- Page 1 User manual REP01-15 Digital end position sensor Cover Valid from: Firmware version: --- Server version: --- Hardware version: 1.0 301640 | Rev.01...
- Page 3 Chapter 1 Table of contents Chapter 1 Table of contents Cover Chapter 1 Table of contents Chapter 2 Declaration of conformity Chapter 3 Certification Chapter 4 Specifications Chapter 5 General specifications 5.1 Translation 5.2 Copyright 5.3 General descriptive names 5.4 Ex protection 5.5 Safety instructions 5.5.1 Use of the hazard warnings 5.6 Overview...
- Page 4 8.2 Installing the REP01-15 8.2.1 Aligning the REP01-15 8.3 Electrical installation 8.3.1 Connecting a compatible data logger 8.3.2 Technical details about the output signal Chapter 9 Initial Start-Up 9.1 User information 9.2 Applicable documents 9.3 General principles Chapter 10 User interfaces Chapter 11 Maintenance 11.1 General maintenance...
- Page 5 Chapter 2 Declaration of conformity Chapter 2 Declaration of conformity Rev. 01...
- Page 7 Chapter 3 Certification Chapter 3 Certification Rev. 01...
- Page 9 Chapter 4 Specifications Chapter 4 Specifications Voltage supply 15 V , 22 V or 24 V : 29 V : 100 mA : 600 mW : 7,8 µH : 2,1 nF Housing Material: MJF-PA12 Weight: 570 g Degree of protection: IP68 (max.1 m immersion depth for 24 h ) Dimensions (DL): 28 x 97 mm (without connection cable) Comparable ATEX II 2G Ex ib IIC T4 Gb...
- Page 11 5.4 Ex protection The digital end position sensor REP01-15 is a "simple apparatus" that is suitable for use in areas with an ATEX Zone 1 and ATEX Zone 2 explosive atmosphere. The REP01-15 also has the following characteristics: With the ambient temperature range of -20...+50 °C the product is classified in temperature class T4.
- Page 12 The connecting cable must be firmly installed and adequately protected against mechanical impact. The REP01-15 must be mounted in such a way that the housing is protected from mechanical impact/damage. When used in hazardous areas, EN60079-11 and EN 60079-14 must be observed.
- Page 13 Note: Indicates a situation that does not result in any injury to persons. Note: Information that supplements the specifications in the main text. 5.6 Overview Right side of the REP01-15 1 Magnet (included in the scope of supply) 3 Mounting thread (M20 )
- Page 14 4-20 mA current loop (see "Technical details about the output signal" on page 28). 5.9 Device labelling The specifications in this user manual apply exclusively to the device type REP01-15 . The type plate is located on the side of the device and contains the following specifications:...
- Page 15 It is strictly prohibited to disable the safety equipment or modify its mode of operation. 5.10 Storage of the product The REP01-15 does not include a special transport mode. Store the REP01-15 in its original packaging. 5.11 Warranty The device has been functionally tested before delivery. If it is used as intended (see "Intended use" on page 14) and the operating instructions, the applicable documents(see "Applicable documents "...
- Page 16 For safety and warranty reasons, all internal work on the instruments beyond from that involved in normal installation and connection, must be carried out only by qualified Microtronics personnel or persons or companies authorised by Microtronics .
- Page 17 Chapter 5 General specifications 5.14 Personnel requirements Installation, commissioning and maintenance may only be completed by personnel who meet the following conditions: Qualified specialist personnel with the relevant training Authorised by the facility operator Note: Qualified personnel In the context of these instructions and the warnings on the product itself, individuals responsible for the setup, installation, commissioning and operation of the product must have gained relevant qualifications relating to their activities, including, for example: Training, instruction and authorisation to activate/deactivate, ground and label electric circuits and...
- Page 19 1 Magnet (included in the scope of supply) 3 Compatible data logger (e.g. myDatalogEx LTE-M ) 2 REP01-15 Functions and components: REP01-15 It is a "simple apparatus" designed for use in ATEX Zone 1 and ATEX Zone 2 which allows detecting whether a moving object to be monitored is in a defined end position.
- Page 21 An RMA number is mandatory for any returns and can be obtained from the Support & Service Centre (see "Contact information" on page 43). The return shipment of the REP01-15 must occur in the original packaging and with freight and insurance paid to Microtronics Engineering GmbH (see "Contact information"...
- Page 23 When mounting and aligning the REP01-15 , the following conditions must be observed: The magnet and the REP01-15 must be on the same axis. The distance between the magnet and REP01-15 must be less than 11 mm when the object to be monitored is in the end position.
- Page 24 Aligning the REP01-15 1 Magnet (included in the scope of supply) 3 REP01-15 2 M20x1,5 adjusting nut (included in the scope of supply) : Sensing distance (On: 11 mm , off: 16 mm ) Switch : The length of the mounting thread (M20 , 32 mm ) and the width of the adjusting nut included in Thread the scope of supply result in an adjustment range of 20 mm .
- Page 25 2 Mounting bracket (not included in the scope of supply) 3. Check the distance between the magnet and REP01-15 when the object to be monitored is in the end position. To ensure that the reed contact triggers reliably, this distance must not be greater than 11 mm .
- Page 26 2 Cable connector of the REP01-15 1. Ensure that the data logger you would like to connect to the REP01-15 is ready for operation. You can find instructions on how to do this in the "Commissioning the system" chapter of the manual for the respective data logger.
- Page 27 The following step is not mandatory. 7. Check whether the reed contact of the REP01-15 triggers correctly when the object to be monitored is in the defined end position. To do so, evaluate the data transmitted from the data logger to the myDatanet server.
- Page 28 8.3.2 Technical details about the output signal The REP01-15 is a "Simple apparatus". It therefore contains no active components but only a passive resistor network to convert the digital signal of the reed contact into a mA signal. The output signal is therefore dependent on the selected sensor supply voltage and the internal resistors of the data logger.
- Page 29 Study the manual thoroughly before placing into operation to prevent faulty or incorrect configuration. Utilise the manual to familiarise yourself with the operation of the REP01-15 and the input screens of the myDatanet server before you begin with the configuration.
- Page 31 This includes the selection of the sensor supply voltage (15 V , 22 V or 24 V ) and of the correct mode (0...20 mA or 4...20 mA) for the input the REP01-15 should be connected to. If an alarm is also to be triggered when the contact closes or opens, the appropriate alarm threshold must also be set depending on the sensor supply voltage ( 7 mA at 15 V supply and 10 mA at 22 V or 24 V supply).
- Page 33 Check all of the cables for mechanical damage at regular intervals. Clean the REP01-15 with a soft, moist cloth. Use a mild cleaning agent, if necessary. Important note: Due to the electrostatic effects, the REP01-15 must not be rubbed with cloths in the Ex zone.
- Page 35 Logo of the EU WEEE Directive This symbol indicates that the requirements of Directive 2012/19/EU regarding the scrap disposal of waste from electric and electronic equipment must be observed. Microtronics Engineering GmbH supports and promotes recycling and environmentally friendly, separate collection/disposal of waste from electric and electronic equipment in order to protect the environment and human health.
- Page 37 Check whether the sensing distance is maintained (see (no recognisable switch between "Specifications" on page 9). Check the alignment of the REP01-15 (see "Aligning the REP01- closed and open) 15 " on page 23). There is another magnetic field in the immediate vicinity, which overrides the magnetic field of the magnet attached to the object to be monitored.
- Page 39 Important note: Always check the specifications detailed in the manual for the relevant data logger, whether the device you have selected is approved for use in the intended environment (Ex zone). Note: A corresponding IoT app is required to use the REP01-15 in conjunction with the data loggers listed in the following table.
- Page 41 Chapter 15 Document history Chapter 15 Document history Rev. Date Changes 19.01.2024 First version Rev. 01...
- Page 43 Chapter 16 Contact information Chapter 16 Contact information Support & Service: Microtronics Engineering GmbH Hauptstrasse 7 3244 Ruprechtshofen Austria, Europe Tel. +43 (0)2756 7718023 support@microtronics.com www.microtronics.com Microtronics Engineering GmbH (Headquarters) Hauptstrasse 7 3244 Ruprechtshofen Austria, Europe Tel. +43 (0)2756 77180 Fax.
- Page 44 Certified by TÜV AUSTRIA: EN ISO 9001:2015, EN ISO 14001:2015, ISO/IEC 27001:2013, EN ISO 50001:2011 for myDatanet | TÜV SÜD: ATEX Directive 2014/34/EU © Microtronics Engineering GmbH. All rights reserved. Photos: Microtronics, shutterstock.com Microtronics Engineering GmbH | www.microtronics.com Hauptstrasse 7 | 3244 Ruprechtshofen | Austria | +43 2756 77180 | office@microtronics.com 301640 | Rev.01...
