Bale/Low Loader Trailers
OPERATING & SAFETY INSTRUCTIONS
For all spare parts please visit:
www.marshall-trailers.co.uk
For all trailer models please contact:
Charles J. Marshall (Aberdeen) Ltd
Chapel Works, Bucksburn, Aberdeen AB21 9TL
Telephone: 01224 722777
Email: admin@marshall-trailers.co.uk
www.marshall-trailers.co.uk
Website:
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Marshall Amplification BC-21
- Page 1 Bale/Low Loader Trailers OPERATING & SAFETY INSTRUCTIONS For all spare parts please visit: www.marshall-trailers.co.uk For all trailer models please contact: Charles J. Marshall (Aberdeen) Ltd Chapel Works, Bucksburn, Aberdeen AB21 9TL Telephone: 01224 722777 Email: admin@marshall-trailers.co.uk www.marshall-trailers.co.uk Website:...
- Page 3 EC Declaration of Conformity Charles J. Marshall (Aberdeen) Ltd of Chapel Works, Bucksburn, Aberdeen, AB21 9TL United Kingdom Declares that the product: Make: Charles J. Marshall (Aberdeen) Ltd Type: Marshall Trailer Model: Serial No: Conforms to the essential health & safety requirements of 98/37/EC as amended by 2006/42/EC directive.
- Page 4 Ensure to NEVER overload the bed of the trailer. The Rating of bale trailers is as follows. BC-25- BC-25- BC-32- BC-32- BC-36- BC-36- BC-21 BC-28 Our Two Low Loader Trailers are rated as follows. LL-26-TAN 16 Tonnes LL-33-TRI 21 Tonnes...
- Page 5 LOW LOADER INSTRUCTIONS Connect hydraulic hoses to tractor spool valve. Rotate locking handle at the near side rear to raise the ram safety stops. If no rear ramp spool valve is fitted the entire rear ramp can now be operated from inside the tractor by simply operating the spool valve in different directions.
- Page 6 MAINTENANCE INSTRUCTIONS 1. Check all hydraulic hoses for chaffing, signs of wear and perishing. 2. Hinge Points shall wear, causing serious damage and posing an obvious safety problem. Pins should be removed and checked annually. Replace as necessary, not forgetting ram bolts. 3.
- Page 7 AIR BRAKE INSTRUCTIONS 1. To connect the air brakes, plug the yellow and red Suzi’s into the corresponding connectors on the tractor. Ensure the hydraulic braking system is left unplugged. 2. Trailers equipped with rocking beam suspension will have a manual load sensing system that adjusts the brake force via a handle mounted on the front upstand.
- Page 8 TYRE PRESSURE CHART PART NUMBER SIZE MAX. HEIGHT SPEED MAX. TYRE PRESS. PLEASE NOTE THIS CHART IS FOR REFERENCE ONLY EACH TYRE BRAND CAN HAVE DIFFERENT RATINGS. 083-01-26-12 26 x 1200 x 12 800kg 25km/h 20psi 083-01-100-12 10.0/80x12 10ply 1000kg 30km/h 45psi 083-01-100-15...
- Page 9 Marshall Pre-delivery Inspection Check Dealer Name: Customer Name: Address & Post Code: Model: Serial Number: Check Completed Check tyre pressure (See chart on page 6) Tighten wheel nuts 18mm stud diameter = 270Nm & 22mm stud diameter = 475Nm Check U-bolt torque 19mm bolt diameter = 270Nm 22mm bolt diameter = 540Nm &...
