Page 1 SH3 Series Hardware Manual...
Page 2: Hardware Manual
Warning: This device has been tested, certified by CE-EMC, and complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the device is operated in a commercial environment.
Page 3: Introduction
Introduction Thank you for purchasing SSZN high-speed camera system "SH3 series" (hereinafter referred to as the System). This manual contains the operating instructions and warnings required to use the System. Before using the System, please read the entire manual. If there are any unclear information in this manual, please contact SSZN using the contact information printed on the back of the manual.
Page 4: Instruction Manual
This chapter provides an overview of warranty.  Chapter 4 - Contact SSZN This chapter lists the contact information that should be used to contact SSZN when there is a system malfunction or when certain parts of the manual are unclear.
Page 5: Symbols
Symbols The symbols used in this manual have the following meanings. Icons / Symbols Description This symbol indicates what should always be read. This symbol indicates instructions that should always be followed when using the software, or things to keep in mind when using the software. This symbol indicates something that requires additional attention when using the system.
Page 6: Safety And Proper Usage Instructions
To avoid harm to yourself and others, as well as damage to property, please carefully follow the following safety precautions. SSZN has given full attention to the security of this system. However, ignoring the content of safety precautions and using this system incorrectly may result in potential losses and injuries, which will be explained below.
Page 7 Warning  Do not do anything that will damage the cable or plug. (Do not damage the cable, do not modify the cable, do not use the cable near the heater, do not excessively bend, twist or pull the cable, do not place heavy objects on the cable, and do not bind the cable).
Page 8 Notes  When cleaning the system or not in use for a long time, be sure to unplug the power cord. Connecting or keeping the system to a power source may cause a fire due to a decrease in insulation performance and discharge. ...
Page 9 Electrostatic discharge (ESD) events may cause direct and irreversible damage to image sensors. Clean the Surface of the Image Sensor Please read the following instructions and be extra careful when cleaning the surface of the image sensor. Always take appropriate anti-static precautions when cleaning or working ...
Page 10: Table Of Contents
AC/DC Adapter ......................... 37 Dimensions ............................38 2.2.1. Dimensions of the Camera ....................... 38 2.2.2. Dimensions of the AC Power Supply Device ................39 Chapter 3 Warranty ............................40 3.1. About Warranty ...........................41 Chapter 4 Contact SSZN ..........................42 4.1. Contact Information ..........................43...
Page 11: Chapter 1 Settings
Chapter 1 Settings This chapter provides an overview of the various components that make up the system.
Page 12: The Components And Accessories Of The System
1.1. The Components and Accessories of the System 1.2.1. Components Please refer to the attached packaging list for the standard components and accessories of this product. This system does not include a lens. 1.2.2. Accessories The system has the following accessories. 1.
Page 13: Component Name
1.2. Component Name The system consists of components such as the camera, power adapter, and SSZN FastPhoto control software. Cautions for camera and AC power adapter Do not expose the camera, AC power adapter, and other optional  components to impact.
Page 14: Name Of Camera Parts
Lens E mount 1.2.2 Name of Camera Parts Front Status indicator Ethernet interface I/O Interface Power interface Back...
Page 15: Accessory Lens Mount Adapter
1.2.3 Accessory Lens Mount Adapter The lens of this camera has an E-mount, and the lens mount on the interface camera can use an adapter (such as E-to-F or E-to-C mount) according to the shooting purpose. F-E Mount Adapter...
Page 16: The Status Indicator Led On The Back Of The Camera
1.2.4 The Status Indicator LED on the Back of the Camera There are three indicator LEDs behind the camera. These LEDs display the status of the camera. Function LED Behavior Status POWER Power on (Power Input voltage too low or faulty supply) Connected network cable (Ethernet)
Page 17 The camera enters the recording state. The camera has not entered the recording state. (Recording)
Page 18: Power Input Interface
1.2.5 Power Input Interface The camera power input interface can be connected with the AC power adapter in the product accessories or with a DC power supply (such as a UPS power pack). When using other power sources, please strictly refer to the pin diagram below to construct the cable.
Page 19: Ethernet Interface
1.2.6 Ethernet Interface The network interface of the camera end is X-code cnt12-m12-Z08X09W-Model PIN NO. Name Input/Output Description Remark TRX0+ Input TRX0 Input TRX1+ Input TRX1 Input TRX2+ Input TRX2 Input TRX3+ Input TRX3 Input The wiring method of the cable in the accessories is as follows: Wiring method A end B end...
Page 20: Input/Output Signal Type
1.3. Input/output Signal Type This camera can input and output through I/O cables, and the signals that can be input and output from the I/O cables are as follows. Do not input signals other than the specified ones into each connector. Be particularly careful when using, as there is a risk of damage to both input and output devices.
Page 21: Input 1, 2, 3 Input Interface
1.3.2 INPUT 1, 2, 3 Input Interface The following describes the effects when inputting signals, which can be selected and set. The input voltage is 0V to +5V (+3.3V to +5V for high logic level), and the positive and negative pulse width is 100ns or greater. The default settings are that the INPUT1 connector is designated as "SYNC POS", the INPUT2 connector is designated as "TRIG POS", and the INPUT3 connector is designated as "READY POS".
Page 22 the recorded image.
Page 23: Output 1, 2, Output Interface
1.3.3 OUTPUT 1, 2, Output Interface Standard BNC connector, output voltage from 0V to+5V, positive and negative polarity, pulse width can be changed, minimum 100ns. The default settings are "SYNC POS" for OUTPUT1 and "TRIG POS" for OUTPUT2. The output signal effect is described as follows: Signal Menu Function...
Page 24: Input/Output Circuit Diagram
1.3.4 Input/output Circuit Diagram INPUT: Supports TTL signal, 5V pull-up resistor 4700 Ω, low logic level: -0.5 to +0.5V, high logic level: 3.5 to 5V. OUTPUT: 5V CMOS, low logic level below 0.5V, high logic level above 3.5V, current ≤ ± 4mA, default to high logic level output, with polarity reversal function.
Page 25: Input/Output And Synchronous Output Parameter Settings
1.3.5 Input/output and Synchronous Output Parameter Settings Through this system, you can set signal delay time (filtering) or pulse width for various input and output signals. For detailed settings, please set the parameters in the FASTPHOTO software - IO settings. Input filtering Set filter input pulse width for each INPUT (1,2,3) interface, with a range of 0-6553.5μs TRIG OUT settings...
Page 27: Device Connection
1.4. Device Connection 1.4.1 The Least Device Connection The least device connection for using a camera is as follows.  Network cable (the network cable attached to this product). Power adapter (the accessory adapter of this product). The computer needs to install the FastPhoto software package, and the computer network card needs to support 1Gb or 10Gb types.
Page 28: Connecting Ac Power Supply
1.4.2 Connecting AC Power Supply Connect the provided AC power supply device. Connect the DC end of the power adapter to the "DC-IN (20-32V)" interface on the back of the camera. Connect the AC end to the power outlet.
Page 29: Chapter 2 Specifications
Chapter 2 Specifications This chapter provides an overview of the system's specifications.
Page 30: Specifications
2.1.1. Camera Type and Specifications For SH3 series cameras, there are monochrome and color versions, each with version options 16GB standard memory, 32GB, 64GB and 128GB high-capacity memory. When purchasing, you can choose from these versions according to your application or your...
Page 31 SH3-101 Model SH3-101 Max. Resolution 1280×1024 Full Frame Rate 1000fps Maximum Frame Rate 73000fps Minimum Exposure Time 100ns Exposure Frame Interval 210ns Cell Size 14.6μm Standard RAM 16GB, 32GB, 64GB, 128GB (Optional) Extended Memory 1.2T, 2T, 4T (Optional) Dynamic Range 60dB Analog Gain ×2, ×4, ×8...
Page 32 SH3-103 Model SH3-103 1280×1024 Max. Resolution Full Frame Rate 3000fps Maximum Frame Rate 219000fps Minimum Exposure Time 100ns Exposure Frame Interval 210ns Cell Size 14.6μm Standard RAM 16GB, 32GB, 64GB, 128GB (Optional) Extended Memory 1.2T, 2T, 4T (Optional) Dynamic Range 60dB Analog Gain ×2, ×4, ×8...
Page 33 SH3-105 Model SH3-105 Max. Resolution 1280×1024 Full Frame Rate 5000fps Maximum Frame Rate 367000fps Minimum Exposure Time 100ns Exposure Frame Interval 210ns Cell Size 14.6μm Standard RAM 16GB, 32GB, 64GB, 128GB (Optional) Extended Memory 1.2T, 2T, 4T (Optional) Dynamic Range 60dB Analog Gain ×2, ×4, ×8...
Page 34 Max. Resolution 1280×1024 Full Frame Rate 8000fps Maximum Frame Rate 585000fps Minimum Exposure Time 100ns Exposure Frame Interval 210ns Cell Size 14.6μm Standard RAM 16GB, 32GB, 64GB, 128GB (Optional) Extended Memory 1.2T, 2T, 4T (Optional) Dynamic Range 60dB Analog Gain ×2, ×4, ×8 Bit Depth 8bit/10bit/12bit...
Page 35 SH3-202 Model SH3-202 1920×1080 Max. Resolution Full Frame Rate 2000fps Maximum Frame Rate 20000fps Minimum Exposure Time 100ns Exposure Frame Interval 280ns Cell Size 7.8μm Standard RAM 16GB, 32GB, 64GB, 128GB (Optional) Extended Memory 1.2T, 2T, 4T (Optional) Dynamic Range 60dB Analog Gain ×2, ×4, ×8...
Page 36 SH3-204 Model SH3-204 1920×1080 Max. Resolution Full Frame Rate 3600fps Maximum Frame Rate 365000fps Minimum Exposure Time 100ns Exposure Frame Interval 280ns Cell Size 7.8μm Standard RAM 16GB, 32GB, 64GB, 128GB (Optional) Extended Memory Dynamic Range 60dB Analog Gain ×2, ×4, ×8 Bit Depth 8bit/10bit/12bit Shutte Mode...
Page 37 SH3-502 Model SH3-502 2560×1920 Max. Resolution Full Frame Rate 2000fps Maximum Frame Rate 365000fps Minimum Exposure Time 100ns Exposure Frame Interval 280ns Cell Size 7.8μm Standard RAM 16GB, 32GB, 64GB, 128GB (Optional) Extended Memory Dynamic Range 60dB Analog Gain ×2, ×4, ×8 Bit Depth 8bit/10bit/12bit Shutte Mode...
Page 38: Ac/Dc Adapter
2.1.2. AC/DC Adapter Manufacturer Dongguan City Gangqi Electronics Co., Ltd. Type GQ120-2400500-E4 Input AC100-240V, 50-60Hz, Max. 2A Rating Output DC24V, 5.0A 153.5(L) x 66.2(W) x 32.35(H)mm, excluding Dimensions protrusion parts Weight 556.4g...
Page 39: Dimensions
Dimensions 2.2.1. Dimensions of the Camera...
Page 40: Dimensions Of The Ac Power Supply Device
2.2.2. Dimensions of the AC Power Supply Device...
Page 41: Chapter 3 Warranty
Chapter 3 Warranty This chapter provides an overview of warranty.
Page 42: About Warranty
Consumables (e.g. cables) When the system is repaired, adjusted or replaced by an entity other than SSZN service, and subsequent damage or failure is caused by using the product. Please contact the dealer from whom you purchased the product or the nearest SSZN office if you have any questions regarding malfunctions.
Page 43: Chapter 4 Contact Sszn
Chapter 4 Contact SSZN This chapter lists contact information that should be used to contact SSZN when there is a system malfunction or when certain parts of the manual are unclear.
Page 44: Contact Information
4.1. Contact Information For inquiries about SH3 high-speed cameras, please contact SSZN through the following information. In addition, you are kindly required to verify and prepare the following items before the inquiry. Items that need to be Required information verified...
