INTRODUCTION Thank you for purchasing this CLARKE Respirator. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
PRODUCT SPECIFICATIONS DARKENING HELMET Viewing field (W x H) 100 x 98 mm Shade available in Light State DIN4 Shade available in Dark State DIN 9-13 UV/IR protection Max shade DIN16 at all times Operating temperature range C - +55 Weight 400g Switching time from light to dark...
SECTION 1 - SAFETY PRECAUTIONS USING THE HEADSHIELD 1. This headshield is not suitable for laser welding, laser cutting or overhead welding applications or for oxy-acetylene usage. 2. The lens in this headshield is breakable and will not protect against impact hazards.
Page 5
6. DO NOT weld on coated metals such as galvanized, lead, or cadmium plated steel, unless the coating is removed from the weld area, the area is well ventilated, and while wearing an air-supplied respirator. The coatings and any metals containing these elements can give off toxic fumes if welded.
Page 6
19. ALWAYS wear the powered air purifying respirator when entering a contaminated area. DO NOT remove the respirator until outside the contaminated area. 20. Dangerous contaminants may not smell or be visible. Leave the area immediately if you notice the following: •...
d. NEVER attempt to clean the filter by knocking or blowing out accumulated material. Doing so will damage the filter media. 4. Failure to follow these user instructions may reduce respirator performance and expose you to contaminants. 5. Read and follow all user instructions in order to ensure correct system operation.
SECTION 2 - POWERED AIR PURIFYING RESPIRATOR CHARGING THE BATTERY Remove the battery from the blower assembly and connect the charging cable.Plug the charger into a suitable mains socket. DO NOT allow the battery to get wet. DO NOT attempt to open the battery case.
Page 9
ATTACHING THE BREATHING HOSE Insert the hose connector into the blower receptacle until snug and then turn 1/8 turn to the right to lock it into place. 1. Welding helmet 2. Face seal 3. Headgear terminal 4. Breathing Hose terminal 1 5.
OPERATING THE CONTROLS 1. Low Speed Indicator 2. High Speed Indicator 3. Danger Indicator 4. Battery Level Indicator 5. Power On/Off Button 6. Low/High, SELECT Button To start, press the On button for 1 second until the blower starts. • The Danger, Low Speed, High Speed Indicator lights come on, then go out, the alarm sounds and the blower vibrates momentarily.
Page 11
TESTING THE AIR-FLOW Disconnect the breathing hose from the hood. Insert the flowmeter into the breathing hose. Hold the flowmeter straight up and start the blower. The flowmeter ball should be above the MIN mark. If the flowmeter reads MIN or below, check the battery and filter elements.
Page 12
Continue blocking the air flow until the alarm sounds and the blower vibrates. If the alarm does not sound and the blower does not vibrate, check the battery and filter element. CHECKING THE RESPIRATOR BEFORE USE Before using the respirator, check the following items: 1.
SECTION 3-AUTO-DARKENING WELDING HELMET The Solar-Powered Auto-Darkening Welding Helmet is suitable for most welding and grinding applications. This helmet comes with a 1/30,000-second switching time which automatically darkens the lens the moment you start welding. No matter what shade the filter is set to, the UV/IR protection is always present.
SECTION 4 - PREPARATION & USE WARNING: IT IS ESSENTIAL THAT AFTER USING THE HEADSHIELD IN GRINDING MODE, IT SHOULD BE RETURNED TO THE CORRECT SETTING BEFORE WELDING. FAILURE TO DO THIS COULD LEAD TO EYE INJURY. USING THE HELMET 1.
SCREEN SETTINGS SELECT THE SHADE SETTING WARNING: DO NOT USE FOR WELDING OUTSIDE THE RANGE OF DIN 9-13. INJURY TO THE EYES & LOSS OF EYESIGHT MAY BE CAUSED. On striking an arc, the light created will activate the solar cell and the window will automatically darken to a preset level.
Page 16
SHADE GUIDE TABLE Shade numbers according to BS 379, DIN 4647-1 and EN 169. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
SENSITIVITY CONTROL The sensitivity can be set from LOW to HIGH using the dial knob. The LOW setting suits excess ambient light or with another welding machine close by. The HIGH setting suits low amperage welding and welding in areas with low light conditions, especially low amperage argon arc welding.
SECTION 5-CARE & MAINTENANCE HELMET CARE & MAINTENANCE Damaged components must be replaced immediately to avoid risk of eye and face injuries. Periodically inspect the filter cartridge and lenses. Cracked, pitted or scratched lenses reduce vision and seriously reduce the level of protection and should be replaced with genuine, certified spare parts.
RESPIRATOR CARE & MAINTENANCE The respirator must be used together with the correct particle filter at all times. The particle filter can not be cleaned. DO NOT attempt to remove contamination using for example, compressed air, as this will destroy the filters, which will not give the expected protection and the warranty will be invalidated.
CLEANING Detach the battery pack and breathing hose from the blower. Inspect all parts for damage and replace any damaged parts prior to storage or next use. a. Blower: Clean the outer surfaces of PAPR assembly and battery pack with a soft cloth dampened in a solution of water and mild, pH neutral detergent.
ENVIRONMENTAL PROTECTION If broken, DO NOT dispose of this product with general household waste. This product contains valuable raw materials and should be disposed of appropriately at a recognised disposal facility. Through purchase of this product, the customer is taking on the obligation to deal with the WEEE in accordance with the WEEE regulations in relation to the treatment, recycling &...
Page 22
COMPONENT PARTS-HELMET Helmet shell Height adjusting pin Front cover lens Diameter adjusting knob Rubber gasket Angle/distance adjusting knobs Protective plate Retaining frame GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase.
