BRK-SB Assembly Instructions Guide
BRK-SB Assembly Instructions Guide
Assembly Instructions
Step 1:
• Double check dimension size, and clean assembled flange surface of servomotor and
brake.
Step 2:
• Remove Key from motor shaft (as below red circle).
L011953
Tel. (714) 992-6990
www.anaheimautomation.com
4985 East Landon Drive Anaheim, CA 92807
Fax. (714) 992-0471
Advertisement
Related Manuals for Anaheim Automation BRK-SB Series
Summary of Contents for Anaheim Automation BRK-SB Series
- Page 1 BRK-SB Assembly Instructions Guide BRK-SB Assembly Instructions Guide Assembly Instructions Step 1: • Double check dimension size, and clean assembled flange surface of servomotor and brake. Step 2: • Remove Key from motor shaft (as below red circle). L011953 Tel. (714) 992-6990 www.anaheimautomation.com 4985 East Landon Drive Anaheim, CA 92807 Fax. (714) 992-0471...
- Page 2 BRK-SB Assembly Instructions Guide BRK-SB Assembly Instructions Guide Step 3.1: • Put Brake at the bottom and motor at the top. Place them vertically. Step 3.2: • Use wrench to tighten mounting bolts (including washer) in sequence 1~4 by 5% tighten torque to assembly brake and servomotor. Step 4: • Use wrench to tighten the set collar bolt by 5% tighten torque. L011953 Tel. (714) 992-6990 www.anaheimautomation.com 4985 East Landon Drive Anaheim, CA 92807 Fax.
- Page 3 BRK-SB Assembly Instructions Guide BRK-SB Assembly Instructions Guide Step 5: • Use wrench to tighten mounting bolts (including washer) in sequence 1~4 by full tighten torque to assembly brake and servomotor. Step 6: • Use wrench to tighten back screw plug by full tighten torque. L011953 Tel. (714) 992-6990 www.anaheimautomation.com 4985 East Landon Drive Anaheim, CA 92807 Fax. (714) 992-0471...
