- Page 1 79952/79953 CONCRETE MIXER 230V~50HZ INSTRUCTION MANUAL SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
- Page 2 SAFETY SAFETY WARNINGS AND PRECAUTIONS Original manual You will need the manual for the safety warnings and precautions, assembly instructions, opening and maintenance procedures, parts list and diagram. Keep your invoice with this manual. Write the invoice number on the inside of the front cover.
- Page 3 SETUP ASSEMBLY Packing diagram Quantity Spare part No. Spare part name Support Beam frame Wheel support Wheel Lower drum with a cross beam Upper drum Blade Seal Steering wheel Pedal Tie rod Fasteners unit Engine unit Manual book...
- Page 4 SETUP Fasteners unit(12) Sub-package details...
- Page 5 SETUP Step 1 As shown in Fig 1, insert the A1 end of beam frame(2) into the A1 end of support(1), and tighten it with 2 screws and 2 nuts in A bag of fasteners unit(12). NOTE: Make sure the support(1) is installed on the side of beam frame(2) with spring seat.
- Page 6 SETUP Step 3 As shown in Fig. 5, 2 people work together to li lower drum with a cross beam(5), insert the A3 and A4 ends of cross beam into the A3 and A4 ends of beam frame(2), then let the drum opening facing up as shown in Fig.
- Page 7 SETUP Step 5 As shown in Fig. 11 and Fig. 12, use 2 screws and 2 nuts in D bag of fasteners unit(12) to fix the smaller ends of 2 blades(7) in lower drum(5). NOTE: ①The screw is inserted into the blade hole from the outside of the drum, and the nut is screwed from the inside of the drum.
- Page 8 SETUP Step 7 As shown in Fig. 15, align the 2 arrows and place upper drum(6) on lower drum(5). Make sure the screws on upper drum(6) are all aligned with the screw holes of lower drum(5), then tighten all the screws as shown in Fig. 16. Suggestion: If there’s screws do not fit into the holes, li the upper drum(6) slightly to adjust.
- Page 9 SETUP Step 9 As shown in Fig. 19, align the groove of steering wheel(9) with the pin of spring seat. Press down and align the 2 holes as shown in Fig. 20. Then use 2 screws in F bag of fasteners unit(12) to fix steering wheel(9) on the small disc of beam frame(2) as shown in Fig.
- Page 10 SETUP Step 10 As shown in Fig. 22, put engine unit(13) on the sha of beam frame(2), Then tighten it with 2 shorter screws and 2 spring washers in G bag of fasteners unit(12) shown as in Fig. 23. Step on the pedal(10), turn the steering wheel(9) to rotate the drums as shown in Fig. 24. Then use 1 longer screw and 1 spring washer in G bag of fasteners unit(12) to fix engine unit(13) as shown in Fig.
- Page 11 SETUP & MAINTENANCE OPERATION 1. Place the Cement Mixer on a solid, even surface. 2. Connect the Power Cord to an electrical outlet(or properly rated extension cord) with a third, ground prong. 3. Add material to the Drum. Typical maximum quantities include:2 gallons water 3 shovels cement, 15 shovels aggregate rock using a size 3 shovels.
- Page 12 SPECIFICATIONS SPECIFICATIONS 79952 79953 Stock No. Drum capacity 145 L 200 L 550W 850W Power Voltage 230V~50Hz 230V~50Hz 42.3 kg 52.5 kg Net weight Motor Speed 2800/min 2800/min Drum speed 29/min 27/min...
- Page 13 PARTS LIST PARTS LIST Part Description Qty. Part Description Qty. Power cord stents tie rod The motor housings Screw M5×12 Pedal Washer M5 stents Nut M5 Lock Nut M8 Switch screw M8×70 Ringφ38 Iron tube fixture washer φ27 Spring washers M8 A tripod Washer M8 wheel...
- Page 14 ASSEMBLY DIAGRAM ASSEMBLY DIAGRAM 17-10 18-19 23-10-28 23-10-28 23-10-9 44-4 44-5 9-10 44-5 10-23 5-19-4...
- Page 15 CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79952/79953 CONCRETE MIXER Complies with the essential health and safety requirements of the following Directices: EC Council Directive 2006/42/EC Machinery Standards and technical specifications referred to:...
- Page 16 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
