STEPS TO ASSEMBLE THE LAMPSHADE

Take out the lampshades

and round iron frames.

Align the frame with the edge of the

lampshades and secure it in place using

fasteners. Repeat the process for the

second frame. Ensure that the frames are

firmly attached and the lampshades are

tightly stretched.

For an oblique barrel-shaped

lampshade, align the lamp frame

by placing its short edge on the

corresponding short side of the

lampshade and the long edge

on the corresponding long side.

Install the harps onto the lamp

base by positioning them over the

sockets. Next,insert the bulb into

the socket and rotate it clockwise

until it is securely in place.(bulbs

are notincluded).

Once the lampshade is

positioned correctly, screw the

finial into place to hold it

securely.(lf the lamp shade is

slanted,adjust the base of the

finial to make it level).

MADE IN CHINA

INSTRUCTION MANUAL

T193

Need help?

Do you have a question about the T193 and is the answer not in the manual?

Page 1 STEPS TO ASSEMBLE THE LAMPSHADE Take out the lampshades and round iron frames. T193 Align the frame with the edge of the INSTRUCTION MANUAL lampshades and secure it in place using fasteners. Repeat the process for the second frame. Ensure that the frames are firmly attached and the lampshades are tightly stretched.
Page 2 Applicable bulb type:A19,A60,T45,ST58... (Excluding bulb) Body Lamp socket Saddle Harp 1.Unpack all parts from cartons carefully. 2.During assembly, the power cord should be Shade prevented from twisting. Finial 3.Stuff cord into the lamp socket(B)，then tighten the lamp socket(B)into the body(A) until tight.
