 watts IP amplifier with metal housing for connection to an Intercom Server or SIP server.
Output power: 1 x 20 W at 4 Ω, 2 x 25 W at 8 Ω, 4 x 12.5 W at 16 Ω.
Connection diagram
Cable entry for
expansion module
Power
Uplink
Downlink
+
–
Intercom/
Computer,
24 VDC
PC / Terminals /
SIP Server,
Intercom station,
IP- Kamera
PoE
IP camera
Connection of the loudspeaker
+ – + –
LS
LS
4 Ω
+
-
+
-
LS
LS
Relay
Loudspeaker
+ –
+ –
+ – + –
LS
LS
LS
LS
16 Ω
16 Ω
8 Ω
8 Ω
16 Ω
16 Ω
Dimensions
Measuring units in mm (in), not to scale!
Uplink
Downlink
Mounting
2
1
158.5 (6.24)
1
Install screws and dowels.
2
Break out the mounting opening
on the back side of the housing
and hook onto the screws.
Advertisement
Related Manuals for Commend AF 20H
Summary of Contents for Commend AF 20H
- Page 1 IP amplifier AF 20H Dimensions Measuring units in mm (in), not to scale! 20 watts IP amplifier with metal housing for connection to an Intercom Server or SIP server. Output power: 1 x 20 W at 4 Ω, 2 x 25 W at 8 Ω, 4 x 12.5 W at 16 Ω.
- Page 2 (directive 2011/65/EU) FCC – CAN ICES-3 (A)/NMB-3(A); For the FCC Rules, see “Safety warnings” . • Contact Commend USA: Commend Inc, 63 Ramapo Valley Road, Suite 201, Mahwah, NJ 07430 (New York Area), www.commendusa.com For technical specifications, see the respective data sheet.
- Page 3 IP-Verstärker AF 20H Abmessungen Maße in mm, kein Maßstab! 20-Watt-IP-Verstärker mit Metallgehäuse für den Anschluss an einen Intercom oder SIP-Server. Ausgangsleistung: 1 x 20 W an 4 Ω, 2 x 25 W an 8 Ω, 4 x 12,5 W an 16 Ω.
- Page 4 Wir bemühen uns, unsere Produkte noch besser zu machen. Folgen Sie dem Lautstärke-Einstellungen Link zum Commend-Feedback-Formular und lassen Sie uns wissen, was Sie Die Lautstärke kann im IoIP-Betrieb über CCT 800 und im SIP-Betrieb über das Webinterface, über das denken.
