Safety, Operation, Maintenance and Parts
Thoroughly read and understand the content of this manual before using the Allied HPC. The safe and efficient
use of the Allied equipment depends upon proper installation, operation, maintenance and training.
Keep this manual in a convenient location so that it is easily accessible for future reference. Contact your Allied
Dealer or the Allied Customer Service Department for replacement manuals. Inquiries regarding the content of this
manual must include effective date shown on inside cover.
Allied PBS, Allied Attachments Hydraulic Plate Compactor
1
Hydraulic Plate
Compactor
Models:
AC410
AC1216
AC1725
AC3040
