Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with these instructions will result in voiding of the product warranty and may result in personal injury and/
or property damage.
Direct Drive
Upblast Centrifugal Exhaust Fan
These fans are specifically designed
for roof and wall mounted applications.
The maximum continuous operating
temperature for fan sizes 099-300 is 400°F
(204°C) and for fan sizes 060-095 is 130°F
(54°C). Direct drive fans are available with
nominal wheel diameters ranging from 9
to 30 inches (229 to 762 mm) (060-300
unit sizes). Each fan shall bear a permanently affixed
manufacturer's embossed metal nameplate containing
the model number and individual serial number.
General Safety Information
Only qualified personnel should install this fan.
Personnel should have a clear understanding of these
instructions and should be aware of general safety
precautions. Improper installation can result in electric
shock, possible injury due to coming in contact with
moving parts, as well as other potential hazards. Other
considerations may be required if high winds or seismic
activity is present. If more information is needed,
contact a licensed professional engineer before moving
forward.
1. Follow all local electrical and safety codes, as well as
the National Electrical Code (NEC) and the National
Fire Protection Agency (NFPA), where applicable.
Follow the Canadian Electrical Code (CEC) in
Canada.
2. The rotation of the wheel is critical. It must be free
to rotate without striking or rubbing any stationary
objects.
3. Motor must be securely and adequately grounded.
4. Do not spin fan wheel faster than max cataloged fan
RPM. Adjustments to fan speed significantly affects
motor load. If the fan RPM is changed, the motor
current should be checked to make sure it is not
exceeding the motor nameplate amps.
5. Do not allow the power cable to kink or come in
contact with oil, grease, hot surfaces or chemicals.
Replace cord immediately if damaged.
6. Verify that the power source is compatible with the
equipment.
®
Upblast Centrifugal Roof Exhaust
Belt Drive
Upblast Centrifugal Exhaust Fan
These fans are specifically designed for
roof and wall mounted applications. The
maximum continuous operating temperature
is 400°F (204°C). Belt drive fans are available
with nominal wheel diameters ranging
from 10 to 48 inches (254 to 1219 mm)
(099-480 unit sizes). Each fan shall bear
a permanently affixed manufacturer's
embossed metal nameplate containing the model
number and individual serial number.
7. Never open access doors to a duct while the fan is
running.
DANGER
Always disconnect, lock and tag power source before
installing or servicing. Failure to disconnect power
source can result in fire, shock or serious injury.
CAUTION
When servicing the fan, motor may be hot enough
to cause pain or injury. Allow motor to cool before
servicing.
CAUTION
Precaution should be taken in explosive atmospheres.
DANGER
Pour écarter les risques d'incendie, de choc électrique
ou de blessure grave, veiller à toujours débrancher,
verrouiller et étiqueter la source de courant avant
l'installation ou l'entretien.
ATTENTION
Lors de toute intervention sur la soufflante, le moteur
peut être suffisamment chaud pour provoquer une
douleur voire une blessure. Laisser le moteur refroidir
avant toute maintenance.
ATTENTION
Faire preuve de précaution dans les atmosphères
explosives.
Upblast Centrifugal Roof Exhaust
Document 471560
Model CUE Direct Drive
Model CUBE Belt Drive
1
Advertisement
Related Manuals for Greenheck CUE
Summary of Contents for Greenheck CUE
- Page 1 Document 471560 Model CUE Direct Drive Model CUBE Belt Drive ® Upblast Centrifugal Roof Exhaust Installation, Operation and Maintenance Manual Please read and save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions will result in voiding of the product warranty and may result in personal injury and/ or property damage.
- Page 2 Receiving When lifting a unit onto the roof, use either the four lifting points on the drive frame or the two lifting points Upon receiving the product, check to ensure all on the bearing plate if present, see Figure 2 for lifting items are accounted for by referencing the delivery points.
- Page 3 the continuity of the surfaces. Thoroughly wipe clean Indoor ® with Tectyl 506 (Ashland Inc.) or the equivalent. For The ideal environment for the storage of fans and hard to reach internal surfaces or for occasional use, accessories is indoors, above grade, in a low humidity ®...
- Page 4 Installation 8. Connect power supply wiring to the motor as indicated on the motor nameplate or terminal box General Ventilation Installation cover. Check the power source for compatibility with the requirements of your equipment. 9. Check fan wheel for free rotation, recenter if necessary.
- Page 5 Commercial Kitchen Installation 2. Mount the curb or wall bracket to the wall with a minimum of eight 3/8 inch fasteners around the flange. Caulk and flash the curb or wall bracket to ensure a watertight seal. 3. Curb only: If unit is equipped with a backdraft damper, it should be installed now.
- Page 6 Grease Trap Installation The electrical supply must enter the motor compartment through the breather tube and the disconnect must The polypropylene grease trap is designed to collect be mounted outside the fan’s motor compartment. grease residue and avoid drainage onto roof surface. Emergency smoke removal fans may also require an Follow all local codes, as well as the National Fire EN/CF Label...
- Page 7 Curb to Deck Mounting: Fasteners need to be located 2. Wheel position is preset and the unit is test run at on all four sides of the curb, Figures 12a and 12b. the factory. Movement may occur during shipment and realignment may be necessary. Figure 12a Roof Curb Roof Curb...
- Page 8 7. Belt tension can be adjusted by loosening four 3. Start the fan and shut it off immediately to check fasteners on the drive frame, see Figure 17. rotation of the wheel with directional arrow in the The motor plate slides motor compartment, reference Figure 14.
- Page 9 Tapered Bushing Hub Installation Installation and maintenance are to be performed only by qualified personnel who are familiar with local codes and Removal and regulations and who are experienced with this type For wheel hubs and shaft pulleys utilizing a tapered of equipment.
- Page 10 Bushing Installation hand gun rating is 40 psi. Rotate bearings during lubrication where good safety practice permits. 1. Clean all surfaces of hub and bushing to remove any Caution should be employed to prevent over oil or residue present and do not use any lubricant to packing or contamination.
- Page 11 Parts List Each fan bears a manufacturer’s nameplate with model CAUTION number and serial number embossed. This information A fan manufactured with an explosion resistant motor will assist the local representative and the factory in does not certify the entire unit to be explosion proof. providing service and replacement parts.
- Page 12 As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications without notice. Product warranties can be found online at Greenheck.com, either on the specific product page or in the literature section of the website at Greenheck.com/Resources/Library/Literature.
